Introduction

This guide covers the installation, operation, and configuration of the Extron PVS 407D
PoleVault Switcher. Throughout the guide, this switcher is interchangeably referred to as
the "PVS 407D" or the "PoleVault switcher" or the "switcher".
NOTE: In this guide, where used, the generic term "12 VDC power supply", refers to

PVS 407D Description

The Extron PVS 407D is part of the PoleVault System and is used in conjunction with the
Extron PVT series of transmitters and Extron speakers. It has four video and audio twisted
pair inputs, two HDMI inputs, and one HDMI output, and incorporates a built-in audio
amplifier. The switcher accepts a combination of up to six HDMI digital signals, four of
which can be computer video signals with stereo audio, and supports up to two analog
VGA signals on the wallplates.
A seventh input is a switchable analog audio-only input for line-level audio such as an
Apple iPod
always active, and it is independent of the switchable audio inputs (1-7).
As part of the Extron PoleVault system, the PVS 407D can be installed above a
suspended ceiling in the Extron PVM 220 plenum rated enclosure, or installed at ceiling
level within the Extron PMK 560 Pole Mount Kit. Alternatively it can be mounted in either
the Extron WMK 160 or USFM 100 wall mount kits that can be installed on a wall close to
a projector or display device.
The PVS 407D switcher is used in conjunction with the Extron digital PVT wallplates,
(such as the PVT HD RGB), and the VoiceLift microphone system. It is equipped with an
integrated 50 watt RMS stereo amplifier capable of driving 4 or 8 ohm speakers.
The switcher supports all standard single link HDMI 1.4 signals at resolutions up to
4096x2160 at 30 Hz with 4:4:4 chroma sampling, and data rates up to 10.2 Gbps. The
switcher and the PVT wallplates feature EDID Minder technology, which automatically
manages the EDID information between the display device and each HDMI and RGB
input source.
The switcher has DSP audio processing incorporated that provides advanced control of
ducking and other audio features.
The switcher is also equipped with Ethernet control via the rear panel LAN ports, and
supports audio file playback for pre-recorded announcements.
The PVS 407D is ENERGY STAR
that conserves energy and reduces running costs.
either the 12 VDC, 48 Watt 4 Amp power supply, or the 12 VDC, 50 Watt, 4.2 Amp
power supply ONLY, as supplied by Extron.
or MP3 player. The dedicated auxiliary (Aux) mixed input on rear panel is
®
qualified. The switcher is an energy efficient product
®
PVS 407D Switcher • Introduction 1
