Reliable Transaction Router

System Manager's Manual

Order Number: AA-Q88CE-TE

June, 1999

This manual describes how to conﬁgure, manage and monitor Reliable

Transaction Router, Version 3.2 (RTR).

Revision/Update Information:

Software Version:

Compaq Computer Corporation

Houston, Texas

This manual supersedes Version 3.1D

of the System Manager's Manual

Reliable Transaction Router, Version

3.2

Table of Contents

Summary of Contents for Compaq AA-Q88CE-TE

Page 1: Reliable Transaction Router
Reliable Transaction Router System Manager’s Manual Order Number: AA-Q88CE-TE June, 1999 This manual describes how to conﬁgure, manage and monitor Reliable Transaction Router, Version 3.2 (RTR). Revision/Update Information: Software Version: Compaq Computer Corporation Houston, Texas This manual supersedes Version 3.1D of the System Manager’s Manual...
Page 2 The software may be used or copied only in accordance with the terms of the agreement. Compaq and the Compaq logo are registered in the United States Patent and Trademark Ofﬁce. The following are trademarks of Compaq Computer Corporation: AlphaGeneration, AlphaServer,...
Page 3: Table Of Contents
Preface ............1 Introduction Getting Started .
Page 4 Life Cycle of a Partition ........3.3.1 Implicit Partition Creation .
Page 5 5.2.14 Monitor IPCRATE ........5.2.15 Monitor Journal .
Page 6 DISPLAY BAR ..........DISPLAY NUMERIC .
Page 7 STOP RTR ..........TRIM FACILITY .
Page 8 Figures 2–1 Conﬁguration Example ........2–2 Extend Conﬁguration Example .
Page 9 A–3 Arithmetic Operators in Display Commands ....A–4...
Page 11: Preface
Purpose of this Manual This manual describes how to conﬁgure, manage and monitor the operation of Reliable Transaction Router (RTR) using the RTR Command Line Interface (CLI). Intended Audience The System Manager’s Manual is intended for persons who perform system management functions to conﬁgure, test, monitor and maintain RTR applications.
Page 12: Related Documentation
• Application Design Guide • Migration Guide Reader’s Comments Compaq welcomes your comments on this manual. Please send us your comments by email to rtrdoc@compaq.com Include the title of the manual, section and page numbers with your comments or suggestions.
Page 13: Conventions Used In This Guide
Table 1 Conventions Used in this Guide Convention Meaning UPPERCASE Some operating systems differentiate between lowercase and lowercase uppercase characters. For these systems, examples, syntax descriptions, function deﬁnitions, and literal strings that appear in text must be typed exactly as shown. Commands typed to the RTR CLI are not case sensitive unless enclosed in quote marks A number sign ( # ) is the default operating system superuser prompt.
Page 15: Introduction
For a general introduction to Reliable Transaction Router, Version 3.2 (RTR), you should read the introductory chapter in the Reliable Transaction Router Application Design Guide. Additional information about the Reliable Transaction Router is available in the Reliable Transaction Router Application Programmer’s Reference Manual.
Page 16: Online Help
Introduction 1.2 Entering Commands or, when several commands are to be entered at the RTR prompt: % rtr RTR> start rtr RTR> create journal For convenience, the user prompt for the operating system is shown here as the ‘‘%’’ symbol. Your system may have a different prompt. The RTR CLI accepts commands that you type and can process procedures consisting of RTR commands.
Page 17: Command Procedures
where error-identification The following sequence returns an error message, explained by the % rtr RTR> start rtr %RTR-F-RTRALRSTA, rtr already started RTR> help errors rtralrsta Errors RTRALRSTA RTR already started Explanation: RTR was already running when the "START RTR" command was executed.
Page 18 Introduction 1.5 Remote Commands This command starts RTR on the three nodes. The /CLUSTER and /NOCLUSTER command qualiﬁers refer to cluster support. These qualiﬁers are for operating systems that fully support clustering. Use of the /CLUSTER qualiﬁer on systems that do not have clustering causes the relevant command to be executed on the local node only.
Page 19: Starting And Setting Up Rtr
This chapter describes how to conﬁgure and start an RTR environment. Recovery journals, router load balancing and call-out servers are also discussed. 2.1 Introduction Before RTR applications can run, RTR must be started and the application’s must be deﬁned on each node of the application’s environment. This facility is done by issuing the participating node.
Page 20: Local Conﬁguration Of Each Node
Starting and Setting Up RTR 2.2 Setting Up—An Example Figure 2–1 Conﬁguration Example F r o n t e n d s ( F E ) F E 1 F E 2 F E 3 In this example, the application client processes run on the nodes FE1, FE2 and FE3.
Page 21: Creating A Recovery Journal
Example 2–2 illustrates how to use RTR remote commands to start the same conﬁguration. The commands to a number of RTR nodes. Example 2–2 Remote Setup from one Node % rtr RTR> set environment/node= - _RTR> (FE1, FE2, FE3, TR1, TR2, BE1, BR2, BR3) RTR>...
Page 22: Changing A Facility
Starting and Setting Up RTR 2.3 Creating a Recovery Journal • The operator should move any duplicate copies of journal ﬁles to a location other than the see only the one it created. • Track duplicate copies of journal ﬁles in the log ﬁle to prevent RTR seeing more than the one it created and issuing the SPUJOUFIL error message.
Page 23: Reconﬁguration Using Delete And Create Facility
Example 2–3 Reconﬁguration Using Delete and Create Facility % rtr RTR> stop rtr/node=FE3 RTR> delete facility funds_transfer/node=TR2 RTR> create facility funds_transfer/node=TR2 - _RTR> _RTR> RTR> delete facility funds_transfer/node=TR1 RTR> create facility funds_transfer/node=TR1 - _RTR> _RTR> RTR is stopped on node FE3, the node being excluded from the network. In order to prevent transactions being interrupted or aborted, application processes should be stopped in an orderly manner before issuing the ’stop rtr’...
Page 24: Extend Conﬁguration Example
Starting and Setting Up RTR 2.4 Changing a Facility Figure 2–2 Extend Conﬁguration Example F R O N T E N D S F E 1 F E 2 F E 3 F E 4 All backend nodes must be informed when router conﬁgurations are changed. Because TR3 will be a router for the FE3 and FE4 frontends, these nodes must also be informed of its presence.
Page 25: Reconﬁguration Using Extend Facility
Example 2–4 Reconﬁguration Using Extend Facility % RTR RTR> start rtr /node=(TR3,FE4) RTR> set environment/node= - _RTR> (FE1,FE2,FE3,TR1,TR2,BE1,BE2,BE3,TR3,FE4) RTR> extend facility funds_transfer - _RTR> /router=TR3/frontend=(FE3,FE4) - _RTR> /backend=(BE1,BE2,BE3) RTR> extend facility funds_transfer - _RTR> /router=TR1/frontend=FE4 set environment the facility, including the new nodes. extend facility Because the new router is also connected to the existing frontend FE3, this node must also be speciﬁed as a frontend.
Page 26: Conﬁguration Of Callout Servers
Starting and Setting Up RTR 2.5 Setting up Callout Servers Example 2–5 Conﬁguration of Callout Servers % rtr RTR> set environment/node= - _RTR> (FE1,FE2,FE3,TR1,TR2,BE1,BE2,BE3) RTR> start rtr RTR> create facility funds_transfer/frontend=(FE1,FE2,FE3) - _RTR> _RTR> _RTR> 2.6 Router Load Balancing Router load balancing, or intelligent re-connection of frontends to a router is possible, allowing a frontend to select the router that has least loading.
Page 27: Rtr Privileges
• /balance only to enable RTR Version 2 balancing. Use this qualiﬁer only when you are connecting frontend nodes running RTR Version 2. See CREATE FACILITY and SET FACILITY for more information on • Commands to set/show load balancing are: create facility /balance Enables load balancing attribute on the executor node Signiﬁcant only on router and frontend nodes...
Page 28: Rtr Acp Virtual Memory Sizing
RTR ACP process is using. Compaq strongly recommends that you allocate as much virtual memory as possible. While there is no penalty for allocating more virtual memory than is used, the result of allocating too little can be catastrophic.
Page 29 • Add the size of all messages 2. For each transaction router: • Allow one Kbyte for each active transaction 3. For each back end: • Allow one Kbyte per active transaction • Allow ﬁfty bytes for each message of a transaction •...
Page 30: Unix Virtual Memory Sizing
The following are the minimum limits for the ACP on the following UNIX platforms: • On Compaq Tru64 UNIX: A minimum of 1024 open ﬁle descriptors A minimum of 1073742 Kbytes for virtual memory address space A minimum of 268436 Kbytes for a single ﬁle size A minimum of 419430 Kbytes for heap data segment sizing A minimum of 33555 Kbytes for core ﬁle size...
Page 31: Network Transports
A minimum of 419430 Kbytes for heap data segment sizing A minimum of 33555 Kbytes for core ﬁle size A minimum of 8389 Kbytes for stack segment size A minimum of 0 for CPU time • On HPUX: A minimum of 1024 open ﬁle descriptors The START RTR qualiﬁers /LINK and /PROCESSES apply only to the OpenVMS platform and the determination of process quotas on UNIX platforms must be done through operating system handling of virtual memory sizing.
Page 32: Using Rtr With Dhcp And Internet Tunnels
Valid wild card characters are ‘‘*’’, ‘‘%’’ and ‘‘?’’. The result of using a wild card character at facility conﬁguration time is the creation of a template link. When operating RTR in conjunction with the Compaq Internet Personal Tunnel, a client system outside of the corporate ﬁrewall uses tunnel software to obtain a secure channel from the Internet to inside the corporate domain.
Page 33: Interoperation With Rtr Version 2 Using Decnet
If the RTR V3 frontend fails to connect with the RTR V2 router node, then you can make a basic check by executing a OpenVMS router node. If this fails, consult your Network Manager. (For Compaq Tru64 UNIX machines, ensure that the DECnet library is installed as /libdna.so...
Page 34: Network Protocol Selection On Openvms
If the value of the logical RTR_PREF_PROT is changed, the new value takes effect only after RTR has been restarted. • Reliable Transaction Router Version 3.2 for OpenVMS can use either Compaq TCP/IP Services for OpenVMS or TCPware Version 5.1 as the TCP/IP transport layer.
Page 35: Customizing The Rtr Windows Nt Service
2.11.1 Customizing the RTR Windows NT Service While starting RTR, the Service looks for the ﬁle directory. On ﬁnding the ﬁle, the Service executes any RTR commands it may contain. RTR commands from From the point of view of the Service, the RTR home directory is found in the system-level environment variable the directory from which the Service was executed.
Page 36: How Rtr Selects Processing-States (Roles) For Nodes
Starting and Setting Up RTR 2.12 How RTR Selects Processing-states (Roles) for Nodes 2.12 How RTR Selects Processing-states (Roles) for Nodes This section discusses how RTR assigns roles to backend node partitions, and how routers are selected. 2.12.1 Role Assignment for Backend Node Partitions RTR assigns a primary or secondary processing state to a partition (or a key- range deﬁnition), consisting of one or more server application channels, which may or may not share a common process.
Page 37 2.12 How RTR Selects Processing-states (Roles) for Nodes The SHOW PARTITION command on each backend node is as follows: Backend partitions on node BRONZE in group "test" at Mon Mar 22 14:52:32 1999 Partition name: Facility: RTR$DEFAULT_FACILITY Low bound: Active servers: Transaction presentation: active Active transaction count:...
Page 38 Starting and Setting Up RTR 2.12 How RTR Selects Processing-states (Roles) for Nodes 8. The network connection to node Gold is reestablished. The partition on Gold retained its original sequence number of 2 and retains the primary role while the partition on Bronze reassumes the secondary role. Alternately, the roles of backend nodes can be speciﬁcally assigned with the /PRIORITY_LIST qualiﬁer to the SET PARTITION command.
Page 39: Router Selection
2.12 How RTR Selects Processing-states (Roles) for Nodes Router If the relative priority (sequence number) for Node-A2 is changed to four it still becomes the primary active server if Node-A1 fails because the failover policy indicates a fail_to_standby requirement for this facility. SET PARTITION test/PRIORITY_LIST=(Node-A1,Node-B1,Node-B2,Node-A2) After issuing this command the router partition appears as follows.
Page 40 Starting and Setting Up RTR 2.12 How RTR Selects Processing-states (Roles) for Nodes relevant to a backend. It is where the backend goes to obtain and verify partition conﬁguration and facility information. Routers are made known to the frontend systems through the list speciﬁed in the /ROUTER=(list) qualiﬁer to the CREATE FACILITY command.
Page 41: Partition Management
3.1 Overview This section describes the concepts and operations of RTR’s partitions. 3.1.1 What is a Partition? Partitions are subdivisions of a routing key range of values. They are used with a partitioned data model and RTR data content routing. Partitions exist for each distinct range of values in the routing key for which a server is available to process transactions.
Page 42: Partition Naming
Partition Management 3.2 Partition Naming 3.2 Partition Naming A prerequisite for partition management is the ability to identify a partition in the system that is to be the subject of management commands. For this purpose, partitions have been given names, which may be drawn from a number of sources described below.
Page 43: Implicit Partition Creation
3.3.1 Implicit Partition Creation Partitions are created implicitly when an application program calls rtr_open_channel( ) and value ranges for the segments with the attributes are established with the the only way in which partitions could be created. Partitions created in this way are automatically deleted when the last server channel to the partition is closed.
Page 44: Entering Partition Commands
Partition Management 3.5 Entering Partition Commands 3.5 Entering Partition Commands Partitions can be managed by issuing partition commands directed at the required partition after they are created. Partition commands can be entered in one of two ways: • A command line processed by the RTR command line interface, for example RTR>...
Page 45: Managing Partitions
rtr_set_info( ) successful, completion will be signaled by the delivery of an RTR message of type rtr_mt_closed argument. The programmer should retrieve this message by pchannel using rtr_receive_message( ) rtr_status_data_t accessed as the status ﬁeld of the message data. 3.6 Managing Partitions To manage partitions a set of commands or program calls are used.
Page 46: Controlling Transaction Presentation
Partition Management 3.6 Managing Partitions 3.6.2 Controlling Transaction Presentation Transaction presentation is the process of passing transactions to idle server channels for processing. While transaction presentation is active, new transactions are started on the ﬁrst free server channel for the appropriate partition.
Page 47: Command Line Example
If a partition enters a wait state or fails but has neither a local or remote journal, an operator can instruct RTR to skip the current step in the recovery process with the /IGNORE_RECOVERY recovery cycle use it with caution in cases where availability above consistency in application databases is desired.
Page 48: Programming Information
Partition Management 3.6 Managing Partitions 3.6.4.2 Programming Information To set the partition backend priority list, program the of the rtr_set_info( ) rtr_qualifier_value_t char *szNodeList = "your,list,of,node,names,here" set_qualifiers[ 0 ].qv_qualifier = rtr_partition_be_priority_list; set_qualifiers[ 0 ].qv_value = &szNodeList; set_qualifiers[ 1 ].qv_qualifier = rtr_qualifiers_end; set_qualifiers[ 1 ].qv_value = NULL;...
Page 49: Controlling Transaction Replay
• rtr_partition_fail_to_shadow • rtr_partition_pre32_compatible 3.6.6 Controlling Transaction Replay RTR has implemented the capability of controlling transaction replay in cases where a "killer message" happens during a transaction replay preventing recovery from continuing normally. A "killer message" presents a situation where server availability is lost because of the presence of a message capable of causing repeated server application failure during recovery.
Page 50: Displaying Partition Information
Partition Management 3.7 Displaying Partition Information 3.7 Displaying Partition Information Information on the deﬁnition and state of a partition is displayed with the SHOW PARTITION command. The information of interest in the context of partition management relates to the backend instance of the partition. For more information see the SHOW PARTITION command in Chapter 6.
Page 51: Transaction Management
4.1 Overview This section describes the concepts of RTR’s transaction management capability. The RTR transaction is the heart of an RTR application, and transaction state is the property that characterizes a transaction’s current condition. Whenever a transaction progresses from one stage to another, the transaction state is updated to reﬂect a transaction transition.
Page 52: Command Line Examples
Transaction Management 4.1 Overview this transaction is removed from memory and can no longer be monitored by the command. The RTR DUMP JOURNAL transaction. The RTR journal saves all of the information about a transaction, its transaction journal state, the transaction messages (records) received from the RTR client, and the content of a message sent to the server.
Page 53: Transaction State Changes
4.1.2 Transaction State Changes There are eight valid state changes allowed for the Attempting to change transaction state to a state that is not allowed produces an error message of state to the specified state changes. Table 4–19 Valid Transaction State Transitions Current State COMMIT SENDING...
Page 54 Transaction Management 4.1 Overview This is the case where, for example, a server crashed while performing an SQL commit immediately after receiving a transaction is in COMMIT state as recorded in the RTR journal and the transaction is also committed in the underlying database. After the SET TRANSACTION be used to verify the result.
Page 55: Rtr Monitoring
This chapter contains a description of the RTR monitor. The RTR monitor gives you a means of viewing the activities of RTR and your applications. Many different aspects of RTR’s behaviour can be viewed, allowing the activities and performance of RTR to be analyzed. 5.1 Introduction The RTR monitor provides a means to continuously display the status of RTR and the applications using it.
Page 56 RTR Monitoring 5.2 Standard Monitor Pictures Obsolete monitor pictures have been removed from the documentation. Table 5–1 Standard Monitor Pictures Picture name Description accfail Shows link transport name for links on which a connection attempt was declined, with a reason for failure. The most recent entry is highlighted. acp2app Displays counts of messages and number of bytes from RTRACP to the application, as viewed from a speciﬁc node.
Page 57 Table 5–1 (Cont.) Standard Monitor Pictures Picture name Description jcalls Displays counts of successful (success), failed (fail) and total journal calls for local and remote journals. journal Displays the current journal usage on a node. Local node journal statistics are provided, and data for non-local journals accessed from the local node.
Page 58: Monitor Accfail (Link Acceptance Failures)
RTR Monitoring 5.2 Standard Monitor Pictures Table 5–1 (Cont.) Standard Monitor Pictures Picture name Description trafﬁc Displays a list of the links to other nodes. Shown for each link are: byte rate, packet rate, message rate and congestion, in both directions. Average packets per second is also shown.
Page 59: Monitor Acp2App
your domain name, depending on how the name is entered in either your local hosts ﬁle or name server. DECnet-Plus systems may yield both a pseudonym and a link name; both are checked for a match with a template. • RTR_STS_FACNOTDEC - "facility name not matched"...
Page 60: Monitor Active
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.3 Monitor Active ACTIVE TRANSACTIONS BY PROCESS Fri Mar 12 1999 19:32:41 All processes: Node NodeA 11141 Displays a list of RTR processes, and for each process the number of transactions they have started, the number of transactions they have completed and the number of transactions still active.
Page 61: Monitor Calls
5.2.6 Monitor Calls RTR api calls, Node: nodea.zuo.dec.com , PID: 2162 Image: -ALL- CALLS open_channel close_channel start_tx send_to_server reply_to_client prepare_tx accept_tx reject_tx broadcast_event set_user_handle get_tid request_info set_info error_text set_wakeup receive_message user wakeup Displays the total number of RTR API calls and their outcome for the processes on all the nodes being monitored.
Page 62: Monitor Event
RTR Monitoring 5.2 Standard Monitor Pictures Displays the link protocol for connected links, and the fail reason as a text message for any links on which a connection has failed. Unconnected links where connection have been attempted are highlighted. Link state and architecture of the remote node are also displayed.
Page 63: Monitor Flow
5.2.11 Monitor Flow FLOW CONTROL COUNTERS 7-JAN-1999 14:08:06, NODE: -ALL- , FACILITY: -ALL- CREDIT ROLE AVAILABLE FE=>TR 15000 TR=>BE 15000 BE=>TR TR=>FE 15000 LINK DATA RATE NODEA =>NODEA NODEA =>NODEB NODEB =>NODEB NODEB =>NODEA Displays the ﬂow control internals. 5.2.12 Monitor Group % rtr monitor group Concurrency Measures krid...
Page 64: Monitor Ipc
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.13 Monitor IPC RTR> Monitor IPC Node: LENGTH +----------------------------------------------------------------------------+ This screen displays usage information on IPC messages, byte counts and IO primitives. Display units are counts, kbytes and calls respectively. +----------------------------------------------------------------------------+ | - - - - - O u t g o i n g / s - - - - | - - I n c o m i n g / s - -| Process Messages ...kbytes rtracp...
Page 65: Monitor Link
Displays information about journal usage, including total number of entries and records written, number of records read, and how many bytes were involved. Bar graphs showing current usage of journal blocks (as a percentage of the total) are also provided. The local journal ﬁgures refer to journal usage for the displayed node.
Page 66: Monitor Netstat
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.18 Monitor Netstat C o n n e c t i o n Node: NODEA Ini Cnf Acc Abo Rej Loss Gain Ctmo Rstr State Type FailCode Node Link NODEA ->nodeb NODEA ->nodec NODEA ->noded NODEA ->nodee Displays the link status for connected links in detail and the fail code for any links on which a connection has failed.
Page 67: Monitor Queues
Table 5–3 (Cont.) Monitor Partition States State active pri_act sec_act remember 5.2.20 Monitor Queues TRANSACTION QUEUES BY PARTITION 15-JAN-1999 12:42:53, NODE: NODEA Partition-name NODEA$NODEB$16842753 Shows transaction queues on a partition basis. Uses counters from Transaction Manager (TM) and the Requester/Server conﬁgurator (RSC). 5.2.21 Monitor Quorum QUORUM STATUS BY NODE AND FACILITY Tue Apr 6 1999 10:50:24, NODE: NODEA (node/role counts can be inaccurate for incorrectly configured facilities)
Page 68: Monitor Rejects
RTR Monitoring 5.2 Standard Monitor Pictures Server recovery state meanings are shown in Table 5–4. Table 5–4 Monitor Recovery States State wt_tr_ok wt_quorum lcl_rec lcl_rec_fail lcl_rec_icpl lcl_rec_cpl shd_rec shd_rec_fail shd_rec_icpl shd_rec_cpl catchup standby active pri_act sec_act remember 5.2.23 Monitor Rejects NODE: NODEA Time -------------------...
Page 69: Monitor Rejhist
5.2.24 Monitor Rejhist NODE: NODEA Time ------------------- Mon Mar 15 18:06:06 Mon Mar 15 18:06:41 Mon Mar 15 18:06:41 ------------------------------------------------------------------------------- Displays the last ten This picture should always be invoked with the /ID qualiﬁer. The transaction identiﬁer associated with the rejected transaction can be displayed with the SHOW PROCESS <...
Page 70: Monitor Rolequorum
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.26 Monitor Rolequorum QUORUM COUNTS BY FACILITY 7-JAN-1999 14:32:48, NODE: -ALL- Router View of backends CNF RCH QRT CNF RCH QRT CNF RCH QRT CNF RCH QRT 5.2.27 Monitor Routers ROUTER TRANSACTION COUNTERS AT 14:33:29 7-JAN-1999 Node: -ALL- Facility: -ALL-...
Page 71: Monitor Rscbe
5.2.29 Monitor RSCBE RTR> Monitor rscbe Most Recent RSC Dclsrv Calls History on Backend LENGTH Thu Mar 4 1999,15:19:41 Key Range Id: 16777216 Image Name: RTR.EXE T-delta RSC calls 0 send_dcl_to_master sfranc 1 recv_status_ok 1 send_dcl_to_master sfranc 1 recv_status_ok 1 send_dcl_to_master sfranc 1 recv_status_ok 1 send_dcl_to_other 1 recv_status_ok...
Page 72: Monitor Stalls
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.31 Monitor Stalls NETWORK STALLS AT 29-JAN-1999 15:35:03, ON NODE: TR1 Total TR1 -> TR1 TR1 -> FE2 TR1 -> BE1 TR2 -> TR2 TR2 -> BE1 FE1 -> FE1 FE1 -> FE2 FE1 -> BE1 FE2 ->...
Page 73: Monitor System
5.2.32 Monitor System Resource Facility QUORUM states... JOURNAL free space... x Link CONNECTS... Link traffic STALLS... x FLOW control credits... x PARTITION states... x CALL Msg outstanding... Transaction QUEUES... x Transaction REJECTS... x Broadcast EVENT discards... x Displays the state of critical resources within the RTR environment. If a resource has exceeded a predeﬁned threshold, a warning indicator is displayed.
Page 74: Monitor Tps
RTR Monitoring 5.2 Standard Monitor Pictures 5.2.33 Monitor TPS TRANSACTION COMMITS BY PROCESS 14:37:23 7-JAN-1999 Node -ALL- 00000000 -REQUESTERS- -ALL- 00000000 -SERVERS- NODEA 20200BEA RTRACP NODEA 20200C03 ANDERS_1 NODEB 21400724 RTRACP NODEB 214005F0 ANDERS_1 Same as TOPTPS except that a given process is always displayed at the same position on the screen, that is, the list is not sorted by TPS.
Page 75: Monitor V2Calls
5.2.36 Monitor V2CALLS RTR> Monitor V2CALLS RTR system service calls, Node: NODEA , PID: 00000000, Process name: -ALL- Image: -ALL- dcl_tx_prc/server dcl_tx_prc/req. dcl_tx_prc/shut. start_tx start_tx /timeout enq_tx enq_tx /broadcast enq_tx /reply deq_tx deq_tx /reply commit_tx abort_tx vote_tx /commit vote_tx /abort vote_tx /forget Displays RTR Version 2 calls when running RTR Version 2 or mixture of RTR Version 3 and 2 environment.
Page 77: Rtr Command Line Interface
Each RTR API call can be invoked This is provided to facilitate testing. For example, clients may be tested before the corresponding servers have been written by manually entering the server’s API calls. 6.1 Introduction The commands that invoke the RTR API calls are similar to the call names. For example, the rtr_accept_tx( ) CLI-level.
Page 78: Add Facility
ADD FACILITY ADD FACILITY See CREATE FACILITY; ADD FACILITY is retained for compatibility reasons only. 6–2 RTR Command Line Interface...
Page 79: Parameters For Rtr_Accept_Tx
CALL RTR_ACCEPT_TX The CALL RTR_ACCEPT_TX command causes a command server to execute rtr_accept_tx( ) Format CALL RTR_ACCEPT_TX Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /FORGET /INDEPENDENT /NODE[=node-list] /OUTPUT[=ﬁle-spec] /REASON[=reason] Description The CALL RTR_ACCEPT_TX command causes a command server to call the rtr_accept_tx( ) The numeric status returned from the call is then converted to its textual representation and displayed.
Page 80 CALL RTR_ACCEPT_TX Qualiﬁers /CHANNEL_NAME=channel_name /CHANNEL_NAME=RTR$DEFAULT_CHANNEL Speciﬁes the channel for which the operation is to be performed. The command server uses a combination of the channel_name and the window from which the call was issued to uniquely identify which channel to use. channel_name is not case sensitive.
Page 81: Call Rtr_Accept_Tx
Related Commands • CALL RTR_OPEN_CHANNEL • CALL RTR_REJECT_TX Examples Accept the current transaction with a reason of 42. RTR> CALL RTR_ACCEPT_TX /REASON=42 %RTR-S-OK, normal successful completion CALL RTR_ACCEPT_TX RTR Command Line Interface 6–5...
Page 82 CALL RTR_BROADCAST_EVENT CALL RTR_BROADCAST_EVENT The CALL RTR_BROADCAST_EVENT command causes a command server to execute the rtr_broadcast_event( ) Format CALL RTR_BROADCAST_EVENT [message-ﬁeld1] [,message-ﬁeld2...] Parameters [message-ﬁeld1] [,message-ﬁeld2...] Specify the message to be sent (if any) as one or more comma separated parameter values. You can use the /TYPE_OF_DATA and /LENGTH_OF_DATA positional qualiﬁers on each parameter value to specify the data type and length of each ﬁeld.
Page 83: Call Rtr_Broadcast_Event
Table 6–2 Parameters for rtr_broadcast_event C Parameter Name C Parameter Value channel ﬂags RTR_NO_FLAGS pmsg, msglen, msgfmt evtnum rcpspc "workstat*" pmsg msglen The actual values used for command line parameter. The command server uses message data speciﬁed as command line parameter values to generate a record containing the message data (for the the message length (for the parameter).
Page 84: Generated Format Strings
CALL RTR_BROADCAST_EVENT Table 6–3 Generated Format Strings Data Type STRING SIGNED SIGNED SIGNED UNSIGNED UNSIGNED UNSIGNED Refer to Application Programmer’s Reference Manual, section ‘‘Deﬁning a Message Format Description’’ for information on constructing a parameter. /LENGTH_OF_FIELD=ﬁeld-length Enter the size of the message ﬁeld that you want to deﬁne. The default for string types is the length of the message entered, plus one (for the zero termination byte).
Page 85 RTR> CALL RTR_BROADCAST_EVENT "Dollar is up"/EVENT_NUMBER=23 %RTR-S-OK, Normal successful completion The following command broadcasts user event number 24 to all recipients whose /RECIPIENT_NAME matches the DEALER% string (that is, DEALER1, DEALER2, DEALERx). Note that only the event is broadcast, there is no associated message.
Page 86: Call Rtr_Close_Channel
CALL RTR_CLOSE_CHANNEL CALL RTR_CLOSE_CHANNEL The CALL RTR_CLOSE_CHANNEL command causes a command server to execute the rtr_close_channel( ) Format CALL RTR_CLOSE_CHANNEL Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /IMMEDIATE /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description The CALL RTR_CLOSE_CHANNEL command causes a command server to call rtr_close_channel( ) The numeric status returned from the call is then converted to its textual representation and displayed.
Page 87: Call Rtr_Close_Channel
/CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued. Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only.
Page 88: Call Rtr_Error_Text
CALL RTR_ERROR_TEXT CALL RTR_ERROR_TEXT The CALL RTR_ERROR_TEXT command causes a command server to execute rtr_error_text( ) Format CALL RTR_ERROR_TEXT Command Qualiﬁers /OUTPUT[=ﬁle-spec] /STATUS=status-code Description The CALL RTR_ERROR_TEXT command causes a command server to call the rtr_error_text( ) rtr_error_text( ) Reference Manual. The prototype of char Table 6–5 shows the correspondence between values you supply on the command...
Page 89: Call Rtr_Get_Tid
CALL RTR_GET_TID The CALL RTR_GET_TID command causes a command server to execute the rtr_get_tid( ) routine and to display the returned status. Format CALL RTR_GET_TID Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description The CALL RTR_GET_TID command causes a command server to call to the rtr_get_tid( ) routine using values supplied on the command line.
Page 90: Call Rtr_Get_Tid
CALL RTR_GET_TID If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued. Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only.
Page 91 CALL RTR_OPEN_CHANNEL The CALL RTR_OPEN_CHANNEL command causes a command server to execute the rtr_open_channel( ) Format CALL RTR_OPEN_CHANNEL Command Qualiﬁers /ACCEPT_EXPLICIT /ACCESS=access /BE_CALL_OUT /CHANNEL_NAME=channel-name /CLIENT /CLUSTER /CONCURRENT /EVENTS[=event-nr-list] /FACILITY_NAME[=facility-name] /FOREIGN_TM[=tm_id] /HIGH_BOUND=high-bound /KEY1=keysegdesc /KEYn=keysegdesc /LENGTH_OF_FIELD=key-ﬁeld-length /LENGTH_OF_FIELD=4 /LOW_BOUND=low-bound /NODE[=node-list] /OFFSET_OF_KEY=offset /OUTPUT[=ﬁle-spec] /PARTITION_NAME=partition-name /PREPARE_EXPLICIT /RECIPIENT_NAME=rcpnam /SERVER...
Page 92: Parameters For Rtr_Open_Channel
CALL RTR_OPEN_CHANNEL rtr_status_t Table 6–7 shows the correspondence between values you supply on the command line and the C language parameter values produced and used for the call. Table 6–7 Parameters for rtr_open_channel C Parameter Name C Parameter Value channel ﬂags RTR_NO_FLAGS RTR_F_OPE_CLIENT...
Page 93 /ACCESS=access /NOACCESS (D) Speciﬁes an access string (that is, a password). All application programs (clients and servers) must specify the same access string for a given facility. /BE_CALL_OUT /NOBE_CALL_OUT (D) Speciﬁes that the RTR_F_OPE_BE_CALL_OUT ﬂag is set in the in the call to rtr_open_channel( ) server.
Page 94: Call Rtr_Open_Channel
CALL RTR_OPEN_CHANNEL /FACILITY_NAME=facility-name /FACILITY=RTR$DEFAULT_FACILITY (D) Speciﬁes the name of the facility for which the channel is declared. An application must specify the facility name when using the RTR CLI. The default facility name is RTR$DEFAULT_FACILITY. /FOREIGN_TM[=tm_id] /NOFOREIGN_TM (D) Valid for client channels only. This indicates that the global coordinating Transaction Manager (TM) is a Foreign TM (denoted as FTM), and that all TXs on this channel will be coordinated by the FTM.
Page 95 Speciﬁes the length of the key ﬁeld in enqueued messages in length_of_key=nnnn bytes. Use this qualiﬁer only if the key ﬁeld type is string, since the key length is in other cases implied by the key type. The default value for bytes.
Page 96 CALL RTR_OPEN_CHANNEL /OFFSET_OF_KEY=offset /OFFSET_OF_KEY=0 (D) Speciﬁes the offset of the key within the messages in bytes. The default is zero, that is, the key is at the start of the messages. Note that only one key segment deﬁnition is allowed. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle...
Page 97 /TYPE_OF_FIELD=key-ﬁeld-type /TYPE_OF_FIELD=UNSIGNED (D) Speciﬁes the ﬁeld type of the key. The SIGNED or STRING. The default is UNSIGNED. Related Commands • CALL RTR_CLOSE_CHANNEL Examples This command opens a server channel called RTR$DEFAULT_CHANNEL that may not have concurrent servers, explicitly accepts transactions and listens for all RTR events.
Page 98: Call Rtr_Prepare_Tx
CALL RTR_PREPARE_TX CALL RTR_PREPARE_TX The CALL RTR_PREPARE_TX command causes a command server to execute rtr_prepare_tx( ) Format CALL RTR_PREPARE_TX Command Qualiﬁers /CHANNEL_NAME=channel-name /DATA[=data] /NODE[=node-list] /OUTPUT[=ﬁle-spec] /REASON[=reason] Description The CALL RTR_PREPARE_TX command causes a command server to call the rtr_prepare_tx( ) The numeric status returned from the call is then converted to its textual representation and displayed.
Page 99 CALL RTR_PREPARE_TX The CALL RTR_PREPARE_TX can only be used in the context of nested transactions (rtr_start_tx was called with the parameter join_txid not equal to NOJOIN_TXID). If this call returns RTR_STS_OK, then the ﬁrst (prepare) phase of the RTR 2PC protocol has been initiated. The message type associated with this command is rtr_mt_prepared .
Page 100 CALL RTR_PREPARE_TX /REASON[=reason] /REASON=0 Use /REASON to supply a value for the rtr_prepare_tx( ) The reason parameter to parameter in the subsequent the call to rtr_accept_tx call( ) rtr_prepare_tx( ) Related commands • CALL RTR_OPEN_CHANNEL • CALL RTR_REJECT_TX Examples Prepare the current transaction with a reason of 42. RTR>...
Page 101: Call Rtr_Receive_Message
CALL RTR_RECEIVE_MESSAGE The CALL RTR_RECEIVE_MESSAGE command causes a command server to execute the rtr_receive_message( ) Format CALL RTR_RECEIVE_MESSAGE Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] /TIMEOUT_MS=timoutms Description The CALL RTR_RECEIVE_MESSAGE command causes a command server to call the rtr_receive_message( ) line. The numeric status returned from the call is then converted to its textual representation and displayed.
Page 102 CALL RTR_RECEIVE_MESSAGE For all messages received, RTR displays the contents of the message status block (msgsb) as follows: the message type (for example, the message length in bytes the transaction ID, user handle, are event number are shown if they are relevant for the message type.
Page 103 /TIMEOUT_MS=timoutms /TIMEOUT_MS=0 (D) The timoutms argument deﬁnes a timeout for the receive, in milliseconds. The default value is an inﬁnite timeout. /TIMEOUT_MS speciﬁes an immediate timeout. Examples The following example shows two CALL RTR_RECEIVE_MESSAGE commands on RTR$DEFAULT_CHANNEL. RTR> CALL RTR_RECEIVE_MESSAGE /TIMEOUT_MS %RTR-S-OK, normal successful completion channel name: RTR$DEFAULT_CHANNEL msgsb...
Page 104: Parameters For Rtr_Reject_Tx
CALL RTR_REJECT_TX CALL RTR_REJECT_TX The CALL RTR_REJECT_TX command causes a command server to execute rtr_reject_tx( ) Format CALL RTR_REJECT_TX Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] /REASON[=rsnsts] /RETRY Description The CALL RTR_REJECT_TX command causes a command server to call the rtr_reject_tx( ) The numeric status returned from the call is then converted to its textual representation and displayed.
Page 105 is not case sensitive. channel_name The default channel name is RTR$DEFAULT_CHANNEL. /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued.
Page 106: Call Rtr_Reject_Tx
CALL RTR_REJECT_TX Examples Reject the current transaction with a reason of 42. RTR> CALL RTR_REJECT_TX /REASON=42 %RTR-S-OK, normal successful completion 6–30 RTR Command Line Interface...
Page 107: Call Rtr_Reply_To_Client
CALL RTR_REPLY_TO_CLIENT The CALL RTR_REPLY_TO_CLIENT command causes a command server to execute the rtr_reply_to_client( ) Format CALL RTR_REPLY_TO_CLIENT [message-ﬁeld1] [,message-ﬁeld2...] Parameters [message-ﬁeld1] [,message-ﬁeld2...] Specify the message to be sent as one or more comma separated parameter values. You can use the /TYPE_OF_DATA and /LENGTH_OF_DATA positional qualiﬁers on each parameter value to specify the data type and length of each ﬁeld.
Page 108: Parameters For Rtr_Reply_To_Client
CALL RTR_REPLY_TO_CLIENT Table 6–11 Parameters for rtr_reply_to_client C Parameter Name C Parameter Value channel ﬂags RTR_NO_FLAGS RTR_F_REP_ACCEPT pmsg, msglen, msgfmt pmsg msglen The actual values used for command line parameter. The command server uses message data speciﬁed as command line parameter values to generate a record containing the message data (for the the message length (for the msgfmt...
Page 109: Generated Format Strings
Table 6–12 Generated Format Strings Data Type STRING SIGNED SIGNED SIGNED UNSIGNED UNSIGNED UNSIGNED Refer to Application Programmer’s Reference Manual, section ‘‘Deﬁning a Message Format Description’’ for information on constructing a parameter. /INDEPENDENT NOINDEPENDENT Use the /INDEPENDENT qualiﬁer to specify the ﬂags parameter RTR_F_ACC_ INDEPENDENT in the call to rtr_reply_to_client( ).
Page 110 CALL RTR_REPLY_TO_CLIENT Examples The following example replies a message to the client. RTR> CALL RTR_REPLY_TO_CLIENT "Getting that info for you" %RTR-S-OK, Normal successful completion The following example shows a message of type unsigned and entered as a hexadecimal number. RTR> CALL RTR_REPLY_TO_CLIENT "0xFA9BC0"/TYPE_OF_DATA=UNSIGNED %RTR-S-OK, Normal successful completion 6–34 RTR Command Line Interface...
Page 111: Call Rtr_Request_Info
CALL RTR_REQUEST_INFO The CALL RTR_REQUEST_INFO command causes a command server to execute the rtr_request_info( ) Format CALL RTR_REQUEST_INFO Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /GETITM=item-name /INFCLA=infoclass /NODE[=node-list] /OUTPUT[=ﬁle-spec] /SELITM=item-name /SELVAL=item-value Description The CALL RTR_REQUEST_INFO command causes a command server to call to rtr_request_info( ) rtr_request_info( ) Reference Manual.
Page 112 CALL RTR_REQUEST_INFO Qualiﬁers /CHANNEL_NAME=channel_name /CHANNEL_NAME=RTR$DEFAULT_CHANNEL Speciﬁes the channel for which the operation is to be performed. The command server uses a combination of the channel_name and the window from which the call was issued to uniquely identify which channel to use. channel_name is not case sensitive.
Page 113 Examples This command requests the backend transaction IDs for the facility ‘‘CASHFAC’’. RTR> CALL RTR_REQUEST_INFO/CHANNEL=INFOCHAN /INFCLA="btx"/SELITM=fac_id/SELVAL=CASHFAC /GETITMS=tb_txdx.tx_id The information can then be viewed by repeatedly executing the following command until the channel is closed. RTR> CALL RTR_RECEIVE_MESSAGE/CHANNEL=INFOCHAN/TIMEOUT CALL RTR_REQUEST_INFO RTR Command Line Interface 6–37...
Page 114 CALL RTR_SEND_TO_SERVER CALL RTR_SEND_TO_SERVER The CALL RTR_SEND_TO_SERVER command causes a command server to execute the rtr_send_to_server( ) Format CALL RTR_SEND_TO_SERVER [message-ﬁeld1] [,message-ﬁeld2...] Parameters [message-ﬁeld] [,message-ﬁeld2...] Specify the message to be sent as one or more comma separated parameter values. You can use the /TYPE_OF_DATA and /LENGTH_OF_DATA positional qualiﬁers on each parameter value to specify the data type and length of each ﬁeld.
Page 115: Parameters For Rtr_Send_To_Server
Table 6–14 Parameters for rtr_send_to_server C Parameter Name C Parameter Value channel ﬂags RTR_NO_FLAGS RTR_F_SEN_EXPENDABLE RTR_F_SEN_READONLY RTR_F_SEN_RETURN_TO_SENDER pmsg, msglen, msgfmt pmsg msglen The actual values used for command line parameter. The command server uses message data speciﬁed as command line parameter values to generate a record containing the message data (for the the message length (for the parameter).
Page 116: Call Rtr_Send_To_Server
CALL RTR_SEND_TO_SERVER If /FORMAT is speciﬁed without format string. The format string is generated using the parameters given for the qualiﬁers /SIGNED, /UNSIGNED, /STRING and /LENGTH. The following table shows permitted values for these qualiﬁers when using /FORMAT without fmt-string Table 6–15 Generated Format Strings Data Type STRING...
Page 117 CALL RTR_SEND_TO_SERVER Examples This command sends a message to a server. The message is type string (the default). RTR> CALL RTR_SEND_TO_SERVER "Get that info for me, please" %RTR-S-OK, Normal successful completion RTR Command Line Interface 6–41...
Page 118: Call Rtr_Start_Tx
CALL RTR_START_TX CALL RTR_START_TX The CALL RTR_START_TX command causes a command server to execute the rtr_start_tx( ) Format CALL RTR_START_TX Command Qualiﬁers /CHANNEL_NAME=channel-name /CLUSTER /JOIN_TXID=txid-number /NODE[=node-list] /OUTPUT[=ﬁle-spec] /TIMEOUT_MS=timoutms /TXID_TYPE=txid-type Description The CALL RTR_START_TX command causes a command server to call the rtr_start_tx( ) The numeric status returned from the call is then converted to its textual representation and displayed.
Page 119: Call Rtr_Start_Tx
phase cannot be executed on an client FTM channel, may be relaxed in a future release.) When a nested transaction is started (join_txid not equal to NOJOIN_ TXID), then that transaction is given a new RTR TXID (which the operator can retrieve by calling rtr_get_tid). The foreign TXID passed in join_txid is used only to identify the transaction for the foreign TM (for example, when the foreign TM goes through recovery and requests RTR to return all transactions in prepared state).
Page 120 CALL RTR_START_TX /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec /TIMEOUT_MS=timoutms /TIMEOUT_MS=0 (D) The timoutms argument deﬁnes a timeout for the transaction, in milliseconds. The default value is an inﬁnite timeout. /TIMEOUT_MS speciﬁes an immediate timeout (timeout if no message to receive).
Page 121: Clear
CLEAR Interactively remove one or more displayed items from a monitor picture. Format CLEAR Command Qualiﬁers /ALL /X=column /Y=row Description CLEAR command enables you to interactively remove one or all of the displayed items from a monitor picture. The picture can then be redisplayed using the MONITOR /RESUME CLEAR /ALL...
Page 122 CLEAR Examples See Section A.1, Interactive Deﬁnition of a Monitor Picture, for an example of how to use the CLEAR 6–46 RTR Command Line Interface command.
Page 123: Create Facility
CREATE FACILITY Create an RTR facility and ready it for transaction trafﬁc. Format CREATE FACILITY Command Qualiﬁers /ALL_ROLES=node-list /BACKEND=backend-list /BALANCE /CALL_OUT=role-list /CLUSTER /FRONTEND=frontend-list /NODE[=node-list] /OUTPUT[=ﬁle-spec] /REPLY_CHECKSUM /RESOURCE_MANAGER=resource-list /ROUTER=router-list Description CREATE FACILITY and readies it for transaction trafﬁc (that is, establishes links to other the participating nodes).
Page 124 CREATE FACILITY Qualiﬁers /ALL_ROLES=node-list /NOALL_ROLES (D) Speciﬁes the names of the nodes that are to act as frontend, router in this facility. Note that the deﬁnition order of nodes may be signiﬁcant. This applies to the order of router node deﬁnitions when frontend load balancing is not enabled. Nodes deﬁned with the /ROUTER qualiﬁer have the higher priority and are followed by nodes deﬁned by the /ALL_ROLES qualiﬁer.
Page 125 Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only. /FRONTEND=frontend-list /NOFRONTEND (D) is a list of Frontend-list than one frontend-node Frontend-node is either the name of a node or speciﬁes a text ﬁle containing a /NODE[=node-list] /NODE=default-node-list (D)
Page 126 CREATE FACILITY Examples See Chapter 2, Starting and Setting Up RTR, for examples of how to use the CREATE FACILITY 6–50 RTR Command Line Interface command.
Page 127: Create Journal
CREATE JOURNAL Create RTR’s recovery journal. Format CREATE JOURNAL [disk-1] ... [,disk-n] Command Qualiﬁers /CLUSTER /BLOCKS=nr-blocks /MAXIMUM_BLOCKS=nr-blocks /NODE=node-list /OUTPUT[=ﬁle-spec] /SUPERSEDE Description The CREATE JOURNAL command creates RTR’s recovery journal ﬁles on the speciﬁed disks. The target size of the ﬁles is speciﬁed using the /BLOCKS qualiﬁer (512 byte blocks).
Page 128: Platform Speciﬁc Information
CREATE JOURNAL Table 6–17 Platform Speciﬁc Information Platform Journal Root UNIX /rtrjnl OpenVMS [RTRJNL] Qualiﬁers /BLOCKS[=nr-blocks] /BLOCKS=1000 (D) Speciﬁes the target size of the journal ﬁle in 512 byte blocks. This qualiﬁer can be applied locally to each disk or globally for all disks. /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster.
Page 129 If /NOSUPERSEDE is speciﬁed (default), then a journal is created only if no journal previously existed. Related commands • DELETE JOURNAL • MODIFY JOURNAL • SHOW JOURNAL Examples RTR> CREATE JOURNAL /SUPERSEDE DISK1$:/BLOCK=1000/MAX_BLOCK=10000, - _RTR> DISK2$:/BLOCK=2000/MAX_BLOCK=200000 This command deletes any existing journal ﬁles and then creates new ones on DISK1$ and DISK2$.
Page 130: Create Partition
CREATE PARTITION CREATE PARTITION Creates an RTR partition. Format CREATE PARTITION Command Qualiﬁers /CLUSTER /CONCURRENT /FACILITY=facility-name /NODE[=node-list] /OUTPUT[=ﬁle-spec] /STANDBY /SHADOW /KEY1=keysegdesc /KEYn=keysegdesc Description CREATE PARTITION characteristics that may be deﬁned include key range or ranges and whether attached server processes can be shadows or standbys. The command must be issued before any server application programs using the partition are started.
Page 131 /CONCURRENT (D) /NOCONCURRENT Speciﬁes that concurrent servers are allowed for this partition. /KEYn=keysegdesc Speciﬁes a partition key segment. Up to nine key segments may be deﬁned for a partition (KEY1, KEY2,... up to KEY9). (If more than nine key segements are required, a named partiton can be created using the The syntax of the KEYn qualiﬁer is: /KEYn= (type_of_key=[signed|unsigned|string], -...
Page 132 CREATE PARTITION /STANDBY (D) /NOSTANDBY Speciﬁes that standby servers are allowed for this partition. /SHADOW /NOSHADOW (D) Speciﬁes that shadow servers are allowed for this partition. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Related Commands •...
Page 133: Define /Key
DEFINE /KEY Assign a string to a keyboard function key. Format DEFINE /KEY key-name "equivalence-string" Command Qualiﬁers /ECHO /IF_STATE /LOCK_STATE /LOG /SET_STATE /TERMINATE Description This command lets you assign a string to a function key, possibly overriding any predeﬁned function that was bound to that key. When you then press the key, the RTR Utility enters the currently associated string into your command line.
Page 134 DEFINE /KEY Table 6–18 (Cont.) Key names Key-name KP0, KP1 ..KP9 PERIOD COMMA MINUS ENTER HELP F6, F7, .. F20 equivalence-string Speciﬁes the string to be processed when the speciﬁed key is pressed. Typically, this is all or part of an RTR command. If the string contains spaces or non-alphanumeric characters, it must be enclosed in quotation marks.
Page 135 /LOG /NOLOG (D) Controls whether a message is displayed indicating that the key deﬁnition has been successfully created. /SET_STATE=state-name /NOSETSTATE (D) Controls whether pressing the key changes the current key state. changes the current state to (the default) causes the current state to remain in effect. /TERMINATE /NOTERMINATE (D) Controls whether the speciﬁed string is to be terminated (processed) when the...
Page 136 DEFINE /KEY The word DEFAULT in the second line of the example refers to the fact that has been deﬁned in the default state. Note the space before the word CREATE in the second DEFINE /KEY command. If the space is omitted, the system fails to recognize CREATE as the keyword for the HELP command.
Page 137: Delete Facility
DELETE FACILITY Delete an RTR facility. Format DELETE FACILITY Command Qualiﬁers /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] Description DELETE FACILITY the command is issued. After issuing this command applications are able to use the facility. Any outstanding transactions using the facility are aborted. Parameters facility_name The name of the facility to delete.
Page 138 DELETE FACILITY Related Commands • CREATE FACILITY • SHOW FACILITY Examples See Chapter 2, Starting and Setting Up RTR, for examples of how to use the DELETE FACILITY 6–62 RTR Command Line Interface command.
Page 139: Delete Journal
DELETE JOURNAL Delete an RTR journal. Format DELETE JOURNAL Command Qualiﬁers /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] Description DELETE JOURNAL node where the command is issued. DELETE JOURNAL has been created but is currently in use. The command causes the previous contents of the journal, if any, to be destroyed. Qualiﬁers /CLUSTER /NOCLUSTER (D)
Page 140 DELETE JOURNAL Examples See Chapter 2, Starting and Setting Up RTR, for examples of how to use the command. DELETE JOURNAL 6–64 RTR Command Line Interface...
Page 141: Delete Partition
DELETE PARTITION Delete an RTR PARTITION. Format DELETE PARTITION Command Qualiﬁers /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] /FACILITY Description DELETE PARTITION where the command is issued. Parameters PARTITION_name The name of the partition to delete. The parameter partition_name <or as partition_name Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster.
Page 142 DELETE PARTITION Related Commands • CREATE PARTITION • SHOW PARTITION 6–66 RTR Command Line Interface...
Page 143: Display Bar
DISPLAY BAR Display a bar-graph in a monitor picture. Format DISPLAY BAR expression Command Qualiﬁers /AVERAGE=(keyword,...) /BELL=Boolean-expression /BLANK=Boolean-expression /BLINK=Boolean-expression /BOLD=Boolean-expression /CHARACTER=char /DAMPING=damping-factor /LABEL=text /LENGTH=nr-chars /MAXIMUM=max-value /MINIMUM=min-value /RATE=interval /REVERSE=Boolean-expression /ROWS=nr-rows /SELECT=Boolean-expression /SEPARATE=(keyword,...) /TOTALIZE=(keyword,...) /UNDERLINE=Boolean-expression /VALUE=value-type /X=column /Y=row Description DISPLAY BAR picture. It can be used within a monitor ﬁle or issued at the interactively deﬁning a monitor picture for use in a subsequent MONITOR command.
Page 144 DISPLAY BAR Qualiﬁers /AVERAGE=(keyword,...) /NOAVERAGE Speciﬁes that the items being monitored relating to average. This allows a number of items to be averaged in one qualiﬁer. can be one of the following: keyword Keyword NODE LINK FACILITY PROCESS PARTITION FE_TRANSACTION TR_TRANSACTION BE_TRANSACTION /BELL[=Boolean-expression]...
Page 145 /LABEL=text /NOLABEL (D) Speciﬁes the text used to label the value being displayed. Symbols are substituted at display time. (See Section A.2, Substitution Symbols). /LENGTH[=nr-chars] /LENGTH=50 (D) Speciﬁes the number of characters in a bar chart representing the maximum value. The default is 50. /MAXIMUM[=max-value] /MAXIMUM=10 (D) Speciﬁes the maximum value represented on a bar chart.
Page 146 DISPLAY BAR Keyword PROCESS PARTITION FE_TRANSACTION TR_TRANSACTION BE_TRANSACTION /TOTALIZE=(keyword,...) /NOTOTALIZE Speciﬁes that the items being monitored relating to and displayed as a total. can be one of the following: keyword Keyword NODE LINK FACILITY PROCESS PARTITION FE_TRANSACTION TR_TRANSACTION BE_TRANSACTION /UNDERLINE[=Boolean-expression] /NOUNDERLINE (D) Speciﬁes that the displayed value is underlined if to True (non-zero).
Page 147 /X=previous-column (D) Speciﬁes the screen column where the item is displayed (the leftmost column is 1). By default, items are displayed in the same column as deﬁned by the previous DISPLAY command. /Y[=row] /Y=next-free-row (D) Speciﬁes the screen row where the item is displayed (top row is 1). By default, items are displayed on the next free row after the item deﬁned by the previous DISPLAY command.
Page 148: Display Numeric
DISPLAY NUMERIC DISPLAY NUMERIC Display a number in a monitor picture. Format DISPLAY NUMERIC Command Qualiﬁers /AVERAGE=(keyword,...) /BELL=Boolean-expression /BLANK=Boolean-expression /BLINK=Boolean-expression /BOLD=Boolean-expression /DAMPING=damping-factor /DECIMALS=decimal-places /LABEL=text /RATE=interval /REVERSE=Boolean-expression /ROWS=nr-rows /SELECT=Boolean-expression /SEPARATE=(keyword,...) /TOTALIZE=(keyword,...) /UNDERLINE=Boolean-expression /VALUE=value-type /WIDTH=ﬁeld-width /X=column /Y=row Description DISPLAY NUMERIC in a monitor picture. It can be used within a monitor ﬁle or issued at the prompt when interactively deﬁning a monitor picture for use in a subsequent MONITOR command.
Page 149 can be one of the following: keyword Keyword Meaning NODE Node data items LINK Link data items FACILITY Facility data items PROCESS Process data items PARTITION Partition data items FE_TRANSACTION Frontend transaction data items TR_TRANSACTION Backend transaction data items BE_TRANSACTION Router transaction data items /BELL[=Boolean-expression] /NOBELL (D)
Page 150 DISPLAY NUMERIC /RATE[=interval] /NORATE (D) Speciﬁes that the rate of change of the the absolute value. When seconds used to calculate the rate of change. This has no effect on the sampling, it simply allows the rate to be displayed in another unit. For example, displaying the start transaction counter with being displayed instead of per second.
Page 151 Keyword Meaning LINK Link data items FACILITY Facility data items PROCESS Process data items PARTITION Partition data items FE_TRANSACTION Frontend transaction data items TR_TRANSACTION Backend transaction data items BE_TRANSACTION Router transaction data items /UNDERLINE[=Boolean-expression] /NOUNDERLINE (D) Speciﬁes that the displayed value is underlined if to True (non-zero).
Page 152 DISPLAY NUMERIC Related Commands • MONITOR • SHOW DISPLAY • CLEAR • DISPLAY BAR • DISPLAY SYMBOLIC • DISPLAY TEXT Examples See Section A.1 for examples of how to use the 6–76 RTR Command Line Interface command. DISPLAY NUMERIC...
Page 153: Display String
DISPLAY STRING Display a string in a monitor picture. Format DISPLAY STRING expression Command Qualiﬁers /AVERAGE=(keyword,...) /BELL=Boolean-expression /BLANK=Boolean-expression /BLINK=Boolean-expression /BOLD=Boolean-expression /JUSTIFY=keyword /LABEL=text /REVERSE=Boolean-expression /ROWS=nr-rows /SELECT=Boolean-expression /SEPARATE=(keyword,...) /TOTALIZE=(keyword,...) /UNDERLINE=Boolean-expression /WIDTH=ﬁeld-width /X=column /Y=row Description DISPLAY STRING alphanumeric in a monitor picture. It can be used within a monitor ﬁle or issued at the a subsequent MONITOR command.
Page 154 DISPLAY STRING can be one of the following: keyword Keyword NODE LINK FACILITY PROCESS PARTITION FE_TRANSACTION TR_TRANSACTION BE_TRANSACTION /BLANK[=Boolean-expression] /NOBLANK (D) Speciﬁes that the displayed value is replaced by blanks if evaluates to True (non-zero). /BLINK[=Boolean-expression] /NOBLINK (D) Speciﬁes that the displayed value blinks if (non-zero).
Page 155 /SEPARATE=(keyword,...) /NOSEPARATE Speciﬁes that the items being monitored relating to each other and displayed as a list. This allows a number of items to be separated in one qualiﬁer. keyword can be one of the following: Keyword Meaning NODE Node data items LINK Link data items FACILITY...
Page 156 DISPLAY STRING /X[=column] /X=previous-column (D) Speciﬁes the screen column where the item is displayed (the leftmost column is 1). By default, items are displayed in the same column as deﬁned by the previous DISPLAY command. /Y[=row] /Y=next-free-row (D) Speciﬁes the screen row where the item is displayed (top row is 1). By default, items are displayed on the next free row after the item deﬁned by the previous DISPLAY command.
Page 157: Display Symbolic
DISPLAY SYMBOLIC Display a text in a monitor picture depending on the result of an expression evaluation. Format DISPLAY SYMBOLIC Command Qualiﬁers /BELL=Boolean-expression /BLANK=Boolean-expression /BLINK=Boolean-expression /BOLD=Boolean-expression /REVERSE /UNDERLINE=Boolean-expression /X=column /Y=row Description DISPLAY SYMBOLIC the value of expression zero (0), the second string is output if the expression’s value is 1, and so on. If the expression has a value for which there is no corresponding entry in the list of texts, then the value itself is printed.
Page 158 DISPLAY SYMBOLIC /BOLD[=Boolean-expression] /NOBOLD (D) Speciﬁes that the item is displayed in high intensity if evaluates to True (non-zero). /REVERSE[=Boolean-expression] /NOREVERSE (D) Speciﬁes that the item is displayed with the foreground and background visual attributes swapped if /UNDERLINE[=Boolean-expression] /NOUNDERLINE (D) Speciﬁes that the displayed value is underlined if to True (non-zero).
Page 159: Display Text
DISPLAY TEXT Display text in a monitor picture. Format DISPLAY TEXT text Command Qualiﬁers /BELL=Boolean-expression /BLANK=Boolean-expression /BLINK=Boolean-expression /BOLD=Boolean-expression /FACILITY /LINK /NODE /PROCESS /REVERSE=Boolean-expression /SELECT=Boolean-expression /UNDERLINE /X=column /Y=row Description DISPLAY TEXT within a monitor ﬁle or issued at the monitor picture for use in a subsequent MONITOR command. Parameters text Speciﬁes the text to be displayed.
Page 160 DISPLAY TEXT /BOLD[=Boolean-expression] /NOBOLD (D) Speciﬁes that the item is displayed in high intensity if evaluates to True (non-zero). /FACILITY /NOFACILITY (D) Speciﬁes that the symbol substitution in the text is carried out as if a facility data item were being displayed. This means that the link name symbol ($LINK_ NAME) and the process related symbols ($PROCESS_ID, $PROCESS_NAME, $IMAGE_NAME, $FULL_IMAGE_NAME) are always replaced by the text "-ALL-".
Page 161 /UNDERLINE[=Boolean-expression] /NOUNDERLINE (D) Speciﬁes that the displayed value is underlined if to True (non-zero). /X[=column] /X=previous-column (D) Speciﬁes the screen column where the item is displayed (the leftmost column is 1). By default, items are displayed in the same column as deﬁned by the previous DISPLAY command.
Page 162 Execute an operating system command. Format DO [operating-system-command] Command Qualiﬁers /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] Description command enables an operating system command to be executed from RTR. By using the on one or more remote nodes. (Note that the SPAWN command does not have this ability).
Page 163 Example RTR> DO/NODE=(TR2,TR1) "ps" This command displays the processes running on Compaq Tru64 UNIX nodes TR2 and TR1. command can be used if a series of DCL commands are to RTR Command Line Interface 6–87...
Page 164: Flush Name_Cache
FLUSH NAME_CACHE FLUSH NAME_CACHE Flushes RTR’s internal network name cache. Format FLUSH NAME_CACHE Command Qualiﬁers /CLUSTER /NODE[=node-list] Description FLUSH NAME_CACHE internal network name cache. Network links could become unstable if a Distributed Name Service (DNS) was conﬁgured improperly or the service was slow in responding. During extreme DNS latency, RTR could time-out the connections to nodes waiting for a DNS response.
Page 165: Execute
EXECUTE Executes a ﬁle containing RTR commands. Format EXECUTE ﬁle-spec Command Qualiﬁers /VERIFY Description The EXECUTE command reads a ﬁle containing RTR commands and executes them. This command also has the form Parameters ﬁle-spec Speciﬁes the name of the ﬁle containing commands to be executed. Qualiﬁers /VERIFY /NOVERIFY (D)
Page 166: Exit
EXIT EXIT Exits from the RTR prompt. Format EXIT Description The EXIT command exits from the RTR prompt and returns control to the operating system prompt. The command has no parameters or qualiﬁers. Same as QUIT. 6–90 RTR Command Line Interface...
Page 167: Extend Facility
EXTEND FACILITY Adds new nodes or roles or both to an existing facility deﬁnition. Format EXTEND FACILITY Command Qualiﬁers /BACKEND=backend-list /BALANCE /CALL_OUT=role-list /CLUSTER /FRONTEND=frontend-list /NODE[=node-list] /OUTPUT[=ﬁle-spec] /ROUTER=router-list Description EXTEND FACILITY New nodes and roles can be added to a facility deﬁnition using the EXTEND FACILITY command.
Page 168 EXTEND FACILITY $ RTR RTR> SET ENVIRONMENT /NODE=(FE,FETRBE) RTR> CREATE FACILITY facnam /FRONTEND=(FE,FETRBE) - /ROUTER=FETRBE - /BACKEND=FETRBE A new frontend $ RTR RTR> SET ENVIRONMENT /NODE=(FETRBE,NFE) RTR> EXTEND FACILITY facnam /FRONTEND=NFE - /ROUTER=FETRBE Parameters facility_name Speciﬁes the name of the facility to be extended. Any application program which uses this facility must specify the same name when it calls the Facility names can contain up to thirty-one characters.
Page 169 is a list of Backend-list backend-nodes than one backend-node , then backend-list is either the name of a node or Backend-node speciﬁes a ﬁle containing a backend-list /BALANCE /NOBALANCE (D) Speciﬁes that load balancing is enabled for frontend/router connections across the facility.
Page 170 EXTEND FACILITY /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec /ROUTER=router-list /NOROUTER (D) Speciﬁes the names of the added nodes that act as routers for this facility. is a list of Router-list than one router-node If /NOBALANCE is speciﬁed with the EXTEND FACILITY command, then the order in which router nodes are speciﬁed with the /ROUTER qualiﬁer deﬁnes the...
Page 171: Initialize Journal
INITIALIZE JOURNAL INITIALIZE JOURNAL See CREATE JOURNAL; INITIALIZE is only retained for compatibility reasons. RTR Command Line Interface 6–95...
Page 172: Log
Specify RTR to write a log message to a log ﬁle. Format Command Qualiﬁers /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] Description command speciﬁes a deﬁned log entry to be written to its log messages. You can write log messages to the operator console and to a maximum of four log ﬁles.
Page 173 Examples RTR> LOG/OUTPUT=RTRLOG.LOG "Message check here" This command tells RTR to write a log message to the ﬁle RTRLOG.LOG. RTR> LOG/CLUSTER="Check for this message to see if logging is working" This command tells RTR to write log messages to all members of a cluster. RTR>...
Page 174: Modify Journal
MODIFY JOURNAL MODIFY JOURNAL Speciﬁes the desired and maximum allowed sizes of RTR’s recovery journal. Format MODIFY JOURNAL [disk-1] ... [,disk-n] Command Qualiﬁers /CLUSTER /BLOCKS=nr-blocks /MAXIMUM_BLOCKS=nr-blocks /NODE=node-list /OUTPUT[=ﬁle-spec] Description The MODIFY JOURNAL command speciﬁes how the size of RTR recovery journal ﬁles on the speciﬁed disks can be modiﬁed.
Page 175 If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued. Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only. /MAXIMUM_BLOCKS[=nr-blocks] /MAXIMUM_BLOCKS=1000 (D) Speciﬁes the maximum size that the journal ﬁle can use.
Page 176: Monitor
MONITOR MONITOR Displays a monitor picture on the screen. Format MONITOR [monitor-ﬁle-spec] Command Qualiﬁers /CLUSTER /COUNT=nr-updates /FACILITY=facility-name /IDENTIFICATION=process-id /INTERVAL=delay-seconds /LINK=link-name /NODE=node-list /OUTPUT[=ﬁle-spec] /PARTITION=partition-name /RESUME /VERIFY Description command allows certain RTR status variables to be continuously MONITOR displayed on your terminal. The individual items displayed in the monitor picture may be deﬁned interactively using command.
Page 177 MONITOR Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only. /COUNT=nr-updates /COUNT=inﬁnite (D) Speciﬁes how many times the RTR utility updates the screen before exiting or returning to the prompt.
Page 178 MONITOR qualiﬁer can be used to reset all the averages currently being displayed. It is also useful if monitoring is resumed after issuing one or more RTR commands. /VERIFY /NOVERIFY (D) Speciﬁes that the contents of useful when developing monitor ﬁles to ﬁnd the exact location of syntax errors. Related Commands •...
Page 179: Quit
QUIT Quits from the RTR prompt. Format QUIT Description The QUIT command exits from the RTR prompt and returns control to the operating system prompt. The command has no parameters or qualiﬁers. Same as EXIT. QUIT RTR Command Line Interface 6–103...
Page 180: Recall
RECALL RECALL Display a previously entered command for subsequent command editing. Format RECALL [command-speciﬁer] Command Qualiﬁers /ALL Description When you enter commands to the RTR Utility, they are stored in a recall buffer for later use with the entering the ﬁrst few characters of the command or the command’s number. The RECALL/ALL command can be used to list the last twenty commands.
Page 181: Register Resource Manager (Register Rm)
REGISTER RESOURCE MANAGER (REGISTER RM) Registers an instance of a resource manager (RM) with RTR. Format REGISTER RESOURCE MANAGER [resource_name] REGISTER RM [resource_name] Command Qualiﬁers /open_string /close_string /switch_name /library_path /protocol Description The REGISTER RESOURCE MANAGER command registers multiple resource managers or instances of resource managers (up to 16) with the current transaction manager.
Page 182 REGISTER RESOURCE MANAGER (REGISTER RM) Examples RTR> REGISTER RM rmi_1/open_string="Oracle_XA+Acc=P/user/pw+SesTm=15+db=accounting" /close_string="" /xaswitch_name=xaosw /library_path="library_path" 6–106 RTR Command Line Interface...
Page 183: Scroll
SCROLL Scroll a monitor picture. Format SCROLL direction [amount] Description command causes the the last picture that was displayed using the SCROLL command to be scrolled in the direction speciﬁed and then redisplayed. MONITOR Parameters direction Speciﬁes the direction in which the screen is to be scrolled. Can be one of RIGHT DOWN scrolls the picture so that its top left corner coincides with the top left corner...
Page 184: Set Environment
SET ENVIRONMENT SET ENVIRONMENT Specify the node(s) where subsequent RTR commands are executed. Format SET ENVIRONMENT Command Qualiﬁers /CLUSTER /NODE=node-list Description SET ENVIRONMENT on the speciﬁed nodes. Entering subsequent RTR commands to be executed on the local node only. Qualiﬁers /CLUSTER Currently only fully supported in an OpenVMS environment, in which case it speciﬁes that subsequent RTR commands are executed on all nodes in the...
Page 185: Set Facility
SET FACILITY Sets various facility related options. Format SET FACILITY facility-name Command Qualiﬁers /BROADCAST_MINIMUM_RATE=Bps /BROADCAST_MINIMUM_RATE=1000 /QUORUM_THRESHOLD=n /BALANCE /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] /REPLY_CHECKSUM Description SET FACILITY characteristics of a facility. Qualiﬁers /BROADCAST_MINIMUM_RATE=Bps /BROADCAST_MINIMUM_RATE=1000 /BROADCAST_MINIMUM_RATE=nnnn to which ﬂow control can reduce broadcast trafﬁc on outgoing facility links from the node concerned.
Page 186 SET FACILITY A node that combines both backend and router roles is counted twice in determining the threshold. A value of zero implies that the RTR determined threshold (half the number of node/role pairs conﬁgured plus one) is used. This is the default value; do not alter it unless you are sure that the unreachable nodes are really down.
Page 187 Related Commands • SHOW FACILITY Examples RTR> SET FACILITY FINANCE/QUORUM_THRESHOLD=4 quorum threshold set to 4 (from 0) for facility FINANCE The SET FACILITY command tells RTR to set the quorum threshold to four for facility FINANCE. This command should be used on all the backend and router nodes in the facility.
Page 188: Set Link
SET LINK SET LINK Sets various link related options. Format SET LINK link-name Command Qualiﬁers /AUTOISOLATE /ENABLE /CHECKSUM /CLUSTER /INACTIVITY_TIMEOUT[=secs] /NODE=node-list /OUTPUT[=ﬁle-spec] /SUSPECT Description command sets options for one or more or links. The options are link SET LINK enabled or disabled, link autoisolate, link checksum and link inactivity timeout. The parameter link-name honored (or not).
Page 189 Remote node autoisolation may be enabled (at the isolator) where it applies to all links using SET NODE/AUTOISOLATE, or for speciﬁc links only with the SET LINK/AUTOISOLATE command. An isolated node (isolatee) remains isolated until you carry out both of the following actions: •...
Page 190 SET LINK The new value for the current value of the link inactivity timeout. The minimum useful value for inherit the current value of the node inactivity timeout. (See SET NODE /INACTIVITY_TIMEOUT.) You can check the current value of the link inactivity timeout with the command SHOW LINK linkname/COUNTER=ndb_lw_inact You should not specify a value of less than ﬁve times the time required for a round trip over the link.
Page 191 Examples RTR> SET LINK JOEY/ENABLE This command re-allows connections from node JOEY. RTR> SET LINK JOEY/AUTOISOLATE This command sets the autoisolate attribute on the link to node JOEY. SET LINK RTR Command Line Interface 6–115...
Page 192: Set Log
SET LOG SET LOG Specify where RTR writes its log messages. Format SET LOG Command Qualiﬁers /CLUSTER /FILE=ﬁle-spec-list /NODE=node-list /OPERATOR /OUTPUT[=ﬁle-spec] Description command speciﬁes where RTR writes its log messages. You can write SET LOG log messages to the operator console and to a maximum of four log ﬁles. Log ﬁles must be periodically purged to avoid difﬁculties with full disks.
Page 193 /OPERATOR /NOOPERATOR (D) Speciﬁes that messages are written to the operator log. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Related Commands • SHOW LOG Examples RTR> SET LOG/FILE=RTRLOG.LOG/OPERATOR This command tells RTR to write log messages to the ﬁle RTRLOG.LOG and to the operator log.
Page 194: Set Mode
SET MODE SET MODE Specify whether RTR should run in a group mode or the nogroup (system) mode. Format SET MODE Command Qualiﬁers /CLUSTER /GROUP[=user-id] /NODE=node-list /OUTPUT[=ﬁle-spec] Description SET MODE command speciﬁes whether RTR runs in group mode or nogroup mode.
Page 195 /NODE[=node-list] /NODE=default-node-list (D) Speciﬁes that the command is executed on all nodes speciﬁed in is omitted then the command is executed only on the node where the node-list command was issued. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Related Commands...
Page 196: Set Node
SET NODE SET NODE Sets various node related options. Format SET node Command Qualiﬁers /AUTOISOLATE /CLUSTER /INACTIVITY_TIMEOUT[=secs] /ISOLATE /NODE=node-list /OUTPUT[=ﬁle-spec] Description command sets the automatic isolation characteristics and the link SET NODE timeout default of a node. Qualiﬁers /AUTOISOLATE /NOAUTOISOLATE (D) Any RTR node may disconnect a remote node if it ﬁnds the remote node is unresponsive or congested.
Page 197 /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued. Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only.
Page 198: Set Partition
SET PARTITION SET PARTITION Sets various partition related options. Format SET PARTITION partition-name Command Qualiﬁers /FACILITY=[facility_name] /FAILOVER_POLICY=[SHADOW | STAND_BY] /IGNORE_RECOVERY /PRIORITY_LIST=backend-node-list /RECOVERY_RETRY_COUNT=n /RESTART_RECOVERY /RESUME /SHADOW /SUSPEND /TIMEOUT=nn Description SET PARTITION backend partitions may be manipulated with this command; the command must be entered on the backend where the partition is located.
Page 199 SET PARTITION /IGNORE_RECOVERY /NOIGNORE_RECOVERY (D) Forces the partition to exit any current wait state it may be in. If a partition should enter a wait state or fail because of the unavailability of either a local or remote journal, this command can be used to override the default RTR behaviour.
Page 200 SET PARTITION Once shadowing is disabled, the secondary site servers will be unable to startup in shadow mode until shadowing is enabled again. Shadowing for the partition can be turned on by entering the command at the current active member or any of its standbys. If shadowing is already in the desired mode the command has no effect.
Page 201: Set Transaction
SET TRANSACTION Sets various transaction related options. Format SET TRANSACTION transaction-id Command Qualiﬁers /BEFORE[=date] /STATE=current_state /FACILITY=facility_name /NEW_STATE=new_state /NODE[=node_list /OUTPUT[=ﬁle-spec] /PARTITION=partition_name /SINCE[=date] /USER=username Description The SET TRANSACTION command could damage your journal and database integrity if used incorrectly. Ensure that you fully understand the reason and impact for changing a transaction state before altering your RTR system.
Page 202 SET TRANSACTION Usage Notes The command can only be executed on a backend node in which the journal is located and the RTR log ﬁle must be turned on to record the transaction changes. RTR needs to be started before using this command. When a transaction’s state is changed, the new state is written to the RTR journal synchronously.
Page 203: Valid Transaction State Changes
/NEW_STATE Speciﬁes the new transaction state that selected transactions will be changed to. This qualiﬁer is required and new state value must be speciﬁed. Value of new_state ABORT COMMIT DONE EXCEPTION Note that one cannot always change a transaction’s state from one legitimate transaction state to another.
Page 204 SET TRANSACTION Examples RTR> SET TRANSACTION "50d01f10,0,0,0,0,2166,522b2001" - _RTR> /NEW=ABORT /CURRENT=SENDING /PART=DB_PART Abort this speciﬁed transaction running in the DB_PART partition. RTR> SET TRANSACTION /NEW=ABORT /CURRENT=VOTED /PART=DB_PART For all transactions that are in VOTED transaction state and are running in DB_PART partition and in "RTR$DEFAULT_FACILITY facility, abort them.
Page 205: Show Channel
SHOW CHANNEL Show the names and state of channels that have been opened using the CLI API. Format SHOW CHANNEL [channel-name] Command Qualiﬁers /ALL_WINDOWS /CLUSTER /NODE=node-list /OUTPUT[=ﬁle-spec] Description SHOW CHANNEL name and owner process-id for channels opened using the CLI API. Parameters channel-name Speciﬁes the name of the channel to be displayed.
Page 206 SHOW CHANNEL Related Commands • call rtr_open_channel( ) • call rtr_close_channel( ) Examples RTR> SHOW CHANNEL/ALL_WINDOWS Channel type Channel name server RTR$DEFAULT_CHANNEL client CLI_CHN client CLI_CHN2 Display information about all declared channels. The channel called The channel called The channel called opened by another process (in another window).
Page 207: Show Client
SHOW CLIENT Display information about client channels. Format SHOW CLIENT Command Qualiﬁers /CLUSTER /FACILITY /FULL /IDENTIFICATION=process-id /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW CLIENT Information such as PID, key range, state, event mask and event name are displayed. Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest...
Page 208 SHOW CLIENT /NODE[=node-list] /NODE=default-node-list (D) Speciﬁes that the command is executed on all nodes speciﬁed in is omitted then the command is executed only on the node where the node-list command was issued. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Examples...
Page 209: Show Display
SHOW DISPLAY Show which items were displayed by the most recently issued DISPLAY commands. Format SHOW DISPLAY Command Qualiﬁers /ALL /OUTPUT[=ﬁle-spec] /X=column /Y=row Description SHOW DISPLAY recently issued MONITOR ﬁle using the MONITOR file-spec DISPLAY commands. The item deﬁnitions are shown in DISPLAY command format. (The command SHOW DISPLAY/OUTPUT=file Qualiﬁers /ALL...
Page 210 SHOW DISPLAY Examples RTR> MON CALLS RTR> SHOW DISPLAY/ALL DISPLAY TEXT "RTR api calls, Node: $node_name ,- PID: $process_id, Process name: -ALL-" - /X=1 /Y=1 - /BOLD="1" DISPLAY NUMERIC /X=1 /Y=5 - /BLANK - /LABEL=" rtr_open_channel /WIDTH=9 Display the CALLS Show all the items contained in the monitor picture.
Page 211: Show Environment
SHOW ENVIRONMENT Shows the default nodes used for remote command execution. Format SHOW ENVIRONMENT Description SHOW ENVIRONMENT remote command execution. Related Commands • SET ENVIRONMENT Examples RTR> SET ENVIRONMENT/NODE=(FE2,FE3) RTR> SHOW ENVIRONMENT %RTR-S-COMARESEN, commands sent by default to node FE2 %RTR-S-COMARESEN, commands sent by default to node FE3 Set the command environment so that subsequent commands will be executed on nodes FE2 and FE3.
Page 212: Show Facility
SHOW FACILITY SHOW FACILITY Show the names, conﬁguration and status of one or more facilities. Format SHOW FACILITY [facility-name] Command Qualiﬁers /BALANCE /CLUSTER /CONFIGURATION /COUNTER[=counter-name] /FULL /LINKS /STATE /OUTPUT[=ﬁle-spec] /NODE[=node-list] Description SHOW FACILITY facilities on the node where the command is executed. If no qualiﬁers are used, only the facility name or names and the roles in the facility on the node are displayed.
Page 213 /CONFIGURATION /NOCONFIGURATION (D) Speciﬁes that the facility conﬁguration is to be displayed. The conﬁguration information indicates the role(s) of the the node where the command is executed, Whether router call-out servers or backend call-out servers have been conﬁgured, Whether load balancing has been conﬁgured, Whether quorum check is being handled on this node.
Page 214 SHOW FACILITY On a frontend, this qualiﬁer can be used to ﬁnd out whether the node is currently connected to a router. Related Commands • CREATE FACILITY • DELETE FACILITY • SHOW LINK Examples RTR> SHOW FACILITY/FULL/NODE=BRONZE Facility: FUNDS_TRANSFER Configuration:- Frontend: State:- FE ->...
Page 215 The facility’s links. The ﬁrst link shown (to node ‘‘bronze’’ i.e. itself) shows that it is a router, connected to the backend, and the router is quorate. The router is not current because there is no frontend on this connection. The link is also a backend, connected to the router, and this backend is quorate.
Page 216: Show Journal
SHOW JOURNAL SHOW JOURNAL Display information about current RTR journal ﬁles. Format SHOW JOURNAL Command Qualiﬁers /CLUSTER /FILENAMES /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW JOURNAL and (optionally) the maximum and allocated number of blocks for each journal ﬁle and the journal ﬁle name. Qualiﬁers /CLUSTER /NOCLUSTER (D)
Page 217 Related Commands • CREATE JOURNAL • DELETE JOURNAL • INITIALIZE JOURNAL Examples RTR> SHOW JOURNAL/FULL/FILENAMES RTR journal:- Disk(1): /dev/rz3a File(1): /dev/rz3a /rtrjnl/SYSTEM/BRONZE.J01 Disk(2): /dev/rz2c File(2): /dev/rz2c /usr/users/rtrjnl/SYSTEM/BRONZE.J11 Show the disks used for RTR’s recovery journal and the ﬁlenames. Two disks are currently in use. Device name.
Page 218: Show Key
SHOW KEY SHOW KEY Display the key deﬁnitions created by the Format SHOW KEY [key-name] Command Qualiﬁers /ALL /FULL /OUTPUT[=ﬁle-spec] /IF_STATE Description SHOW KEY command shows the key deﬁnitions created by the DEFINE /KEY command. Parameters key-name Speciﬁes the name of the key whose deﬁnition you want displayed. See the description of the Qualiﬁers /ALL...
Page 219 Related Commands • DEFINE /KEY Examples RTR> SHOW KEY/FULL DEFAULT PF1 defined as "" DEFAULT KP0 defined as "MONITOR/RESUME" DEFAULT KP2 defined as "SCROLL DOWN 1" DEFAULT KP4 defined as "SCROLL LEFT 1" DEFAULT KP5 defined as "SCROLL HOME" DEFAULT KP6 defined as "SCROLL RIGHT 1" DEFAULT KP8 defined as "SCROLL UP 1"...
Page 220: Show Link
SHOW LINK SHOW LINK Display the conﬁguration and status of the links to other nodes. Format SHOW LINK [node-name] Command Qualiﬁers /CLUSTER /COUNTER[=counter-name] /FACILITY /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] /STATE Description command shows the conﬁguration and status of the links to RTR SHOW LINK nodes.
Page 221 /FULL Equivalent to specifying /NODE[=node-list] /NODE=default-node-list (D) Speciﬁes that the command is executed on all nodes speciﬁed in node-list is omitted then the command is executed only on the node where the command was issued. /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec /STATE...
Page 222: Show Log
SHOW LOG SHOW LOG Display the names of the current log ﬁles. Format SHOW LOG Command Qualiﬁers /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW LOG command shows the names of the current RTR log ﬁles as deﬁned with the SET LOG Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster.
Page 223 Example RTR> SHOW LOG Messages not being sent to operator console Log file[1]: Show where RTR log messages are currently written. Currently not being sent to the operator log. Currently being written to ﬁle /usr/users/someone/rtr_logfile.log rtr_logfile.log RTR Command Line Interface 6–147 SHOW LOG...
Page 224: Show Mode
SHOW MODE SHOW MODE Displays the current RTR mode. Format SHOW MODE Command Qualiﬁers /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW MODE command shows the currently running user group for RTR. For nogroup (system) mode, a null group name is displayed. further information about modes. Qualiﬁers /CLUSTER /NOCLUSTER (D)
Page 225 SHOW MODE Examples RTR> SHOW MODE Group name is "develop" RTR Command Line Interface 6–149...
Page 226: Show Node
SHOW NODE SHOW NODE Shows the node network status, the autoisolation state and the node inactivity timer. Format SHOW NODE Command Qualiﬁers /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description shows the network status, the autoisolation state (enabled or SHOW NODE disabled) and the node inactivity timer. Qualiﬁers /CLUSTER /NOCLUSTER (D)
Page 227 Examples RTR> SHOW NODE Node properties: Network state: Auto isolation: Inactivity timer/s: SHOW NODE command. Network status Auto isolation state (enabled or disabled). Inactivity timer value in seconds. enabled disabled RTR Command Line Interface 6–151 SHOW NODE...
Page 228: Show Partition
SHOW PARTITION SHOW PARTITION Display server data partition information. Format SHOW PARTITION Command Qualiﬁers /BACKEND /BRIEF /CLUSTER /FACILITY /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] /ROUTER Description SHOW PARTITION their states, and current transaction activity. This information is useful for diagnosing bottlenecks or partition difﬁculties in RTR. The ‘‘States’’...
Page 229: Router Partition States
Table 6–21 Router Partition States State BLOCKED ACTIVE CATCHUP TAKEOVR LAGGING Qualiﬁers /BACKEND /NOBACKEND (D) Displays information about backend partitions; it shows the partition state and low and high bounds. /BACKEND with /FULL provides more detailed information for a partition, giving the current queue depth (transactions active) on a partition. This is useful for determining whether a server is processing transactions correctly.
Page 230 SHOW PARTITION • The state of transaction presentation - one of active, suspended or suspending • The current failover policy - one of fail_to_standby, fail_to_shadow or pre_ v32_compatibilty The SHOW PARTITION comand displays callout server data as backend server data because a callout server uses server, not router, data structures. A callout server actually runs on the router identiﬁed for its facility.
Page 231 Partition name: Facility: RTR$DEFAULT_FACILITY Low Bound: "aaaa" Active Servers: Transaction presentation: active Txns Active: Failover policy: fail_to_standby Partition name: Facility: RTR$DEFAULT_FACILITY Low Bound: "nnnn" Active Servers: Transaction presentation: active Txns Active: Failover policy: fail_to_standby SHOW PARTITION RTR$DEFAULT_PARTITION_16777217 State: High Bound: Free Servers: Last Rcvy BE: Txns Rcvrd:...
Page 232: Show Process
SHOW PROCESS SHOW PROCESS Display information about processes which are using RTR. Format SHOW PROCESS Command Qualiﬁers /CLUSTER /COUNTER[=counter-name] /FULL /IDENTIFICATION=process-id /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW PROCESS Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest...
Page 233 /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Examples RTR> SHOW PROCESS Processes: Process-id is omitted then the standard or default output is used. Process Name RTR Command Line Interface 6–157 SHOW PROCESS .
Page 234: Show Requester
SHOW REQUESTER SHOW REQUESTER See SHOW CLIENT. The SHOW REQUESTER command has been replaced by SHOW CLIENT and is retained for compatibility reasons only. 6–158 RTR Command Line Interface...
Page 235: Show Resource Manager (Show Rm)
SHOW RESOURCE MANAGER (SHOW RM) Displays resource manager instance (RM) information. This command is available only on UNIX and Windows NT systems. Format SHOW RESOURCE MANAGER [resource_name] SHOW RM [resource_name] Command Qualiﬁers /CLUSTER /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description The SHOW RESOURCE MANAGER command displays information for registered RMs.
Page 236 SHOW RESOURCE MANAGER (SHOW RM) /FULL /NOFULL (D) Displays additional information for facilities that reference a particular RM. If no rmi_name is included, displays information for all RMs. /NODE[=node-list] /NODE=default-node-list (D) Speciﬁes that the command is executed on all nodes speciﬁed in is omitted then the command is executed only on the node where the node-list command was issued.
Page 237: Show Rtr
SHOW RTR Display the conﬁguration and status of RTR. Format SHOW RTR Command Qualiﬁers /CLUSTER /COUNTER[=counter-name] /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] /STATUS /VERSION Description command displays the conﬁguration and status of RTR. SHOW RTR Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest...
Page 238 SHOW RTR /STATUS (D) /NOSTATUS Displays the current status of RTR (started, stopped and so on). /VERSION /NOVERSION (D) Displays the RTR version. Related Commands • STOP RTR • START RTR Example RTR> SHOW RTR RTR running on node baby.home.dec.com in group: develpr Show the state and conﬁguration of RTR.
Page 239: Show Segment
SHOW SEGMENT Display the type and size of routing key segments. Format SHOW SEGMENT Command Qualiﬁers /CLUSTER /FACILITY /FULL /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW SEGMENT The routing key definition The routing key speciﬁes the data within a message sent from clients used to route the message to a particular key range server.
Page 240 SHOW SEGMENT Examples RTR> SHOW SEGMENT Facility RTR$DEFAULT_FACILITY TEST_FAC Show the routing key segments for all facilities. The facility name, the routing key data type, key length and offset are shown for each facility. 6–164 RTR Command Line Interface Data Type Length UNSIGNED SIGNED...
Page 241: Show Server
SHOW SERVER Display information about server channels. Format SHOW SERVER Command Qualiﬁers /CLUSTER /FACILITY /FULL /IDENTIFICATION=process-id /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description SHOW SERVER Information such as PID, key range, state, event mask, event name and partition ID can be displayed. The ‘‘State:’’ ﬁeld of the SHOW SERVER command can display the following values: Table 6–22 Key-range States State...
Page 242: Server Flags
SHOW SERVER Table 6–23 Server Flags FLAG Qualiﬁers /CLUSTER /NOCLUSTER (D) Speciﬁes that the command is executed on all the nodes in the cluster. If neither /NODE nodes speciﬁed by the latest command has been entered then the command is executed only on the node where the command was issued.
Page 243 Examples RTR> SHOW SERVER Servers: Process-id Facility 20828 RTR$DEFAULT_FACILITY 20828 RTR$DEFAULT_FACILITY RTR> SHOW SERVER/FULL Servers: Process-id: Channel: State: High Bo Uents: Partition-Id: Process-id: Channel: State: High Bo User Events: Partition-Id: Channel 589825 655362 20828 Facility: RTR$DEFAULT_FACILITY 589825 Flags: active Low Bound: mmmm rcpnam: RTR Events:...
Page 244: Show Transaction
SHOW TRANSACTION SHOW TRANSACTION Displays information about currently active transactions. Format SHOW TRANSACTION Command Qualiﬁers /BACKEND /CLUSTER /FACILITY /FRONTEND /FULL /IDENTIFICATION=process-id /NODE[=node-lisft] /OUTPUT[=ﬁle-spec] /ROUTER Description SHOW TRANSACTION transaction ID, facility, transaction state, frontend user, start time and router node. Qualiﬁers /BACKEND /NOBACKEND (D) Speciﬁes that information should be listed for transactions in a backend node.
Page 245: Key-Range States
Note: In environments that do not support clustering, use of the /CLUSTER qualiﬁer will cause the relevant command to be executed on the local node only. /FRONTEND /NOFRONTEND (D) Speciﬁes that information should be listed for transactions in a frontend node. If none of /BACKEND, /FRONTEND or /ROUTER are speciﬁed, then information for all of them are displayed.
Page 246 SHOW TRANSACTION Table 6–25 (Cont.) Key-Range States State active sec_act pri_act pri_lone sec_chup Examples RTR> SHOW TRANSACTION/BACKEND/FULL Backend transactions: Tid: Facility: RTR$DEFAULT_FACILITY Frontend: State: Router: Active-Key-Ranges: Total-Tx-Enqs: Server-Pid: Journal-Node: First-Enq: Nr-Replies: 6–170 RTR Command Line Interface Meaning Active non-shadowed Secondary active Primary active Primary running alone Secondary is catching up...
Page 247: Spawn
SPAWN Allows you to execute operating system commands without leaving the RTR utility. Format SPAWN [operating-system-command] Command Qualiﬁers /INPUT=ﬁle-spec /OUTPUT=ﬁle-spec /WAIT Description command allows you to execute operating system commands without SPAWN leaving the RTR session. If you specify an operating system command as the parameter to SPAWN, the command is executed in the context of a spawned subprocess.
Page 248: Start Rtr
START RTR START RTR Start RTR on one or more nodes. Format START RTR Command Qualiﬁers /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] The following qualiﬁers are only relevant when running on OpenVMS. Command Qualiﬁers /ASTLM=ast-limit /BIOLM=io-buffered /BYTLM=buffer-limit /CPULM=time-limit /DIOLM=io-direct /ENQLM=enqueue-limit /FILLM=ﬁle-limit /JTQUOTA=job-table-quota /LINKS=max-links /PARTITIONS=max-partitions /PGFLQUOTA=page-ﬁle /PRCLM=subprocess-limit...
Page 249 Qualiﬁers /ASTLM=ast-limit /ASTLM=(max-links + max-processes) Speciﬁes the AST limit for the RTR ACP. The value for ast-limit scheduling and a minimum of two per DECNET logical link maintained by RTR. For example, in a 20-node conﬁguration, a router node needs an ASTLM of at least 45 ( 5 + (20 In systems where a lot of trafﬁc is expected, deﬁning additional ASTLM quota will enable lookahead I/O to be booked to channels without RTR ACP being held...
Page 250 START RTR /DIOLM=io-direct /DIOLM=(max-links + max-processes) Speciﬁes the maximum number of direct I/O operations that the RTR ACP can have outstanding at any one time. If you do not specify a direct I/O quota, the default value established at system generation time is used.
Page 251 The default value of is automatically calculated, based on the values of page-file /LINKS and /PROCESSES. /PRCLM=subprocess-limit /PRCLM=10 (D) Speciﬁes the maximum number of subprocesses that the RTR ACP can create. The default for subprocess-limit /PRIORITY=priority /PRIORITY=6 (D) Requires alter priority (ALTPRI) privilege to set the priority higher than your current process.
Page 252 START RTR Related Commands • SHOW RTR • STOP RTR Examples See Chapter 2, Starting and Setting Up RTR, for examples of how to use the command. START RTR 6–176 RTR Command Line Interface...
Page 253: Stop Rtr
STOP RTR Stop RTR on one or more nodes. Format STOP RTR Command Qualiﬁers /ABORT /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description STOP RTR command stops RTR in an orderly manner. Alternatively, RTR can be stopped in an abrupt manner (/ABORT), and any applications using RTR are forced to exit.
Page 254 STOP RTR /OUTPUT[=ﬁle-spec] /OUTPUT=stdout (D) Speciﬁes that the resulting information is written to the ﬁle /OUTPUT file-spec Related Commands • SHOW RTR • START RTR Examples See Chapter 2, Starting and Setting Up RTR, for examples of how to use the command.
Page 255: Trim Facility
TRIM FACILITY Removes nodes or roles or both from an existing facility deﬁnition. Format TRIM FACILITY [facility_name] Command Qualiﬁers /BACKEND=backend-list /CLUSTER /FRONTEND=frontend-list /NODE[=node-list] /OUTPUT[=ﬁle-spec] /ROUTER=router-list Description TRIM FACILITY deﬁnition. A node can be removed from a facility or a role can be removed from a node.
Page 256 TRIM FACILITY RTR MONITOR QUORUM displays a monitor picture which allows the quorum negotiations to be observed. You can use this after using a TRIM FACILITY command; once quorum has been re-attained, the participating nodes return to the quorate state. For example, in a three node facility called only frontend roles, and node This facility could have been created as follows:...
Page 257 /NOFRONTEND (D) Speciﬁes the names of nodes where the frontend role is removed for this facility. is a list of frontend-list than one frontend-node is either the name of a node or frontend-node speciﬁes a text ﬁle containing a /NODE[=node-list] /NODE=default-node-list (D) Speciﬁes that the command is executed on all nodes speciﬁed in is omitted then the command is executed only on the node where the...
Page 258: Unregister Resource Manager (Unregister Rm)
UNREGISTER RESOURCE MANAGER (UNREGISTER RM) UNREGISTER RESOURCE MANAGER (UNREGISTER RM) UNREGISTER RESOURCE MANAGER resource manager. Format UNREGISTER RESOURCE MANAGER [resource_name] UNREGISTER RM [resource_name] Command Qualiﬁers /CLUSTER /NODE[=node-list] /OUTPUT[=ﬁle-spec] Description The UNREGISTER RESOURCE MANAGER command unregisters an instance of a resource manager. The command succeeds only when no facility references it.
Page 259: A Creating Monitor Pictures
Creating Monitor Pictures The standard monitor pictures provided with RTR (described in Chapter 5) are sufﬁcient for most needs. You may also create your own monitor pictures to suit particular needs. This appendix tells you how to do this. The RTR monitor utility provides a means to continuously display the status of RTR and the applications using it.
Page 260: Interactive Deﬁnition Of A Monitor Picture
Creating Monitor Pictures The commands used to deﬁne and display monitor pictures are: CLEAR DISPLAY BAR DISPLAY NUMERIC DISPLAY STRING DISPLAY SYMBOLIC DISPLAY TEXT MONITOR SCROLL SHOW DISPLAY These commands are described in the following sections. A.1 Interactive Deﬁnition of a Monitor Picture Example A–1 shows a monitor picture being deﬁned in an interactive RTR session.
Page 261: Interactively Deﬁned Monitor Picture
Figure A–1 Interactively Deﬁned Monitor Picture SOME DATA ITEM: OTHER DATA ITEM: 0 Because monitor ﬁle deﬁnitions depend on the internal structure and data items of RTR, they may need to be changed for future versions of RTR. A.2 Substitution Symbols The text and labels in the DISPLAY commands that are used to deﬁne monitor pictures can contain symbols which are substituted when the picture is displayed.
Page 262: Arithmetic Expressions And Operators
Creating Monitor Pictures A.3 Arithmetic Expressions and Operators Table A–3 Arithmetic Operators in Display Commands Characters & <= >= <> < > Example A–2 shows how these operators are used. Example A–2 Arithmetic Operators Examples RTR> DISPLAY NUMERIC RTR_SOME_DATA_ITEM+2 RTR> MONITOR RTR>...
Page 263 A.3 Arithmetic Expressions and Operators Aggregation of Data Items DISPLAY commands which select multiple instances of a data item (for example, multiple instances of a process counter) can use the following keywords to control the way the items are aggregated. _MIN—select the data item instance with the lowest value _MAX—select the data item instance with the higheest value By default, data items are totaled unless the...
Page 265: B Server Shadowing And Recovery
Server Shadowing and Recovery RTR shadowing gives you the ability to recover from a site disaster without the need for special coding within your application program. This appendix is an introduction to RTR shadowing. A server for a database partition is said to be shadowed when two copies of the same server perform identical actions on identical database copies on separate nodes.
Page 266: The Rtr Journal System
Server Shadowing and Recovery B.2 Automatic Features • RTR_EVTNUM_SRSHADOWGAIN - Server has gained its shadow partner • RTR_EVTNUM_SRRECOVERCMPL - Server has completed recovery The shadow events are delivered with no special status and no data. They are delivered only to the server(s) whose state has changed. A server receives RTR_EVTNUM_SRPRIMARY under the following circumstances: •...
Page 267: Shadow Site Failure And Journaling
The number of blocks speciﬁed by the /BLOCKS qualiﬁer speciﬁes the size of the journal that RTR attempts to keep to. (The actual number of blocks used may vary, depending upon the load on RTR.) The command MODIFY JOURNAL also accepts the /BLOCKS and /MAXIMUM_ BLOCKS qualiﬁers.
Page 268: Maximum Journal Size
Server Shadowing and Recovery B.4 Shadow Site Failure and Journaling B.4.1 Maximum Journal Size The current maxima for the size of a journal are: Number of blocks per disk: 524288 (This is max_segments_per_disk * disk_blocks_per_segment 32.) Number of disks per journal: 16. B.5 Standby for Shadows Shadowed sites can either be two nodes within a single cluster, or can be two separate clusters.
Page 269: Shadows In Action
Note that RTR does not have to wait for the secondary shadow server to complete its processing. It only needs to know that the primary has committed the transaction and that the journal ﬁle of the secondary shadow server contains the ﬁnal vote status.
Page 270: B.9 Server States
Server Shadowing and Recovery B.8 Application Considerations • Any physical reference to the transaction which is unique to the executing server, e.g. Channel Id, system time, DB-key, etc., should not be passed back to the client for future references within its subsequent messages, as this could lead to inconsistent handling when a different server is involved in shadow operations.
Page 271: Server States
Figure B–2 Server States INITIAL Propose KR Backend not to Routers yet quorate W A I T − T R − R E T R Y Retry W A I T _ Q U O R U M Router detects definition clash Propose KR to Routers...
Page 272: Client States
Server Shadowing and Recovery B.10 Client States B.10 Client States The current state of a client process can be examined as follows: RTR> show client/full Clients: Process-id: Channel: State: User Events: Figure B–3 describes the client state changes which appear in the "State:" ﬁeld Figure B–3 Client States Requester State Transitions INITIAL...
Page 273: Partition States
B.11 Partition States The current state of a key-range partition can be examined using the command for the routers and the backends: PARTITION/FULL RTR> show partition/router/full Facility: RTR$DEFAULT_FACILITY Low Bound: Failover policy: Backends: States: Primary Main: Backend partitions: RTR> show partition/backend/full Partition name: Facility: RTR$DEFAULT_FACILITY...
Page 275: C Xa Support
This appendix explains how RTR may be used with a X/OPEN Distributed Transaction Processing (DTP) conformant Resource Manager. C.1 Introduction The X/OPEN Distributed Transaction Processing (DTP) architecture deﬁnes a standard interface that lets application programs share resources provided by resource managers. The XA interface uses the two-phase commit protocol to commit transactions, and is a system-level bidirectional interface between the transaction manager (TM) and the resource manager (RM).
Page 276: Modiﬁed Rtr Api
XA Support C.1 Introduction facility_name = user-speciﬁed facility name /resource_manager = the name of those RMs this facility references For example: CREATE FACILITY test /front=N1 /back=N2/router=N3 /resource_manager=(employ_rm,payroll_rm) C.1.3 Modiﬁed RTR API An application written to use RTR with XA does not need all existing RTR application programming interface statements.
Page 277: D Rtr Utility Error Messages
RTR Utility Error Messages This appendix describes the various error messages that can be returned by the RTR utility. %RTR-F-ABKEYW, Ambiguous qualiﬁer or keyword - supply more characters Explanation: Too few characters were used to truncate a keyword or qualiﬁer name to make the keyword or qualiﬁer name unique. %RTR-F-ABVERB, Ambiguous command verb - supply more characters Explanation: Too few characters were used to truncate a command name to make the command name unique.
Page 278 RTR Utility Error Messages %RTR-F-BADDSKWRI, Unable to create/extend a journal ﬁle Explanation: An attempt to create or extend a journal ﬁle on disk failed. Check that the disk(s) you are using for journals have sufﬁcient free space. %RTR-E-BADOP, Unable to complete operation @[A] line [A] Explanation: Processing deﬁnition incomplete or undeﬁned - report occurrence together with supporting information on current command to RTR Engineering.
Page 279 %RTR-E-CLOSEPEND, Send failed due to close pending on channel - call rtr_ receive_message Explanation: Sending of data to the ACP has been aborted due to the presence of an undelivered mt_closed message on the channel. The application may retrieve the reason for the channel closure, by calling the receive_message verb to receive the mt_closed message.
Page 280 RTR Utility Error Messages %RTR-S-DISITMCLR, [A] display item(s) cleared Explanation: Indicates how many display items [A] were successfully cleared after issuing a CLEAR DISPLAY command. %RTR-W-DISKALL, Disk is not available to RTR Explanation: An attempt was made to create a journal on a disk which is allocated to a different process.
Page 281 %RTR-F-DUPJOUFIL, Duplicate RTR journal ﬁle found - remove duplicate ﬁle or CREATE JOURNAL /SUPERSEDE Explanation: A duplicate RTR journal ﬁle has been found. This status may be returned by the CREATE FACILITY and SHOW JOURNAL commands. Probable cause: System management error. A user has copied a journal ﬁle, or a disk containing a journal ﬁle.
Page 282 RTR Utility Error Messages %RTR-F-ERRACCDIR, Directory [A], cannot be accessed or opened Explanation: A directory cannot be accessed or opened. %RTR-E-ERRACCFIL, Error accessing ﬁle [A] Explanation: Displays the name [A] of a ﬁle that the RTR utility was unable to access. %RTR-E-ERRACCMBX, Error accessing mailbox Explanation: An error occurred whilst accessing a mailbox.
Page 283 %RTR-E-ERRSTAACP, Unable to start ACP Explanation: The RTR ACP process could not be started when a "START RTR" command was issued. The subsequent message gives more details. %RTR-E-ERRSTARCH, Unable to start remote client handler Explanation: The RTR remote client handler process could not be started when a "START REMOTE_CLIENT_HANDLER"...
Page 284 RTR Utility Error Messages %RTR-E-FACNAMLON, Facility name [A] is longer than 30 characters Explanation: Facility name [A] is too long. %RTR-E-FACNAMSTA, Facility name [A] does not start with a letter Explanation: Facility name [A] does not start with a capital letter ("A" to "Z").
Page 285 %RTR-E-ILLPARTCHAR, Legal characters are alphanumeric and under-score Explanation: Illegal chars in partition name argument. %RTR-E-ILLREMDEV, Device [A] contains a node speciﬁcation Explanation: RTR cannot create its journal ﬁles on remote systems. Re-issue the "CREATE JOURNAL" command for local disk. %RTR-E-INSUFPRIV, Insufﬁcient privileges to run RTR Explanation: More privileges required to run the RTR utility.
Page 286 RTR Utility Error Messages %RTR-F-INVKSTYPE, Invalid ks_type argument Explanation: Invalid ks_type argument. %RTR-F-INVMSGFMT, Invalid format argument Explanation: Invalid format argument. Possible reasons include the use of an invalid character or expression in the format string, or a mismatch in the number of bytes speciﬁed by the format string and the message length argument.
Page 287 %RTR-E-ITMALREXI, There is already something displayed at x = [A], y = [A] Explanation: Indicates that invalid coordinates were speciﬁed on a "DISPLAY" command within a display ﬁle. There already is an item at point [A], [B]. %RTR-F-IVKEYW, Unrecognized keyword - check validity and spelling n [A] Explanation: A keyword speciﬁed in a command is not valid for the command.
Page 288 RTR Utility Error Messages %RTR-F-JOUFORCHA, Journal format has been changed - CREATE JOURNAL /SUPERSEDE Explanation: The journal ﬁle(s) found have an out-of-date format. This status may be returned by the CREATE FACILITY and SHOW JOURNAL commands after a new version of RTR has been installed on a system. Corrective action: Issue an RTR CREATE JOURNAL /SUPERSEDE command.
Page 289 %RTR-S-JOURNALINI, Journal has been created on device [A] Explanation: Conﬁrms that the RTR journal has been successfully created on device [A] after issuing the "CREATE JOURNAL" command. %RTR-S-JOURNALMOD, Journal has been modiﬁed on device [A] Explanation: Conﬁrms that the RTR journal has successfully modiﬁed the size requirements on device [A] after issuing the "MODIFY JOURNAL"...
Page 290 RTR Utility Error Messages %RTR-E-LOCKFAIL, Cannot obtain lock for resource [A] Explanation: Failed to obtain lock. Enable logging for more information about error. %RTR-S-LOGFILSET, Logging to [A] Explanation: Displays which log ﬁles will be used after issuing a "SET LOG" command with the "/FILE" or "/OPERATOR" or both qualiﬁers. %RTR-S-LOGFILSUP, Logging suppressed Explanation: Indicates that logging is successfully suppressed after issuing a "SET LOG command"...
Page 291 %RTR-E-NDBTABFUL, The NDB table is full Explanation: This message is displayed when an "CREATE FACILITY" command is issued. It indicates that the total number of different nodes speciﬁed with this and all previous "CREATE FACILITY" commands would exceed the limit speciﬁed with the "/LINKS" qualiﬁer when RTR was started. %RTR-E-NFW, Operation requires "SETPRV"...
Page 292 RTR Utility Error Messages %RTR-E-NODNA, DECnet speciﬁed for [A], but transport protocol unavailable or disabled Explanation: DECnet was speciﬁed as required through use of a node name preﬁx ("dna." or a substitute), but no corresponding entry in the node database can be found. Add an entry for the indicated node to your local node name database or to you name server.
Page 293 %RTR-E-NOKEYSEGS, You must specify at least one keysegment - use /KEY1 - /KEY9 Explanation: Except for a callout partition, it is necessary to deﬁne the key range, so the absence of any key segment descriptors is an error. %RTR-F-NOKEYW, Qualiﬁer name is missing - append the name to the slash Explanation: A slash character is on the command line but is not followed by a qualiﬁer keyword name.
Page 294 RTR Utility Error Messages %RTR-E-NOSUCHITM, Nothing displayed at x = [A], y = [A] Explanation: Indicates that invalid coordinates were speciﬁed on a "CLEAR DISPLAY" or "SHOW DISPLAY" command. No item is displayed at point [A], [B]. %RTR-E-NOSUCHNOD, No such node, [A] Explanation: The requested node [A] does not exist.
Page 295 %RTR-E-NUMCONILL, Numeric constant has illegal syntax, [A] Explanation: The numeric constant [A] is invalid. %RTR-W-OBSQUAL, Qualiﬁer [A] is obsolete - value ignored Explanation: An obsolete qualiﬁer has been speciﬁed on a command line. The qualiﬁer no longer has any effect, and the speciﬁed value will be ignored. %RTR-E-ONLONENOD, Only one node allowed if process ID speciﬁed Explanation: If a process ID is supplied on "MONITOR"...
Page 296 RTR Utility Error Messages %RTR-E-PRTBADCMD, Partition command invalid or not implemented in this version of RTR Explanation: Status return indicating that the ACP received a request for an unknown partition command. %RTR-E-PRTBADFPOL, Unrecognised partition failover policy code Explanation: Status indicating that an invalid value was speciﬁed for the partition failover policy.
Page 297 %RTR-S-PRTNCREATED, Partition created Explanation: The requested partition was successfully created. %RTR-S-PRTNDELETED, Partition deleted Explanation: The requested partition was successfully deleted. %RTR-S-PRTNEWFPOLS, Failover policy set Explanation: Status indicating successful change to the partition failover policy. %RTR-S-PRTNEWPOLWAIT, Failover policy stored - awaiting servers before taking effect Explanation: Status indicating successful change to the partition failover policy, but the change will only take effect once servers have been started.
Page 298 RTR Utility Error Messages %RTR-E-PRTRUNDOWN, Partition is in rundown prior to deletion - no action taken Explanation: Cannot perform the requested action since the partition is being deleted. %RTR-I-PRTSHDOFF, Partition [A]:[A] shadow state set to off by operator [A] Explanation: Written to log ﬁle in response to a user request to change the state of partition shadow state.
Page 299 %RTR-E-RTRALRSTA, RTR already started Explanation: RTR was already running when the "START RTR" command was executed. %RTR-S-RTRLOGENT, [A] Explanation: The RTR LOG command was used to make an entry in the RTR LOG %RTR-I-RTRNOTRUN, RTR not running Explanation: Message created speciﬁcally for the STOP RTR command if RTR is not currently running, so that the IVP does not report a fatal message.
Page 300 RTR Utility Error Messages %RTR-F-SPUJOUFIL, Spurious RTR journal ﬁle found - remove extra ﬁle, or CREATE JOURNAL /SUPERSEDE and submit SPR Explanation: A spurious RTR journal ﬁle has been found which does not correspond to the other journal ﬁles on the system. This status may be returned by the CREATE FACILITY and SHOW JOURNAL commands.
Page 301 %RTR-E-TOOMANCHN, Too many channels Explanation: Displayed when a "SYS$DCL_TX_PRC" command is issued and the channel table is full. %RTR-F-TOOMANDIS, Too many disks speciﬁed in journal deﬁnition Explanation: Explanation: Too many disks were speciﬁed in journal deﬁnition. The RTR journal can be deﬁned to use up to a maximum of sixteen disks.
Page 302 RTR Utility Error Messages %RTR-E-UNEXPEND, Expression ended before [A] encountered Explanation: The expression is invalid because it terminated where when token [A] was expected. %RTR-E-UNKNOWQUAL, Invalid qualiﬁer keyword value - check your program Explanation: Status return indicating that an unrecognised qualiﬁer keyword value was supplied.
Page 303: E Rtr Log Messages
This appendix describes the various error messages that can be sent to the operator console or written to RTR’s operator log ﬁle. %RTR-E-ABODEAREQ, Transaction aborted that was started by client that has since exited Explanation: Indicates that a transaction has been aborted that was started by a client that has since exited.
Page 304 RTR log messages %RTR-E-BADIDSIZ, Bad node ID size [A] detected at 0x[A] Explanation: This message indicates that errors have been detected in processing of an internal node identiﬁer. The presence of this message indicates a serious problem in the conﬁguration of the network name/address databases, and RTR will likely be unable to operate correctly.
Page 305 %RTR-F-BRODISLIN, Broadcast message(s) discarded because of link unavailability Explanation: One or more broadcast messages had to be discarded because there is no logical link to the destination node. %RTR-I-CLUENABLED, RTR cluster [A] is enabled using [A] Explanation: Information message indicating whether RTR is making use of any speciﬁc cluster software.
Page 306 RTR log messages %RTR-I-CONNALIAS, Link [A] connected as [A] Explanation: Support for internet tunnels allows for the conﬁguration of links from which connections appear to originate with an source address other than that by which the local node is registered locally, for example, the connection may appear to originate from an pseudo-adapter address assigned by the tunnel server.
Page 307 %RTR-I-FACLOSTFE, Facility [A] lost Frontend node [A] Explanation: This node is no longer a current router on facility [A], for frontend node [B] %RTR-I-FACLOSTTR, Facility [A] lost Router node [A] Explanation: A connection has been lost with router node [B] on facility [A] %RTR-E-FACNOTDEC, Facility name not matched Explanation: Result of a connection attempt to a remote node specifying a facility that does not (yet) exist on the remote node.
Page 308 RTR log messages full). RTR has ensured that the TX has been committed, but the operator should nevertheless check the condition on the BE where the TX was aborted to determine why this occurred (possible resource problems on the server, for example).
Page 309 %RTR-I-JOUSEACOM, Journal search on facility [A] completed. [A] recoverable transactions found Explanation: Journal search has completed. This message appears when RTR is started The number of transactions needing recovery is indicated by [A]. %RTR-F-JOUSEQERR, RTR journal record sequence error - CREATE JOURNAL /SUPERSEDE and submit SPR Explanation: An inconsistency has been found in the record sequence within the RTR journal.
Page 310 RTR log messages %RTR-E-NOCURRTR, Current router search failed for facility [A] Explanation: None of the routers speciﬁed for facility [A] are currently connectable. The search will continue after a short interval. %RTR-W-NODENOTCNFG, Node is not conﬁgured for the facility Explanation: Result of a connection attempt to a remote node where the connecting link is not conﬁgured in the requested facility at the remote node.
Page 311 %RTR-I-PRTCMDFRMBE, Command received for partition [A]:[A] from backend node [A] Explanation: Log ﬁle message indicating the origin of a command. %RTR-E-PRTDELCAN, Partition deleted - operation canceled Explanation: Status used to terminate a pending operation when the partition is deleted prior to completion of the operation. %RTR-W-PRTLCLRECEXIT, Partition [A]:[A] local recovery terminated by operator [A] Explanation: Log message indicating that recovery wait override requested...
Page 312 RTR log messages %RTR-E-PRTSETFAILTR, Router unable to process command Explanation: A partition set command failed at the router. An entry is written to the log ﬁle describing the problem. Message arguments are the facility name and the KR ID. A second message is written detailing the nature of the problem.
Page 313 %RTR-F-QIROVERFLOW, No more QIRs left Explanation: This status is used to indicate an inadequacy in the static reservations for the internal query initiation descriptors. Make a note of all QRM counters using SHOW RTR /COUNTER=QRM* Send SPR with the corresponding RTRACP dump. %RTR-F-RAEOVERFLOW, No more RAEs Explanation: This status is used to indicate an inadequacy in the static reservations for the internal response acceptor elements.
Page 314 RTR log messages %RTR-W-RSPFAC, Response from Node [A] about Facility [A] Explanation: A negotiation with remote node [A] about facility [B] has failed for the reason reported in the following line. This may be a reason for system manager intervention. %RTR-W-RSPNODE, Connection to node [A] failed : reason is Explanation: A negotiation with remote node [A] about facility [B] has failed for the reason reported in the following line.
Page 315 %RTR-W-TOOMANYNETIDS, Too many net IDs for node ’[A]’ - check for and eliminate any unnecessary adapter/protocol combinations Explanation: On a system conﬁgured to run multiple network protocols over multiple adpaters, RTR can run out of space to store and communicate the resultant node IDs.
Page 317: Index
Active Monitor, 5–2 Aggregation of Data Items, A–5 Backend, 2–1 DISPLAY, 6–67 Broadcast Monitor, 5–2 Call Rtr_accept_tx, 6–3 rtr_prepare_tx, 6–22 CALL RTR_BROADCAST_EVENT, 6–6 RTR_CLOSE_CHANNEL, 6–10 RTR_ERROR_TEXT, 6–12 RTR_GET_TID, 6–13 RTR_OPEN_CHANNEL, 6–15 RTR_RECEIVE_MESSAGE, 6–25 RTR_REJECT_TX, 6–28 RTR_REPLY_TO_CLIENT, 6–31 RTR_REQUEST_INFO, 6–35 RTR_SEND_TO_SERVER, 6–38 RTR_START_TX, 6–42 Call-out server, 2–7 Calls...
Page 318 DTC Support, C–2 ENVIRONMENT SET, 1–4, 6–108 SHOW, 6–135 Errors, 1–2 Event Monitor, 5–2 EXECUTE, 6–89 EXIT, 6–90 EXTEND FACILITY, 6–91 Facility, 1–1 Create, 2–1 Monitor, 5–2 FACILITY CREATE, 6–47 DELETE, 2–4, 6–61 EXTEND, 6–91 SET, 6–109 SHOW, 6–136 TRIM, 6–179 @ﬁle, 1–3 Flow Monitor, 5–2...
Page 319 Monitor (cont’d) Routing, 5–3 Rtr, 5–3 Stalls, 5–3 System, 5–3 Tps, 5–3 Tpslo, 5–3 Trafﬁc, 5–3 V2calls, 5–4 XA, 5–4 MONITOR, 5–1, 6–100 Monitor ﬁle, 5–1 Monitor picture, 5–1, A–1 NAME_CACHE FLUSH, 6–88 Netbytes Monitor, 5–3 Netstat Monitor, 5–3 Network transports, 2–13 NODE SET, 6–120 SHOW, 6–150...
Page 320 SET (cont’d) MODE, 6–118 NODE, 6–120 PARTITION, 6–122 TRANSACTION, 6–125 SHOW CHANNEL, 6–129 CLIENT, 6–131 DISPLAY, 6–133, A–2 ENVIRONMENT, 6–135 FACILITY, 6–136 JOURNAL, 6–140 KEY, 6–142 LINK, 6–144 LOG, 6–146 MODE, 6–148 NODE, 6–150 PARTITION, 6–152 PROCESS, 6–156 REQUESTER, 6–158 RESOURCE MANAGER, 6–159 RM, 6–159 RTR, 6–161...
