CONTROL BOARD ADJUSTMENTS

The control board's standard operation is altered by editing various control parameters. This section describes the parameters
and the effect they have. Use the PARAMETER VIEWING AND EDITING PROCEDURE to access the parameters.
MARGINS
The obstruction margins are used to alter the sensitivity of the
controller to obstructions. Increasing the value increases the
PARAMETER
M1 MARGIN
Sets the obstruction detection margin for M1
M2 MARGIN
Sets the obstruction detection margin for M2
The auto-close modes automatically close the gate after it has been operated. To implement this, the controller starts a timer
once the gate has reached its desired open position. The timer then counts down and when it expires the controller starts to
close the gate. Details about the four auto-close modes follow.
STANDARD AUTO-CLOSE
This mode is selected by entering a non-zero time for the STD
Autoclose parameter. When selected the gate will auto-close after
being fully opened (except when the gate has reversed to the open
position after a motor obstruction or overload). Countdown is
suspended by: the P.E, OPN or SWP input being active. The
countdown is aborted if the STP input is activated. If the gate is
already open and the OPN or the SWP input is activated then the
countdown will start.
P.E TRIGGERED AUTO-CLOSE
This mode is selected by entering a non-zero time for the "P.E
Autoclose" parameter. This mode is used to auto-close the gate
but only after a vehicle have passed through the gateway and
triggered the P.E input. If the P.E input is selected to stop the gate
on activation then when the vehicle breaks the beam, the gate will
stop. When the beam is cleared the auto-close countdown will
start. The swipe input can be used to clear the P.E triggered status
so that the P.E input must be activated again before the countdown
will start. As with the other P.E modes the STP input will abort
countdown and the OPN and SWP inputs will restart the count-
down if the gate is OPEN.
PARAMETER
STD AUTOCLOSE TIME
Sets and enables the standard auto-close time.
P.E AUTOCLOSE TIME
Sets and enables the P.E triggered auto-close time.
PEDESTRIAN AUTOCLOSE TIME
Sets and enables the Pedestrian auto-close time.
P.E PEDESTRIAN AUTOCLOSE TIME
Sets and enables the PE Pedestrian auto-close time.

MENU 2 OBSTRUCTION MARGINS

MIN
0.0
0.0

MENU 3 AUTO-CLOSE TIMES

MIN
0.0
0.0
0.0
0.0
17
allowable variation between the "normal" speed profile and the
actual running speed.
MAX DEFAULT STEP UNITS MENU #
20.0 6.0
20.0 6.0
PEDESTRIAN ACCESS AUTO-CLOSE
This mode is selected by entering a non-zero time for the "Ped'n
A/C" parameter. When selected the gate will auto-close after
being opened for pedestrian access unless it was following a
reverse from an obstruction. The countdown is suspended if the
P.E input is active or if the PED input is active. The countdown is
aborted if the STP input is activated. If the gate is open for
pedestrian access and the "PED I/P = PED SWIPE MODE"
parameter is ON, then the count down will start.
P.E TRIGGERED PEDESTRIAN AUTO-CLOSE
This mode is selected by entering a non-zero time for the "P.E
Ped'n A/C" parameter.
triggered auto-close mode but it only operates during pedestrian
access. As the SWP input is not available during pedestrian
access, the PED input can be configured to act in a SWP mode by
setting the "PED I/P = PED SWIPE MODE" parameter to ON.
MAX DEFAULT STEP UNITS MENU #
300.0 0.0
300.0 0.0
300.0 0.0
300.0 0.0
0.5 RPM
0.5 RPM
This mode is the same as the P.E
1.0 SEC
1.0 SEC
1.0 SEC
1.0 SEC
2
2
3
3
3
3
