TMS320C6711D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS292A − OCTOBER 2005 − REVISED NOVEMBER 2005
PLL and PLL controller (continued)
OSCDIV1 Register (0x01B7 C124)
28 27
31
14
15
12 11
OD1EN
R/W−1
Legend: R = Read only, R/W = Read/Write; -n = value after reset
The OSCDIV1 register controls the oscillator divider 1 for CLKOUT3. The CLKOUT3 signal does not go through
the PLL path.
BIT #
NAME
31:16
Reserved
15
OD1EN
14:5
Reserved
4:0
OSCDIV1
52
24 23
Reserved
R−0
8
7
Reserved
R−0
Table 32. Oscillator Divider 1 Register (OSCDIV1)
Reserved. Read-only, writes have no effect.
Oscillator Divider 1 Enable.
0 – Oscillator Divider 1 Disabled.
1 – Oscillator Divider 1 Enabled (default).
Reserved. Read-only, writes have no effect.
Oscillator Divider 1 Ratio [default is /8 (0 0111)].
00000 =
/1
10000 =
00001 =
/2
10001 =
00010 =
/3
10010 =
00011 =
/4
10011 =
00100 =
/5
10100 =
00101 =
/6
10101 =
00110 =
/7
10110 =
00111 =
/8
10111 =
01000 =
/9
11000 =
01001 =
/10
11001 =
01010 =
/11
11010 =
01011 =
/12
11011 =
01100 =
/13
11100 =
01101 =
/14
11101 =
01110 =
/15
11110
01111
=
/16
11111
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251−1443
20 19
5
4
3
DESCRIPTION
/17
/18
/19
/20
/21
/22
/23
/24
/25
/26
/27
/28
/29
/30
=
/31
=
/32
16
2
1
0
OSCDIV1
R/W−0 0111
