The printer section mechanism in this model is taken from the BJC-4200 BJ printer.
Major changes are as follows.
Cartridge installation is not performed from the front, but from above.
l
The spur attachment location has been changed.
l
An ink detection semo~ has been added.
l
Figure 2-7 Printer Section
1
2-l
Chapter 2: Technical Reference
