CONTROL BOARD ADJUSTMENTS (cont)
The control board's lock output can be programmed for both hold
and pulse operation. In addition to this the lock output can be pro-
grammed to activate prior to the gate motor starting. The opera-
PARAMETER
OPEN LOCK TIME
Set the time the lock is activated for on open cycles
CLOSE LOCK TIME
Set the time the lock is activated for on close cycles
PRE-OPEN LOCK TIME
Time the lock is activated for prior to opening.
PRE-CLOSE LOCK TIME
Time the lock is activated for prior to closing
With the addition of a module which plugs into the control board,
the control board will control a light. The time the light stays on
for is controlled by two timers The first times the period the light
PARAMETER
ON AFTER CYCLE LIGHT TIME
Time light remains on for after a cycle
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing
MOTOR SPEED
The maximum speed the motors run at is controlled by the
MOTOR FULL SPEED VOLTAGE.parameter. The default value
is the maximum recommended for normal operation. If however
the gates move too quickly for a particular installation the voltage
can be reduced to cause the motors to run slower.
NOTE: Altering this parameters will cause the travel limits to
be cleared.
PARAMETER
MOTOR FULL SPEED VOLTAGE
Sets the full speed motor voltage
GATE LEAF SYNCHRONIZING DELAY
Set the # of turns delay between gates opening
EXTRA SYNCHRONIZING DELAY FOR CLOSE
Additional # turns delay between gates closing

MENU 4 LOCK TIMES

tion of the lock can be programmed to behave differently on open
cycle to that on close cycles. The parameters for adjustment are
shown below.
MIN MAX
0.0 HOLD
0.0 HOLD
0.0
0.0

MENU 5 LIGHT TIMES

is activated for prior to a drive cycle. This is used to warn that gate
movement is pending. The second timer time how long the light
remains on after a cycle. The parameters are shown below.
MIN MAX
0
0
0

MENU 6 MOTOR SETTINGS

GATE LEAF SYNCHRONIZING DELAYS
These parameters determine the minimum distance that is
maintained between the gates leaves when leaving or approaching
the closed position. If the speed of the gates differs considerable
then an extra delay can be introduced on closing to ensure that the
gates don't overlap (not relevant with sliding gates). The units
used are revolutions of the rack drive gear.
Note altering these parameters will cause the travels limits to
be cleared.
MIN MAX
~12.1
1
0
18
DEFAULT STEP UNITS MENU #
0.5
0.5
25.5 0.0
25.5 0.0
DEFAULT STEP UNITS MENU #
255 60
255 0
255 0
DEFAULT STEP UNITS MENU #
~22 ~20
5 2
5 1
0.1 SEC 4
0.1 SEC 4
0.1 SEC 4
0.1 SEC 4
1 SEC 5
1 SEC 5
1 SEC 5
~1 Volts 6
1 REVs 6
1 REVs 6
