Uplink Modules Connector Pinout Information for EX4200 Switches

Table 49: Uplink Modules Connector Pinout Information

Pin Number
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
130
EX4200 switches have a field-replaceable unit (FRU) uplink module on the front panel.
Table 49 on page 130 provides the uplink modules connector pinout information.
NOTE: You can use these ports to connect an access switch to a distribution
switch. You can also use optional uplink module ports to connect members
of a Virtual Chassis across multiple wiring closets.
Pin Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Uplink_I2C_SCK
GND
Uplink_PD
GND
