Description Of Software Features - SMC Networks SMCGS10C-SMART Management Manual

| Introduction
C 1
HAPTER

Description of Software Features

D S
ESCRIPTION OF OFTWARE
C
ONFIGURATION
B
ACKUP AND
R
ESTORE
A
UTHENTICATION
Table 1: Key Features (Continued)
Feature Description
Spanning Tree Algorithm Supports standard STP, Rapid Spanning Tree Protocol (RSTP), and
Multiple Spanning Trees (MSTP)
Virtual LANs Up to 4K using IEEE 802.1Q, port-based, protocol-based, private
VLANs, and voice VLANs, and QinQ tunnel
Traffic Prioritization Queue mode and CoS configured by Ethernet type, VLAN ID, TCP/
UDP port, DSCP, ToS bit, VLAN tag priority, or port
Qualify of Service Supports Differentiated Services (DiffServ), and DSCP remarking
Link Layer Discovery Used to discover basic information about neighboring devices
Protocol
Multicast Filtering Supports IGMP snooping and query, MLD snooping, and Multicast
VLAN Registration
F
EATURES
The switch provides a wide range of advanced performance enhancing
features. Flow control eliminates the loss of packets due to bottlenecks
caused by port saturation. Storm suppression prevents broadcast,
multicast, and unknown unicast traffic storms from engulfing the network.
Untagged (port-based), tagged, and protocol-based VLANs provide traffic
security and efficient use of network bandwidth. CoS priority queueing
ensures the minimum delay for moving real-time multimedia data across
the network. While multicast filtering provides support for real-time
network applications.
Some of the management features are briefly described below.
You can save the current configuration settings to a file on the
management station (using the web interface) or a TFTP server (using the
console interface through Telnet), and later download this file to restore
the switch configuration settings.
This switch authenticates management access via a web browser. User
names and passwords can be configured locally or can be verified via a
remote authentication server (i.e., RADIUS or TACACS+). Port-based
authentication is also supported via the IEEE 802.1X protocol. This protocol
uses Extensible Authentication Protocol over LANs (EAPOL) to request user
credentials from the 802.1X client, and then uses the EAP between the
switch and the authentication server to verify the client's right to access
the network via an authentication server (i.e., RADIUS or TACACS+
server).
Other authentication options include HTTPS for secure management access
via the web, SSH for secure management access over a Telnet-equivalent
connection, SNMP Version 3, IP address filtering for SNMP/Telnet/web
management access, and MAC address filtering for port access.
– 21 –
