LCD Panel Menus

Table 6: LCD Panel Menu Options

Menu Description
IDLE In the Idle menu:
Press Enter
SPD (speed)
ADM (administrative status)
DPX (duplex)
POE (Power over Ethernet)
See Network Port LEDs in EX3200 Switches or
information on the Status LED modes.
Press
Menu
Copyright © 2015, Juniper Networks, Inc.
In the maintenance mode, the second line displays one of the following options that you
can use to configure and troubleshoot the switch:
System halt
System reboot
Load rescue
Request VC port (for an EX4200 switch that is a member of a Virtual Chassis)
Factory default
System EZSetup
The LCD panel has three menus: Idle, Status, and Maintenance. Toggle between the LCD
panel menus by pressing the
the Enter button.
Table 6 on page 15 describes the LCD panel menu options.
to cycle through the Status LED modes:
to exit the Idle menu and go to the Status menu.
Chapter 2: Chassis Components and Descriptions
button. Navigate through the menu options by pressing
Menu
"Network Port LEDs in EX4200 Switches" on page 24 for
15
