7.7.3. Expansion Slots for PCIe Mini Cards

Depending on the system configuration ordered your KBox C-101 can be extended with up to two PCIe Mini cards.
The KBox C-101 provides two internal Mini PCIe slots for PCIe Mini cards.
One of them you can see it in Fig. 27, pos. 4). The second Mini PCIe slot is on the bottom side of the
baseboard and can be only at the factory fitted with an expansion card.
For installation/removing of the PCIe Mini card (Fig. 27, pos. 4), please refer to the subsection 10.2.2
"Installing/Removing the PCIe Mini Card".

7.7.4. Expansion Slots for PCIe x4 Cards

Depending on the system configuration ordered your KBox C-101 can be extended with up to two PCIe x4 cards (full-
height, half-length form factor).
For installation/removing of the PCIe x4cards (Fig. 27, pos. 6), please refer to the subsection 10.2.1
"Installing/Removing the PCIe Expansion Cards".
To expand your system with additional cards, please observe the power consumption specified in the
chapter 16 "Technical Specification". The power consumption of each additional card does not exceed
15 W.
