installation
Mantel Clearances CV40E Single sided / CB40E 3 sided
Combustible mantel clearances from top of front facing
are shown in the diagram on the right.
Mantel Leg Clearances
Combustible mantel leg clearances as per diagram:
CV40E (single sided)
MANTEL LEG
Allowable mantel
leg projection
8-1/2"
16
| City Series
14
12
10
8
6
4
2
26
20
10
12" (305mm)
2"
0
To Unit
25-9/16"
Top of
Base
Fireplace
Opening
CB40E (3 sided)
MANTEL LEG
8-1/2"
Drywall, wood, wood panel, etc.
Combustible Material
Wood Stud
(On Edge)
Standoff
9"
