Regency CV40E-NG Owners & Installation Manual page 8

dimensions
CB40E (3 sided) dimensions
Ø 6 3 4 "
171mm
Ø 4"
102mm
Dimensions will appear as (inches)" / (metric)mm
throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy
is required, use the metric dimensions.
8 | City Series
48 7 16 "
1231mm
24 1 4 "
616mm
49 5 8 "
1261mm
48 7 16 "
1231mm
47"
1194mm
43"
1091mm
18 11 16 "
475mm
17 11 16 "
449mm
