installation
Wall Board/Drywall Installation CV40E/CB40E
WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as speciied.
Finishing Instructions
It is important to follow the framing and inishing instructions to ensure proper placement of ireplace into the surrounding framing/inishing materials.
Wall board materials 1/2 in. thick are speciied in this installation manual to properly align with the optional inishing methods offered with this appliance. The
CV40E/CB40E may be inished to the appliance opening with 1/2 inch thick drywall.
• Ensure that the back and side clearances are maintained.
WARNING! Risk of Fire! Maintain speciied air space clearances to combustibles. Inadequate air space could cause overheating and ire.
DO NOT use screws more than 3/4 inch in length on the lower access cover panel. Longer screws may penetrate gas line or damage valve or electrical
components.
Note: It is acceptable to use a high temperature silicone sealant to adhere drywall to lower access cover panel.
The appliance is designed to be used with 1/2 in. wall sheathing materials such as drywall, plywood, wood composites, or non-combustible materials.
Thicker materials may be used. Refer to facing and inishing details in this manual.
Facing Material
• Facing and/or inishing materials must never overhang into the glass opening.
• Facing materials may be combustible or non-combustible
WARNING! Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Comply with all minimum clearances to combustibles as
speciied in this manual. Overlapping materials could ignite and will interfere with proper operation.
PAINTING
If desired inishing includes a painted wall, 100% acrylic latex, oil-based or standard acrylic paints may be used.
Follow paint manufacturer's instructions for paint and primer application.
4"
102mm
38
| City Series
5
3"
20
"
16
76mm
515mm
CV40E
3"
76mm
CB40E
3RD ANGLE
TOLERANCES UNLESS
PROJECTION
OTHERWISE STATED
±1°
ANGULAR =
DIMENSIONS =
±0.031
INSIDE BEND RADII =
DO NOT
UNITS IN INCHES
SCALE
656-533
PART
NO.
MODEL #
QTY.
THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT.
SCREWS ONLY IN SHADED AREA
4"
102mm
FIREPLACE PRODUCTS INTERNATIONAL
PART :
CITY 40 3 SIDED FULL ASSEMBLY
DWN
MAT'L :
-
BLANK SIZE :
SEE ABOVE
CHK
PROCESS :
REV.
C.N.
SIGN
DATE
SCALE:
C
CURRENT REVISION
PREVIOUS REVISION
3
1
"
16
30mm
7
"
8
22mm
SL
04/19/2016
SHEAR/ PUNCH/ FORM
1:16
656-533
