16. Technical Specification

16. Technical Specification
KBox C-101
Installed COM Express Module and
Baseboard
Processor
RAM
Internal Drive Bays
(from the outside not accessible)
or
External accessible Drive Bays (Option)
Options for Storage Media
BIOS
Interfaces
(front side accessible)
Free Expansions Slots
(internal)
Controls
(at the front side)
Indicators
(at the front side)
DC IN Connector (at the front side)
Protection Class
Rated Voltage (tolerance)
www.kontron.com
Baseboard with COMe-bHL6 i5-4402E or
Baseboard with COMe-bHL6 i7-4700EQ or
Baseboard with COMe-bHL6 Celeron® 2002E
i5-4402E: Dual-Core 1.6 GHz, 3MB cache, 37W max. power consumption,
i7-4700EQ: Quad-Core 2.4 GHz, 6MB cache, 47W max. power consumption,
Celeron® 2002E, Dual-Core 1.5 GHz, 2MB cache, 25W max. power consumption
Up to 16 GB
2x internal drive bays for non removable SATA
or
2x removable SATA drive bays
Up to 2x removable SATA HDD/SSD or up to 2x SATA HDD/SSD for:
• DRIVE 1: up to SATA 6 Gb/s.
• DRIVE 2: up to SATA 3 Gb/s.
Up to 2x mSATA
1x SD Card
Phoenix uEFI
3x Ehternet (10/100/1000 Mbit/s) with IEEE1588 support
2x USB 3.0
2x USB 2.0
1x DisplayPort
1x SD Card slot
1x RS232
Optional:
1x FIELDBUS (PROFIBUS or CAN BUS) free expansion slot (the expansion
have to be installed at the factory only)
2x full size Mini PCIe x1
2x PCIe x4 or 2x PCIe x1
(via Riser card) (power consumption less than 15W is allowed)
Power button (PWR)
RESCUE button (RSQ)
PWR (Power LED)
RSQ (Rescue LED)
THERM (Thermal LED)
DRIVE (HDD/SSD status LED)
SD (SD Card status LED)
WD (Watchdog status LED)
GP1 ... GP4 (General purpose LEDs)
3-pin DC input connector
IP20
24 VDC (+20%/-15%), 10ms hold-up
