Chapter 2: Technical Reference
2.1 Outline
In the facsimile mode, the printer part prints the received image from the facsimile circuit as
described in Part 1. In the printer mode, the printer part prints the character and image
data from the computer via the centronics type &bit parallel interface.
Figure 2-1 Printer Outline
2-1
