CHAPTER 12

Installing the Switch

Installing and Connecting an EX4200 Switch

Copyright © 2015, Juniper Networks, Inc.
Installing and Connecting an EX4200 Switch on page 157
Mounting an EX4200 Switch on page 158
Mounting an EX4200 Switch on a Desk or Other Level Surface on page 159
Mounting an EX4200 Switch on Two Posts in a Rack or Cabinet on page 160
Mounting an EX4200 Switch on Four Posts in a Rack or Cabinet on page 163
Mounting an EX4200 Switch in a Recessed Position in a Rack or Cabinet on page 166
Mounting an EX4200 Switch on a Wall on page 167
Installing and Removing EX4200 Switch Hardware Components on page 169
The EX4200 switch chassis is a rigid sheet-metal structure that houses the hardware
components.
To install and connect an EX4200 switch:
Follow instructions in "Unpacking an EX4200 Switch" on page
1.
Install a power supply if it is not pre-installed; see
2.
EX4200 Switch" on page
Install a fan tray if it is not pre-installed; see
3.
on page 207.
Mount the switch by following instructions appropriate for your site:
4.
"Mounting an EX4200 Switch on Two Posts in a Rack or Cabinet" on page 160
the mounting brackets provided)
"Mounting an EX4200 Switch on Four Posts in a Rack or Cabinet" on page 163
the separately orderable four-post rack-mount kit)
"Mounting an EX4200 Switch in a Recessed Position in a Rack or Cabinet" on page 166
(using the 2-in.-recess front brackets from the separately orderable four-post
rack-mount kit)
"Installing a Power Supply in an
211.
"Installing a Fan Tray in an EX4200 Switch"
153.
(using
(using
157
