B.5 Touchscreen – Viewer&Job Control
The Viewer Control screen allows the operator to control and modify the image on the
TFT flat screen.
The preview section (1) represents the TFT flat screen.
The scanned image is displayed on the TFT flat screen and with reduced quality in the
preview section right beside the controller elements.
Manual
Picture 42: Viewer & Job Control screen
Picture 43: Scanned image in preview area
The ICC Profile checkbox is displayed when the resolution for the
scan is 300 dpi or higher or when the High Quality scan mode is
active.
(1)
Page 45
