Environmental; Physical - Comtech EF Data LPOD Installation And Operation Manual

LPOD Outdoor Amplifier / Block Up Converter (BUC)
Introduction
1.5.4

Environmental

Temperature
Humidity
Altitude
Shock
1.5.5

Physical

Weight
Dimensions
(excluding connectors)
See Sect. 1.6 for all
dimensional envelope
figures
Connectors
Standard -40º to 122ºF (-40º to 55ºC)
Operating
Optional
-40º to 140ºF (-40º to 60ºC)
Storage
-67º to 167ºF (-55º to 75ºC)
100% condensing rain 2" per hour
10,000 AMSL
Normal commercial shipping and handling
PS 1
17 lbs. (9.1 kg) Nominal
PS 1.5
PS 2 47 lbs (21.32 kg) Nominal
12.65 x 6.26 x 7.37 in.
PS 1
(321.3 x 159 x 187.2 mm)
12.78 x 6.14 x 7.05 in.
PS 1.5
(324.6 x 156 x 179.1 mm)
16.18 x 8.80 x 9.78 x in.
PS 2
(427 x 223.5 x 248.4 mm)
IF/RF Input Type 'N' Female
C-Band / X-band: Type 'N' Female (standard), CPR137G
PS 1 (optional)
Ku-Band: WR75G
C-Band: CPR137G
RF Output PS 1.5 X-Band: CPR112G
Ku-Band: WR75G
C-Band: CPR137G
PS 2
X-Band: CPR112G
Ku-Band: WR75G
LNB Bias
Type 'N' Female
M&C/Ethernet/ 19-pin MS style (single integrated cable assembly available,
Redundancy Switches
dependent upon configuration)
1–10
Revision 9
MN-LPOD
