EX4200 Switch Hardware Guide

Switch Role and Member ID on the LCD Panel

Related
Documentation

Planning EX4200, EX4500, and EX4550 Virtual Chassis

Table 55: Virtual Chassis Components to Consider When Planning an EX4200, EX4500, and
EX4550 Virtual Chassis
Virtual Chassis Components
EX4200 switches only
EX4500 switches only
EX4550 switches only
146
For each switch in the Virtual Chassis, the LCD panel of the switch displays:
Role of the switch— for master,
RE
Member ID for the Virtual Chassis member—A number in the range 0 through 9
Understanding EX Series Virtual Chassis Components
Planning EX4200, EX4500, and EX4550 Virtual Chassis on page 146
EX Series Virtual Chassis Overview
Before interconnecting EX4200, EX4500, and EX4550 switches in a Virtual Chassis
configuration:
Verify that the rack in which you will install the switches meets the requirements
described in "Rack Requirements for EX4200 Switches" on page
for EX4500 Switches, and Rack Requirements for EX4550 Switches. You can mount
the switches in a Virtual Chassis on a single rack or on multiple racks.
Verify that the installation site meets the power requirements of the switches in a
Virtual Chassis.
Verify that you have installed a Virtual Chassis module in an EX4500 switch running
Junos OS releases earlier than Release 11.4R1. The Virtual Chassis module must be
installed in an EX4500 switch to form a Virtual Chassis.
Table 55 on page 146 describes the Virtual Chassis components and the Junos OS release
running on switches that you need to consider when you plan your EX4200, EX4500,
and EX4550 Virtual Chassis configuration.
Junos OS Release Running
on the Member Switches
Junos OS Release 9.0 and later
Junos OS Releases 11.1, 11.2, and
11.3
Junos OS Release 11.4 or later
Junos OS Release 12.2 or later
for backup, and for linecard member
BK LC
Virtual Chassis Details
You can interconnect two to ten EX4200 switches to form
a Virtual Chassis composed exclusively of EX4200 switches.
You can interconnect two EX4500 switches into a Virtual
Chassis composed exclusively of EX4500 switches.
You can interconnect up to ten EX4500 switches into a
Virtual Chassis composed exclusively of EX4500 switches.
You can interconnect up to ten EX4550 switches into a Virtual
Chassis composed exclusively of EX4550 switches.
Copyright © 2015, Juniper Networks, Inc.
69, Rack Requirements
