Table of Contents
Part 2: Printer
Chapter 1: General Description
l - 2
2. SPECIFICATIONS
l - 2
2.1 Basic Specifications
2.2 Interface Specifications
1- 5
1 -10
3. OVERVIEW
3.1 Interface Connector
1 -10
3.2 Printer Operation Panel
1 -11
1 -12
4. SAFETY & PRECAUTIONS
4.1 Personnel Hazards
1 -12
1 -12
4.2 General Cautions
4.2.1 Connecting the interface cable
1 -12
4.2.2 Data lost when power cord is pulled out
1 -12
4.2.3 Data reset
1 -12
5. RESTRICTIONS
1 -13
Chapter 2: Technical Reference
2.1 Outline
2.2 Mechanical Overview
2.3 Data Flow
2.4 Printing
2.5 Circuit Overview
2.6 720 dpi Printing/Smoothing Feature
2.6.1 Canon extension mode
2.6.2 Emulation mode
a
2.7 Printing Modes
a
2.7.1 Printing mode
a
2.7.2 Photoprint mode
2.6 Optimum Printing Direction Control
2 -10
2.9 Ink Smear Control
2 -11
2.10 Bi-Centronics Interface
2 -11
2.10.1 Functions
2 -12
Chapter 3: Maintenance & Service
1. MAINTENANCE LIST
2. HOW TO CLEAN PARTS
3. ADJUSTMENT
4. TROUBLESHOOTING
4.1
Errors Shown on the Display
