EX4200 Switch Hardware Guide
Table 44: SFP+ Direct Attach Cable Specifications (continued)
Model Number
EX-SFP-10GE-DAC-7M

Standards Supported by These Cables

Related
Documentation

Network Cable Specifications for EX4200 Switches

122
Specification
Rate
Connector type
Supply voltage
Power consumption (per end)
Storage temperature
Cable type
Wire AWG
Minimum cable bend radius
Cable characteristic impedance
Crosstalk between pairs
Time delay
Length
The cables comply with the following standards:
SFP mechanical standard SFF-843—see
Electrical interface standard SFF-8432—see
SFP+ Multi-Source Alliance (MSA) standards.
Pluggable Transceivers Supported on EX Series Switches
Installing a Transceiver in an EX Series Switch on page 221
Removing a Transceiver from a Switch on page 223
EX4200 switches have interfaces that use various types of network cables.
For instructions on connecting an EX4200 switch to a network for out-of-band
management using an Ethernet cable with an RJ-45 connector, see
to a Network for Out-of-Band Management" on page
Value
10-Gbps full-duplex serial transmission
SFP+ passive Twinax cable assembly
3.3 V
0.57 W
° °
–40 C through 85 C
Twinax
24 AWG
1 in. (2.54 cm)
100 ohms
2% maximum
1.31 nsec/ft
23 ft (7 m)
ftp://ftp.seagate.com/sff/SFF-8431.PDF
ftp://ftp.seagate.com/sff/SFF-8432.PDF
"Connecting a Switch
185.
