Connecting DC Power to an EX4200 Switch
Copyright © 2015, Juniper Networks, Inc.
Figure 41: Connecting the AC Power Cord Retainer Clip to an AC Power
Supply in an EX4200 Switch
Figure 42: Connecting an AC Power Cord to an AC Power Supply in an
EX4200 Switch
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 195
Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 198
Connecting DC Power to an EX4200 Switch on page 179
Power Supply in EX4200 Switches on page 33
AC Power Supply LEDs in EX4200 Switches on page 37
The power supply in an EX4200 switch is a hot-removable and hot-insertable
field-replaceable unit (FRU) located on the rear panel: You can remove and replace it
without powering off the switch or disrupting switch functions.
Figure 43: DC Power Supply in an EX4200 Switch
Chapter 13: Connecting the Switch to Power
