Names and functions of parts:
1. Paper guide
2. Lifting Plate
This plate moves upwards by the force of the springs and the release cam mechanism,
lifting the paper stack until it touches the Pickup Roller. After separation, it moves hack
down to its original position.
3. Pickup roller
The pickup roller has a semi circular roller. This roller is rotated once, and sends the paper
4. Pickup Roller Sensor (PRS)
monitors the initial position of the Pickup Roller position.
This sensor
5. Paper Separator
extra paper hack.
6. Paper Edge Sensor (PES)
This sensor monitors the paper feed state, and detects jams and misfeeds.
7. Paper Feed Roller
feeder. to the printing position in the Printer Section. It then feeds the paper one line at a
time, in coordination \rith the carriage movement
8. Paper Feed Motor
9. Transmission Roller
10. Paper Eject Roller
It 1s shaped so BS to make it difficult for ink to stick to it
12. Cleaner Roller
Chapter 2: Technical Reference
2-7
