7. System Overview
KBox C-101 – User's Guide (Version 2.00)
Fig. 3: Bottom side view
Fig. 4: Right side view
Fig. 5: Front side view config.
Fig. 6: Front side view config.
Fig. 7: Left side view
with removable drives
without removable drives
Fig. 8: Top side view
Fig. 9: Rear side view
www.kontron.com
17
