Figure 65: Virtual Chassis Cable Connector in an EX4200 Switch

NOTE: If you order Virtual Chassis cables separately, you must reuse the
cable connector retainers provided with the original cable or order Virtual
Chassis cable connector retainers also separately.
Connecting a Virtual Chassis Cable to an EX4200 Switch on page 241
Understanding EX4200, EX4500, and EX4550 Virtual Chassis Hardware Configurations
on page 143
Understanding EX Series Virtual Chassis Components
Planning EX4200, EX4500, and EX4550 Virtual Chassis on page 146
Virtual Chassis Ports Connector Pinout Information for EX4200 Switches on page 138
Chapter 22: Maintaining and Replacing Virtual Chassis Cable
Virtual Chassis cable connector
Release pull tab
Cable connector retainer
