Definition
Exceed Protocol Retransmission Limit Due to Failure to
1
Receive Significant Signals after PPS-EOP Transmission
during ECM TX
Receive DCN after PPS-EOP Transmission during ECM TX
Exceed Protocol Retransmission Limit or T5 Time (60
1
seconds) after PPS-EOP Transmission during ECM T
Exceed Retransmit Protocol after PPS-EOP Transmission
1
during ECM TX
Exceed Repeat Protocol Limit Due to Failure to Receive
1
Significant Signals after Transmitting EOR-NULL during
ECM TX
Receive DCN a&r EOR-NULL Transmission during ECM T
Exceed Protocol Retransmission Limit or T.5 Time (60
seconds) after EOR-NULL Transmission during ECM T
Receive ERR after EOR-NULL Transmission during ECM T
1
Exceed Protocol Retransmission Limit Due to Failure to
[TX 1
Receive Significant Signals after EOR-MPS Transmission
during ECM TX
Receive DCN after EOR-MPS Transmission during ECM TX
[TX 1
Exceed Protocol Retransmission Limit or T5 Time (60
[TX
seconds) after EOR-MPS Transmission during ECM TX
Receive ERR after EOR-MPS Transmission during ECM TX
[TX 1
Exceed Protocol Retransmission Limit Due to Failure to
[TX
Receive Significant Signals after EOR-EOM Transmission
during ECM T
Receive DCN after EOR-EOM Transmission during ECM TX
1
[TX
Exceed Protocol Retransmission Limit or T5 Time (60
[TX
seconds) after EOR-EOM Transmission during ECM TX
Receive ERR after EOR-EOM Transmission during ECM TX
1
ITX
Exceed Protocol Retransmission Limit Due to Failure to
[TX 1
Receive Significant Signals after EOR-EOP Transmission
during ECM T
Receive DCN after EOR-EOP Transmission during ECM TX
ITX 1
Exceed Protocol Retransmission Limit or T5 Time (60
[TX
seconds) after EOR-EOP Transmission during ECM TX
Receive ERR after EOR-EOP Transmission during ECM TX
1
Transmit ERR after EOR-Q Reception during ECM Rx
Receive Non-Significant Signals during ECM Mode
Procedures
Fail to Detect PPS-NULL between Partial Pages during
1
ECM Rx
Time Over Due to Failure to Receive Valid Frame during
IRX
High Speed Signal Rx upon ECM Rx
Receive All 0 PPR during ECM TX
[TX 1
Trouble in the decoding processing during communication
