Part 1: Facsimile
b) G3 signal transmission test
The G3 signal transmission test menu is selected by pressing the 4 button from the
MODEM NCU test menu. The G3 signals below are sent from the modem using the
modular jack and the speaker. The frequency can be changed with the numeric buttons.
Numeric button
0
1
2
3
4
5
6
8
NOTE
300
2400 bps
4800 bps
7200 bps
9600 bps
TC7200 bps
TC9600 bps
12000 bps
14400 bps
The transmission level can be changed with the FUiVCTlCJN button then <
and > button.
bps
