Table 47: Network Port Connector Pinout Information (continued)
Pin
6
7
8
Related
Documentation

RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch

Related
Documentation
Copyright © 2015, Juniper Networks, Inc.
Signal
TRP2-
TRP4+
TRP4-
Front Panel of an EX4200 Switch on page 11
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect
to a management device such as a PC or a laptop. If your laptop or PC does not have a
DB-9 male connector pin and you want to connect your laptop or PC to the switch, use
a combination of the RJ-45 to DB-9 female adapter supplied with the switch along with
a USB to DB-9 male adapter.
Table 48 on page 129 provides the pinout information for the RJ-45 to DB-9 serial port
adapter.

Table 48: RJ-45 to DB-9 Serial Port Adapter Pinout Information

RJ-45 Pin Signal
1 RTS
2 DTR
3 TXD
4 GND
6 RXD
7 DSR
8 CTS
Connecting a Switch to a Management Console on page 187
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 195
Connecting an EX9200 Switch to a Management Console or an Auxiliary Device
Connecting and Configuring an EX9200 Switch (CLI Procedure)
Connecting and Configuring an OCX1100 Switch (CLI Procedure)
Chapter 9: Pinout Specifications
Description
Transmit/receive data pair 2
Positive Vport (in PoE models)
Transmit/receive data pair 4
Transmit/receive data pair 4
DB-9 Pin Signal
8 CTS
6 DSR
2 RXD
5 GND
3 TXD
4 DTR
7 RTS
129
