31
15 14
Enable or
Reserved Non-Enabled
Interrupt Wake
R/W-0 R/W-0
7
Legend: R/W−x = Read/write reset value
NOTE: The shadowed bits are not part of the power-down logic discussion and therefore are not covered here. For information on these other
bit fields in the CSR register, see the TMS320C6000 CPU and Instruction Set Reference Guide (literature number SPRU189).
A delay of up to nine clock cycles may occur after the instruction that sets the PWRD bits in the CSR before the
PD mode takes effect. As best practice, NOPs should be padded after the PWRD bits are set in the CSR to account
for this delay.
If PD1 mode is terminated by a non-enabled interrupt, the program execution returns to the instruction where PD1
took effect. If PD1 mode is terminated by an enabled interrupt, the interrupt service routine will be executed first,
then the program execution returns to the instruction where PD1 took effect. In the case with an enabled interrupt,
the GIE bit in the CSR and the NMIE bit in the interrupt enable register (IER) must also be set in order for the
interrupt service routine to execute; otherwise, execution returns to the instruction where PD1 took effect upon
PD1 mode termination by an enabled interrupt.
PD2 and PD3 modes can only be aborted by device reset. Table 33 summarizes all the power-down modes.
FLOATING POINT DIGITAL SIGNAL PROCESSOR
13 12
Enabled
PD3
Interrupt Wake
R/W-0 R/W-0
Figure 12. PWRD Field of the CSR Register
•
