A.10.1

Powering up the Scanner

The main power switch is found at the back of the scanner.
Picture 8 resp. Picture 10 show the position of power supply connector and main power
switch.
After connecting the scanner to the external power supply, switch the main power switch
to position I. When the main power switch is in position I, the on/off button will be
illuminated and the scanner is in standby mode.
A.10.2

Starting the Scanner from Standby Mode

Push the red illuminated on/off button to start the scanner.
The button illumination changes to blue.
The scanner starts with self-test routines and verifies all system components. Status
messages will be displayed on the TFT flat screen (if connected) and on the touchscreen.
At the end of the start-up sequence, the touchscreen displays the start screen.
A.10.3

Switching the Scanner to Standby Mode

Note: Always turn off the scanner with the on/off button at the right side of
the front panel!
The main power switch should only be used when the scanner is in
stand-by mode and before the scanner is disconnected from the
external power supply.
To turn off the scanner, press and hold the on/off button for at least three seconds. While
pressing the button, a "click" sound is audible.
The content of the TFT flat screen and the touchscreen changes and display the
message: Going to shut down now ...
Finally the TFT flat screen and the touchscreen switch off and the on/off button will be
illuminated red.
A.10.4

The Help Function

To support the user when working with the scanner, a help function is integrated into the
touchscreen menus. A Question Mark (?) symbol in the bottom line of the touchscreen
activates the help function.
After touching the question mark, an additional window opens in the touchscreen and
shows information about the menu items of the selected menu.
Touching the OK button will close the additional window.
Manual Page 27
