Polycom SpectraLink 1725-36038-001 Administration Manual page 46

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
46
provide more credentials for authentication when more than one
line is defined.
SIP_PASSWORD (1-6): as above.
SIP_LINE (1-5): up to five lines may be identified.
SIP_LINE_CALLID (1-5): a different caller ID may be set for each
line.
SIP_FAVORITES: up to 15 Favorites are allowed. These should be
specified in the generic configuration file or the phone specific file
but not both, as the parameter in the phone specific file will
override the same parameter in the generic file.
Sample user specific file
This sample file has all six usernames and passwords defined. It has
all five lines defined and each line has a defined caller ID. Two
Favorites are defined. See the settings.txt file for information on
allowed characters and other parameter possibilities.
The name of the file is SIP_USERNAME1.txt.
SET SIP_USERNAME1 "1234"
SET SIP_PASSWORD1 "1234"
SET SIP_USERNAME2 "1245"
SET SIP_PASSWORD2 "1245"
SET SIP_USERNAME3 "1256"
SET SIP_PASSWORD3 "1256"
SET SIP_USERNAME4 "1267"
SET SIP_PASSWORD4 "1267"
SET SIP_USERNAME5 "1278"
SET SIP_PASSWORD5 "1278"
SET SIP_USERNAME6 "1289"
SET SIP_PASSWORD6 "1289"
##
SET SIP_LINE1 "1234"
SET SIP_LINE2 "1234"
SET SIP_LINE3 "1234"
SET SIP_LINE4 "1234"
SET SIP_LINE5 "1234"
##
SET SIP_LINE_CALLID1 "1234 Andy"
SET SIP_LINE_CALLID2 "1234 Andy"
SET SIP_LINE_CALLID3 "1234 Andy"
SET SIP_LINE_CALLID4 "1245 Pamela"
SET SIP_LINE_CALLID5 "1256 Paul"
##
SET SIP_FAVORITES 1231;"Favorite1",123;"Favorite2"
PN: 1725-36038-001_N.docx
