EX4200 Switch Models

Table 3: EX4200 Switch Models

Number and Type of
Model Ports
EX4200-24T 24 Gigabit Ethernet
EX4200-24T-DC 24 Gigabit Ethernet
EX4200-24P 24 Gigabit Ethernet
EX4200-24PX 24 Gigabit Ethernet
EX4200-24F 24 small form-factor
pluggable (SFP)
Copyright © 2015, Juniper Networks, Inc.
IEEE 802.3at, defined PoE+. An IEEE 802.3af powered device operates normally when
connected to an IEEE 802.3at (PoE+) power sourcing equipment.
EX4200 switches with an AC power supply installed have options of full (all 24 or 48
ports) PoE/PoE+ capability or partial (8 ports) PoE capability. EX4200 switches with a
DC power supply installed do not provide PoE. For more information, see
Models" on page 5.
Full PoE/PoE+ models are primarily used in IP telephony environments. Partial PoE
models are used in environments where, for example, only a few ports for wireless access
points or security cameras are required.
EX4200 Switch Models on page 5
Field-Replaceable Units in EX4200 Switches on page 10
Site Preparation Checklist for EX4200 Switches on page 61
Understanding PoE on EX Series Switches
The EX4200 switch is available with 24 or 48 ports and with partial or full Power over
Ethernet (PoE) capability. EX4200 switches with a DC power supply installed do not
provide PoE.
NOTE: This topic uses the term PoE to refer to both PoE and PoE+ unless
there is a need to distinguish between the two.
Table 3 on page 5 lists the EX4200 switch models.
Number of
PoE-enabled Ports
First 8 ports
–
All 24 ports
All 24 ports (PoE+)
–
Power Supply
Fan Tray (Minimum)
One fan tray with 320 W
three fans.
One fan tray with 190 W
three fans.
One fan tray with 600 W
three fans.
One fan tray with 930 W
three fans.
One fan tray with 320 W
three fans.
Chapter 1: System Overview
"EX4200 Switch
Junos OS
Release
Required
9.0R2 or later
9.0R2 or later
9.0R2 or later
11.2R1 or later
9.0R2 or later
5
