Connect and Apply — Connects to a device (via an existing USB connection, TCP/IP, or
Pass-thru via MLC connection) and applies the current PCS configuration.
Deploy Configuration to Device(s) — Connects and deploys current configuration to
multiple devices simultaneously (see
Disconnect — Disconnects from a connected device.
Settings — This opens to two submenus:
• Hardware Settings — Opens the Hardware Settings window that accesses a
read-only Unit Information page and a Device Name option page.
Communication Settings — Opens the Communication Settings window
•
that allows the user to change the settings for the TCP/IP connection to the device.
Reset Device — Allows the user to reset the device.
Update Firmware — Opens to two submenus to start the update process for either this
device or multiple devices.
NOTE:
Firmware options are disabled until the device is connected.
PVS 407D Help File — Opens the device specific Help file. This file opens in a browser
and has an embedded PDF file for printing if desired.
About This Module — Opens an information box with module name, version number,
and compatible devices details.
For details of these menus see the PVS 407D Help file.

Connect to a Device

To connect to the device or re-establish the connection:
1. From the device menu, select Connect.... The Connect dialog box opens.
Figure 19.
Deploy Configuration to Devices
If a device is not connected, the Disconnect, Reset, and Update
Connect Dialog Box
PVS 407D • Using Extron Product Configuration Software
for details).
