Paging Sensitivity Adjustment

When the Priority Page Sensor is connected to the Priority sensor input on the rear panel,
the HDMI output audio, amplified and line out audio outputs are muted during a system
announcement. The amber LED indicator lights when an announcement or page is made
over the facility PA system.
The PPS 25 Priority Page Sensor works with 25 V/70 V and 4/8 ohms paging systems.
The PPS 35 Priority Page Sensor works with any public address system speakers.
To adjust paging sensitivity, use the
decrease sensitivity.
INPUT
Figure 11.
Paging sensor hold time
configuration software. The default = 3 (enabled).
NOTE: The Paging Sensor port must be enabled in order to operate fully.
The paging sensor hold time can be set via SIS or configuration software to ensure
the amplified and line out audio outputs stay muted for a specific duration after an
announcement or page is finished. This is to prevent the audio being un-muted if the
announcer pauses or stops talking while making the announcement or page.
Paging Sensor
AUDIO LEVEL ADJUST
PAGING
VOICELIFT
SENSOR
PEAK PEAK
NORMAL NORMAL
SIGNAL SIGNAL
Front Panel Paging Sensor Min/Max LED and Adjustment Buttons
(1-8, in 1 second steps, 0 = disabled) can be set via SIS or
sensitivity buttons to increase or
LED lights
during announcement
or page.
PVS 407D Switcher • Operation 17
