EX4200 Switch Hardware Guide
Table 50: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)
Pin Number
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
140
Pin Name
P1RXP3
P1RXN3
GND
NC
NC
NC
NC
NC
NC
NC
NC
GND
P2RXP0
P2RXN0
GND
P2RXP1
P2RXN1
GND
P2RXP2
P2RXN2
GND
P2RXP3
P2RXN3
GND
Copyright © 2015, Juniper Networks, Inc.
