SMC Networks TigerStack II SMC8848M Management Manual page 757

therefore specified by this command at the interface configuration
level.
• If a link-local address has not yet been assigned to this interface, this
command will assign the specified static global unicast address and
also dynamically generate a link-local unicast address for the interface.
(The link-local address is made with an address prefix of FE80 and a
host portion based the router's MAC address in modified EUI-64
format.)
• If a duplicate address is detected, a warning message is sent to the
console.
Example
This example uses the general network prefix of 2009:DB9:2229::/48 used
in an earlier example, and then specifies the subsequent prefix bits
0:0:0:7279::/64, and finally the host address portion of 79.
Console(config)#interface vlan 1
Console(config-if)#ipv6 address rd 0:0:0:7279::79/64
Console(config-if)#end
Console#show ipv6 interface
Vlan 1 is up
IPv6 is enable.
Link-local address:
FE80::200:E8FF:FE90:0/64
Global unicast address(es):
2009:DB9:2229:7279::79, subnet is 2009:DB9:2229:7279::/64
Joined group address(es):
FF01::1/16
FF02::1/16
FF02::1:FF00:79/104
FF02::1:FF90:0/104
MTU is 1500 bytes.
ND DAD is enabled, number of DAD attempts: 1.
ND retransmit interval is 1000 milliseconds
Related Commands
ipv6 address eui-64 (36-18)
ipv6 address autoconfig (36-16)
show ipv6 interface (36-22)
ip address (36-4)
