10. Accessing Internal Components KBox C-101 – User's Guide (Version 2.00)

10.2.3. Installing an mSATA SSD

To have access to the mSATA slots please proceed according to the steps described:
1. Open the device as described in the subsection 10.2 "Opening and Closing the KBox C-101" (step 1-6).
2. Locate the mSATA slots and the corresponding fixing bolts. (Fig. 33, pos. 7 and 8).
3. Insert each mSATA SSD into the corresponding slot (Fig. 33, pos. 7) and rotate it down with the fixing holes of the
mSATA SSD over the fixing bolts (Fig. 33, pos. 8).
4. Press each mSATA SSD down on (the side with the fixing holes) until the mSATA SSD snaps in.
5. In order to close the KBox C-101, proceed in reverse order.
