Network Config

PN: 1725-36038-001_N.docx
The ring indicator icon will take precedence over the RTLS icon, i.e.
the new icon will not be visible while the handset is ringing. When
ringing has ceased and the ring indicator becomes inactive, the RTLS
icon will again appear (regardless of hook state).
Allows selection of
Transmit interval
, or for maximum time between transmit intervals.
minutes 10 minutes
Default transmit interval is 10 minutes. Press
desired transmit interval.
To optimize battery life, the interval between sending out ELP
updates will vary based on handset state. It is expected that ELP
updates will occur at most every two to six seconds and at least
every few minutes. If improved tracking capability is desired, set the
transmit interval for a shorter time between ELP updates. Increasing
the frequency of transmissions will decrease battery life.
Allows the user to statically enter the IP address of
Location Server IP
the EPE. Enter the IP address and press
Ekahau clients are not expected to find the EPE automatically.
Regardless of the handset's selection of DHCP or static IP, the EPE
IP address must be statically entered in the Ekahau Admin menus
or HAT.
Allows the user to select the port number which ELP updates
ELP Port
get sent to at the Location Server IP address. It must match the value
configured in the Ekahau Positioning Engine for proper functionality.
The ELP port number must be greater than zero and less than 65536.
Default is 8552. Enter the port number and press
SNMP Settings
The SNMP option is designed for system administrator use when
troubleshooting.
If the SNMP IP address is set, only SNMP queries from this address
will be accepted. SNMP Community string. For complete information
about these SNMP values, see Chapter 9, the SNMP section.
IP Addresses
There are two modes in which the handset can operate: DHCP-
enabled or Static IP. Select the mode for operation from the IP
Address menu:
Configure Each SpectraLink Wireless Telephone
,
15 seconds 30 seconds
to select the
NavOK
to save.
NavOK
NavOK
, ,
1 minute 5
to save.
