Mounting an EX4200 Switch on a Desk or Other Level Surface

Copyright © 2015, Juniper Networks, Inc.
See the Related Documentation for detailed descriptions of the various rack or cabinet
mounting options.
Mounting an EX4200 Switch on Two Posts in a Rack or Cabinet on page 160
Mounting an EX4200 Switch on Four Posts in a Rack or Cabinet on page 163
Mounting an EX4200 Switch in a Recessed Position in a Rack or Cabinet on page 166
Mounting an EX4200 Switch on a Desk or Other Level Surface on page 159
Mounting an EX4200 Switch on a Wall on page 167
Connecting Earth Ground to an EX Series Switch on page 171
You can mount an EX4200 switch on a desk or other level surface by using the 4 rubber
feet that are shipped with the switch. The rubber feet stabilize the chassis.
Before mounting an EX4200 switch on a desk or other level surface:
Verify that the site meets the requirements described in
for EX4200 Switches" on page
Place the desk in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
Read "General Safety Guidelines and Warnings" on page
to "Chassis Lifting Guidelines for EX4200 Switches" on page
Remove the switch from the shipping carton (see
page 153).
Ensure that you have the following parts and tools available:
4 rubber feet to stabilize the chassis on the a desk or other level surface (provided in
the accessory box shipped with the switch)
Dust covers for ports (for EX4200-24F switches only; optional)
To mount the switch on a desk or other level surface:
Turn the chassis upside down on the desk or the level surface where you intend to
1.
mount the switch.
Attach the rubber feet to the bottom of the chassis, as shown in
2.
Turn the chassis right side up on the desk or the level surface.
3.
If it is an EX4200-24F switch, we recommend you insert dust covers in unused SFP
4.
ports.
"Site Preparation Checklist
61.
267, with particular attention
"Unpacking an EX4200 Switch" on
Chapter 12: Installing the Switch
277.
Figure 30 on page 160.
