Hexadecimal Port Diagrams

Many of the commands, such as bcastshow, portLogShow, and
portLogDump return port diagrams in hexadecimal format.

Reading Hexadecimal Port Diagrams

The following example shows the bcastshow command and a member port list,
member ISL port list, and static ISL port list in hexidecimal format.
Example:
switch:admin> bcastshow
Group Member Ports
----------------------------------------------------------------
256 0x00000000
0x00000000
0x00000001
0x00012083
switch:admin>
To read the hexadecimal port diagrams, they must be converted into binary
notation. Each hexadecimal value represents four binary values. Each
hexadecimal value is converted into a group of four binary values that represent
four ports, as follows:
Table 4: Hexidecimal to binary conversions
Fabric OS Procedures Version 3.1.x/4.1.x User Guide
Member ISL Ports
0x00000000
0x00000000
0x00000000
Hex value = Binary value
0 = 0000
1 = 0001
2 = 0010
3 = 0011
4 = 0100
Basic Switch Management
Static ISL Ports
0x00000000
0x00000000
0x00000000
Hex value = Binary value
8 = 1000
9 = 1001
A = 1010
B = 1011
C = 1100
73
