operating instructions
First Fire
The FIRST FIRE in your ireplace is part of the
paint curing process. To ensure the paint is prop-
erly cured, it is recommended you burn your
ireplace for at least four (4) hours the irst time.
When irst operated, the unit will release an
odour caused by the curing of the paint and the
burning off of any oils remaining from manufac-
turing. Smoke detectors in the house may go off
at this time. Open a few windows to ventilate
the room for a couple of hours. The glass may
require cleaning.
NOTE: When the glass is cold and the
appliance is lit, it may cause con-
densation and fog the glass. This
condensation is normal and will
disappear in a few minutes as the
glass heats up.
DO NOT ATTEMPT TO CLEAN THE
GLASS WHILE IT IS STILL HOT !
DO NOT BURN THE UNIT WITHOUT THE
GLASS IN PLACE.
During the irst few ires, a white ilm
may develop on the glass front as part of
the curing process. The glass should be
cleaned after the unit has cooled down
or the ilm will bake on and become very
dificult to remove. Use a non-abrasive
cleaner and DO NOT ATTEMPT TO CLEAN
THE GLASS WHILE IT IS HOT.
78
| City Series
Normal Operating Sounds Of
Gas Appliances
It is possible that you will hear some sounds from
your gas appliance. This is perfectly normal due to
the fact that there are various gauges and types
of steel used within your appliance. Listed below
are some examples. All are normal operating
sounds and should not be considered as defects
in your appliance.
Burner Tray:
The burner tray is positioned directly under the
burner tube(s) media and logs and is made of a
different gauge material from the rest of the irebox
and body. Therefore, the varying thicknesses of
steel will expand and contract at slightly different
rates which can cause "ticking" and "cracking"
sounds. You should also be aware that as there
are temperature changes within the unit these
sounds will likely re-occur. Again, this is normal
for steel ireboxes.
Pilot Flame:
While the pilot lame is on it can make a very slight
"whisper" sound.
Gas Control Valve:
As the gas control valve turns ON and OFF, a
dull clicking sound may be audible, this is normal
operation of a gas regulator or valve.
Unit Body/Firebox:
Different types and thicknesses of steel will expand
and contract at different rates resulting in some
"cracking" and "ticking" sounds will be heard
throughout the cycling process.
Aeration Adjustment
The burner aeration is factory set but may need
adjusting due to either the local gas supply or
altitude. Open the air shutter for a blue lame or
close for a more yellow lame.
Remove outer safety glass and inner glass panels
plus outer and inner base panels - see instructions
in this manual.
1. Remove burner tray by lifting up and out.
CB40E shown
2. Loosen 4 screws in locations shown below (2 at front
and 2 at rear)—slide burner to the left away from the
oriice and lift out.
front
screw locations
back screw locations
CB40E shown
3. Reverse steps to reinstall burner.
Minimum Air Shutter Opening:
NG
Fully closed
NG with Logs
Fully closed
NG with Stones
Fully closed
LP
1/4"
LP with Logs
1/4"
LP with Stones
1/4"
Note: Any damage due to carboning
resulting from improperly setting
the aeration controls is NOT covered
under warranty.
