PARAMETER MEASUREMENT INFORMATION (CONTINUED)
AC transient rise/fall time specifications
Figure 19 and Figure 20 show the AC transient specifications for Rise and Fall Time. For device-specific
information on these values, refer to the Recommended Operating Conditions section of this Data Sheet.
t = 0.3 t c (max) †
Ground
† t c = the peripheral cycle time.
V US (max)
† t c = the peripheral cycle time.
FLOATING POINT DIGITAL SIGNAL PROCESSOR
Minimum
Risetime
Waveform
Valid Region
Figure 19. AC Transient Specification Rise Time
Figure 20. AC Transient Specification Fall Time
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251−1443
SPRS292A − OCTOBER 2005 − REVISED NOVEMBER 2005
V OS (max)
V IH (min)
t = 0.3 t c (max) †
V IL (max)
Ground
TMS320C6711D
65
