About this Manual:
This manual describes the installation and operation of CX-Integrator and includes the sections
described below.
Please read this manual carefully and be sure you understand the information provided before
attempting to use the CX-Integrator. Be sure to read the precautions provided in the following section.
Precautions provides general precautions for using the CX-Integrator.
Section 1 outlines the functions of the CX-Integrator and describes the menus and connecting to
networks.
Section 2 describes the basic operations required to use the CX-Integrator.
Section 3 describes how to set routing tables.
Section 4 describes how to set data links for Controller Link and SYSMAC LINK Networks.
Section 5 describes how to use the diagnostic tools for Controller Link Networks.
Section 6 describes settings and operations unique to DeviceNet Networks, including registering
slaves in the master, allocating I/O, monitoring devices, etc.
Section 7 describes the basic use of and how to set parameters for CompoNet Networks.
Section 8 describes settings and operations unique to CompoWay/F Networks.
Section 9 settings and operations unique to NT Links.
Section 10 describes operations for testing networks using the Controller Link Network Diagnostic
Tool, echoback tests between nodes, and Ethernet ping tests.
The Appendix describes CPS files for Ethernet, Controller Link, CompoWay/F, and NT Link
Networks and EDS files for DeviceNet Networks.
!WARNING
Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
xiii
