Regency CV40E-NG Owners & Installation Manual page 7

CV40E (single sided) dimensions
Ø 6 3 4 "
171mm
Ø 4"
102mm
43 9 16 "
1107mm
46 1 4 "
1175mm
38 13 16 "
986mm
1091mm
Dimensions will appear as (inches)" / (metric)mm
throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy
is required, use the metric dimensions.
21 7 8 "
556mm
43"
dimensions
18 11 16 "
475mm
17 11 16 "
449mm
City Series | 7
