6-1 DeviceNet Setting Procedures

6-1-1 Designing Networks Offline

6-1 DeviceNet Setting Procedures
This section describes the setting operations that are unique to DeviceNet networks.
Refer to Section 2 Basic Operations for operation that are the same as those for other
networks.
The following flowcharts show the overall flow of DeviceNet settings.
6-1-1 Designing Networks Offline
Prior to constructing the actual network, it can be designed and the master and slave
parameters can be set with the CX-Integrator.
The set parameters can be saved as a network configuration file. The network
configuration file contains the parameters of all of the devices on the network.
(only for the slaves that require parameter setting).
Save the settings in a CX-Integrator project file (.cin).
6-1-2

Downloading Saved Parameters

The parameters for all of the devices on the network can be set (downloaded) from a
network configuration file saved in advance.
6-2
Start the CX-Integrator.
Create the virtual network offline.
Set the slave parameters
Register the slaves with the master.
Set the master's parameters.
Start the CX-Integrator.
Read the CX-Integrator project file (.cin).
Connect to the network (online).
Download to the network or download
parameters to each device.
2-5 Creating Virtual Network Structures Offline
6-2 Setting Slave Parameters
6-3 Adding Slaves to the Master
6-5 Editing Master Parameters
2-9 File Operations
2-9 File Operations
2-2 Connecting Online to the Relay PLC
2-6 Manipulating Component Parameters
2-7 Uploading, Downloading, and Comparing Network
Parameters
