EX4200 Switch Hardware Guide
Table 49: Uplink Modules Connector Pinout Information (continued)
Pin Number
G19
G20
H1
H2
H3
H4
H5
H6
H7
H8
H9
H10
H11
H12
H13
H14
H15
H16
H17
H18
H19
H20
I1
I2
136
Pin Name
POWER (12V)
GND
Uplink_PD_Loopback
GND
XAUI0_RX1P
GND
XAUI0_RX3P
Uplink_P26_ LED2
XAUI1_RX1P
Uplink_P28_ LED2
XAUI1_RX3P
GND
SRX27P
Uplink_XAUI_MDC
SRX25P
GND
Serial_RX
GND
Uplink_P25_LED1
Uplink_P28_LED0
POWER (12V)
POWER (12V)
GND
GND
Copyright © 2015, Juniper Networks, Inc.
