SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
Parameter name in version 1 mode
None
None
LINEn_AUTH (n=1-5)⁵
LINEn_AUTH (n=1-5)⁵
CALL_LOGGING
152
Parameter name in version 2 mode
SIP_LINEn_PROXY (n=1-5)
SIP_LINEn_SECONDARY_PROXY (n=1-5)
SIP_LINEn_USERNAME (n=1-5)
SIP_LINEn_PASSWORD (n=1-5)
CALL_LOG_ENABLE
Version 1 vs. Version 2 Parameter Names Notes
1. The proxy server and port (optional) are specified together on
the version 1 parameter PROXYn_ADDR. For version 2 config,
these are specified on the two different parameters shown.
2. The failover proxy server and port (optional) are specified
together on the version 1 parameter PROXY1_FAILOVERIP.
For version 2 config, these are specified on the two different
parameters shown.
3. The conference proxy server and port (optional) are specified
together on the version 1 parameter
PROXYn_CONF_IP_ADDRESS. For version 2 config, these are
specified on the two different parameters shown.
4. In version 1 mode, up to 15 FAVORITE parameters can be
specified (on different lines). In version 2 mode, the
information for 15 favorites can be specified on one line with
the SIP_FAVORITES parameter.
5. In version 1, the line username and password were specified
together on the LINEn_AUTH parameter. In version 2
configuration mode these are specified separately.
PN: 1725-36038-001_N.docx
