Page 15: Chapter 1: Introduction To Vtrak
About This Manual This Product Manual describes how to setup, use and maintain the VTrak E310f and E310s external disk array subsystem. It also describes how to use the built- in command-line interface (CLI), command-line utility (CLU) and embedded Web- based Promise Array Management—Professional (WebPAM PROe) software.
Page 16: Vtrak Overview
The failure of any single drive will not affect data integrity or accessibility of the data in a RAID protected logical drive. Figure 1. VTrak E310f and E310s front view Drive Carrier LEDs Drive Carriers...
Page 17: Architectural Description
Controller 2 Controller 1 Architectural Description The VTrak E310f is a Fibre Channel subsystem suitable for Direct Attached Storage (DAS), Storage Area Network (SAN), and Expanded Storage. The VTrak E310s is a Serial Attached SCSI (SAS) subsystem suitable for Direct Attached Storage (DAS), Cascaded Storage, and Expanded Storage.
Page 18: Subsystem And Controller Features
VTrak E-Class Product Manual • Supports for Serial Attached SCSI (SAS) and Serial ATA (SATA) 3 Gb/s drives simultaneously in the same system—choose the drive that is best suited to your application • Direct SATA LED support with AAMUX adapter •...
Page 19: Operational Features
Chapter 1: Introduction to VTrak External I/O Ports (per controller): Dual 4-Gb Fibre Channel host port; One external 3 Gb/s SAS x4 ports for JBOD expansion (up to four VTrak JBOD Systems). Data Cache: Shared 512 MB predictive data cache (expandable to 2 GB); Automatic write cache destaging;...
Page 20: Management
VTrak E-Class Product Manual Array Error Recovery: Data recovery from bad sector or failed HD for redundant RAID, RAID 5/6 inconsistent data Prevent (Write Hole Table), Data content Error Prevent (Read/Write Check Table) NVRAM event logging. SCSI Commands: Supports extensive SCSI command set equivalent to SCSI/FC hard disk drives.
Page 21: Warranty And Support
Chapter 1: Introduction to VTrak Warranty and Support Warranty: Three years complete system limited warranty. Support: 24 x 7 email and phone support (Americas and EMEA only). 24 x 7 access to Promise support site for drivers, firmware, compatibility. Advanced replacements program.
Page 22 VTrak E-Class Product Manual...
Page 23: Chapter 2: Vtrak Installation
Chapter 2: VTrak Installation This chapter covers the following topics: • Unpacking the VTrak (below) • Mounting VTrak in a Rack (page 10) • Installing Disk Drives (page 12) • Making Management and Data Connections (page 15) • Making Serial Cable Connections (page 26) •...
Page 24: Mounting Vtrak In A Rack
Mounting VTrak in a Rack The E-Class subsytems installs to the rack using the supplied mounting rails. You can also use your existing rails. Figure 1. VTrak E310f/s mounted in a rack with the supplied rails VTrak E310f/s Vertical Rack Post...
Page 25 Chapter 2: VTrak Installation Attach a two-hole flange to the rail, with the flange toward the back (connector end) of the enclosure. Install four rail adjustment screws (included) through the flange into the rail. Repeat steps 4 through 6 to attach the other rail and flanges to the enclosure.
Page 26: Installing Disk Drives
VTrak’s drive slots are numbered. Slot numbering is reflected in the WebPAM PROe and CLU user interfaces. Figure 3. VTrak E310f/s drive slot numbering Install all of the drive carriers into the VTrak enclosure to ensure proper airflow, even if you do not populate all the carriers with disk drives.
Page 27: Installing Disk Drives
Chapter 2: VTrak Installation Installing Disk Drives Remove a disk drive carrier. SATA drives only. Place the AAMUX adapter into the disk drive carrier and attach it with the four screws. See Figure 5. • Install only the screws supplied with the adapter. •...
Page 28 VTrak E-Class Product Manual Figure 5. SATA drive mounted in a drive carrier with the AAMUX adapter SATA disk drive SAS connector AAMUX adapter Figure 6. SAS drive mounted in a drive carrier SAS disk drive...
Page 29: Making Management And Data Connections
VTrak over your network using the WebPAM PROe Software. VTrak supports HTTP(S) and Telnet protocols. The VTrak E310f RAID controller has two 4-Gb Fibre Channel (FC) connections for the data ports. See Figure 7. You can configure your VTrak for: •...
Page 30 VTrak E-Class Product Manual Connect each Host PC’s or Server’s standard NIC to your network switch. Figure 8. VTrak E310f SAN data and management connections Network Switch FC Switch Mgmt Mgmt FC 1 FC 2 FC 1 FC 2 Gb/s...
Page 31 Chapter 2: VTrak Installation Figure 9. VTrak E310f DAS data and management connections Network Switch Mgmt Mgmt FC 1 FC 2 FC 1 FC 2 Gb/s Gb/s Gb/s Gb/s 115200 115200 8 N 1 8 N 1 VTrak Host PC or Server...
Page 32 Connect CN3 (a subtractive-routed port) on the first J300s unit to CN1 on one of the I/O modules of the next J300s unit. Connect the remaining J300s units in the same manner. Figure 10. VTrak E310f JBOD data connections FC Switch E310f...
Page 33 Chapter 2: VTrak Installation Figure 11. JBOD expansion with no single point of failure Host PCs or Servers Fibre Channel Switches E310f Mgmt Mgmt FC 1 FC 2 FC 1 FC 2 Gb/s Gb/s Gb/s Gb/s 115200 115200 8 N 1 8 N 1 J300s J300s...
Page 34: Serial Attached Scsi
VTrak E-Class Product Manual This completes management and data connections for VTrak E310f. Go to “Making Serial Cable Connections” on page 26. Serial Attached SCSI VTrak models can have one or two RAID controllers. Each controller has an Ethernet (RJ45) Management Port connector that enables you to monitor the VTrak over your network using the WebPAM PROe Software.
Page 35 Chapter 2: VTrak Installation Configuring Direct Attached Storage Direct attached storage (DAS) requires: • Two SAS HBA cards in the Host PC or Server • A network switch • A network interface card (NIC) in the Host PC or Server To establish the data path: On the VTrak controller, connect a SAS data port or a SAS data/cascade port to one of your SAS HBA cards.
Page 36 VTrak E-Class Product Manual Configuring Cascaded Storage Cascaded storage requires: • One SAS HBA card in the Host PC or Server • A network switch • A network interface card (NIC) in the Host PC or Server To establish the data path: On the VTrak controller, connect a SAS data port or a SAS data/cascade port to your SAS HBA card.
Page 37 Chapter 2: VTrak Installation Figure 15. VTrak E310s cascaded management and data connections Network Switch Mgmt 115200 8 N 1 VTrak Host PC or Server Mgmt 115200 8 N 1 VTrak Mgmt 115200 8 N 1 VTrak...
Page 38 VTrak E-Class Product Manual Configuring JBOD Expansion To expand the number of disk drives: On the E310s controller, connect the SAS expansion port (a subtractive- routed port) to the CN1 (a table-routed port) on one of the I/O modules of the first J300s unit.
Page 39 Chapter 2: VTrak Installation Figure 17. JBOD expansion with no single point of failure Host PCs or Servers E310s Mgmt Mgmt 115200 115200 8 N 1 8 N 1 J300s J300s J300s J300s This completes Network and Data connections for VTrak E310s. Go to “Making Serial Cable Connections”...
Page 40: Making Serial Cable Connections
VTrak E-Class Product Manual Making Serial Cable Connections RS232 serial communication enables the Command Line Interface (CLI) and Command Line Utility (CLU) on your PC to monitor and control the VTrak. On VTrak, RS232 communication goes through the RJ11 serial connector on each controller.
Page 41: Connecting The Power
Connecting the Power Plug the power cords and switch on both power supplies on. When the power is switched on, the LEDs on the front of the VTrak will light up. Figure 19.VTrak E310f/s front panel LED display Power FRU Status...
Page 42 VTrak E-Class Product Manual The Power/Activity LED flashes during drive activity. The Disk Status LED displays Green when a drive is present and configured. Go to “Chapter 3: VTrak Setup” on page 29.
Page 43: Chapter 3: Vtrak Setup
Chapter 3: VTrak Setup This chapter covers the following topics: • Setting up the Serial Connection (below) • Choosing DHCP or a Static IP Address (page 30) • Setting up VTrak with the CLI (page 31) • Setting up VTrak with the CLU (page 33) •...
Page 44: Choosing Dhcp Or A Static Ip Address
VTrak E-Class Product Manual Choosing DHCP or a Static IP Address When you setup your VTrak, you have the option of: • Enabling DHCP and letting your DHCP server assign the IP address to the VTrak’s virtual management port. • Specifying a static IP address for the VTrak’s virtual management port.
Page 45: Setting Up Vtrak With The Cli
Chapter 3: Setup Setting up VTrak with the CLI Type the following string to set the system date and time, then press Enter. administrator@cli> date -a mod -d 2006/08/25 -t 14:50:05 In the above example, the date and time are included as examples only. Your values will be different.
Page 46 VTrak E-Class Product Manual In the above example, the IP addresses and subnet mask are included as examples only. Your values will be different. If you prefer to let your DHCP server assign the IP addresses, type the following strings, then press Enter. administrator@cli>...
Page 47: Setting Up Vtrak With The Clu
Chapter 3: Setup Setting up VTrak with the CLU At the administrator@cli> prompt, type menu and press Enter. The CLU main menu appears. Figure 1. CLU main menu With Quick Setup highlighted, press Enter. The first Quick Setup screen enables you to make Date and Time settings. Setting system date and time Press the arrow keys to highlight System Date.
Page 48 VTrak E-Class Product Manual Type the new IP Address. Follow the same procedure to specify the Subnet Mask, Gateway IP Address and DNS Server IP Address. If you do not have a DNS server, skip the DNS Server IP address. Press Ctrl-A to save your settings.
Page 49 Chapter 3: Setup Highlight the controller you want and press Enter. Highlight DHCP and press the spacebar to toggle to Disabled. Highlight each of the following and press the backspace key to erase the current value, then type the new value. •...
Page 50: Creating Disk Arrays With Webpam Proe
VTrak E-Class Product Manual Creating Disk Arrays with WebPAM PROe Note You can also use the CLU to create disk arrays and logical drives. See Chapter 5 of the VTrak E-Class Product Manual for more information. Setting up disk arrays with WebPAM PROe consists of the following actions: •...
Page 51 Chapter 3: Setup When the log-in screen (Figure 2) appears: • Type administrator in the User Name field. • Type password in the Password field. • Click the Login button. The User Name and Password are case sensitive. Click the Login button. Figure 2.
Page 52: Selecting A Language
VTrak E-Class Product Manual Selecting a Language WebPAM PROe displays in English, German, French, Italian, Japanese, Chinese Traditional, Chinese Simple, and Korean. Click Language on the WebPAM PROe Header. The language list appears in the Header. Click on the language you prefer. The WebPAM PROe user interface displays in the selected language.
Page 53 Chapter 3: Setup Automatic When you choose the Automatic option, the following parameters appear on the screen: • Disk Arrays – The number of physical drives in the disk array, their ID numbers, configurable capacity, and the number of logical drives to be created •...
Page 54 VTrak E-Class Product Manual Express When you choose the Express option, a set of characteristics and options appears on the screen. Check the boxes to select any one or a combination of: • Redundancy – The array will remain available if a physical drive fails •...
Page 55 Chapter 3: Setup Advanced Note For an explanation of the parameters under the Advanced option, see “Chapter 7: Technology Background” on page 221. When you choose the Advanced option, the Step 1 – Disk Array Creation screen displays. Step 1 – Disk Array Creation Enter a name for the disk array in the field provided.
Page 56: Logging Out Of Webpam Proe
VTrak E-Class Product Manual 512 B, 1 KB, 2 KB, and 4 KB are available. 512 B is the default. 12. Specify a Read (cache) Policy from the dropdown menu. Read Cache, Read Ahead Cache, and No Cache are available. Read Ahead is the default.
Page 57: Using Webpam Proe Over The Internet
Obtaining a Security Certificate Promise Technology provides a default security certificate for the web server as well as for internal data communication. However, in most cases it is better to install and verify your own certificate. And, if possible, verify your certificate through a certificate authority, such as Verisign or Thwate.
Page 58 VTrak E-Class Product Manual...
Page 59: Chapter 4: Management With Webpam Proe
Chapter 4: Management with WebPAM PROe This chapter covers the following topics: • Logging into WebPAM PROe • Importing a User Database (page 46) (page 93) • Selecting a Language (page 48) • Updating the Firmware (page 94) • Perusing the Interface (page 49) •...
Page 60: Logging Into Webpam Proe
VTrak E-Class Product Manual Logging into WebPAM PROe In order to log into WebPAM PROe, you must first setup a network connection between your Host PC and the VTrak subsystem, as described in “Chapter 3: VTrak Setup” on page 29. To log into WebPAM PROe: Launch your Browser.
Page 61 Chapter 4: Management with WebPAM PROe Figure 1. The WebPAM PROe log-in screen...
Page 62: Selecting A Language
VTrak E-Class Product Manual Selecting a Language WebPAM PROe displays in English, German, French, Italian, Japanese, Chinese Traditional, Chinese Simple, and Korean. Click Language the WebPAM PROe Header. The language list appears in the Header. Click the language you prefer. The WebPAM PROe user interface displays in the selected language.
Page 63: Perusing The Interface
Chapter 4: Management with WebPAM PROe Perusing the Interface WebPAM PROe is browser-based RAID management software with a graphic user interface. Figure 3. WebPAM PROe interface There are four major parts to the graphic user interface: • Header (see page 50) •...
Page 64: Using The Header
VTrak E-Class Product Manual Using the Header The Header contains the following items: • Language – To change languages, see “Selecting a Language” on page 48. • View – To view the Event Frame, see “Viewing the Event Frame” on page 52.
Page 65: Using Tree View
Chapter 4: Management with WebPAM PROe Using Tree View Tree View enables you to navigate around all components of the Subsystem, including Fibre Channel or SAS management, network and service management, RAID controller, enclosure, physical drives, disk arrays, logical drives, and spare drives.
Page 66: Using Management View
VTrak E-Class Product Manual Using Management View Management View provides the actual user interface with the VTrak, including creation, maintenance, deletion, and monitoring of disk arrays and logical drives. Function Tabs control specific actions and processes. This window changes depending on which item you select in Tree View and which tab you select in Management View itself.
Page 67: Logging Out Of Webpam Proe
Chapter 4: Management with WebPAM PROe Logging out of WebPAM PROe There are two ways to log out of WebPAM PROe: • Close your browser window • Click Logout the WebPAM PROe banner (below Figure 8. Clicking “Logout” in the Header) Clicking Logout brings you back to the Login Screen.
Page 68: Working With The Storage Network
VTrak E-Class Product Manual Working with the Storage Network When you log into WebPAM PROe, you access a specific VTrak subsystem. See “Logging into WebPAM PROe” on page 46. The Storage Network feature enables you to access all of the VTrak subsytems with a Management Port connection to your network.
Page 69: Working With Subsystems
Chapter 4: Management with WebPAM PROe Working with Subsystems A VTrak subsystem is identified by its Management Port IP address. Subsystem functions include: • Viewing Subsystem Information (page 55) • Setting an Alias for the Subsystem (page 55) • Setting Redundancy for the Subsystem (page 56) •...
Page 70: Setting Redundancy For The Subsystem
VTrak E-Class Product Manual Enter a name into the Alias field. Maximum of 48 characters. Use letters, numbers, space between words, and underscore. Click the Submit button. Setting Redundancy for the Subsystem To set redundancy for this subsystem: In Tree View, click the Subsystem icon.
Page 71: Saving The Runtime Event Log
Chapter 4: Management with WebPAM PROe In Management View, click the Events tab dropdown menu and select Runtime Events. Events are displayed by: • Item Number – A consecutive decimal number assigned to a specific event • Device – Battery, controller, logical drive, physical drive, port, etc. •...
Page 72: Viewing Nvram Events
VTrak E-Class Product Manual Click the Clear Event Log button. In the Confirmation dialog box, type confirm and click the OK button. Viewing NVRAM Events NVRAM Events lists information about the 63 most recent important events. NVRAM events are stored in non-volatile memory. To view runtime events: In Tree View, click the Subsystem icon.
Page 73: Clearing Nvram Events
Chapter 4: Management with WebPAM PROe In the Save dialog box, name the file, navigate to the folder where you want to save the log file, and click the Save button. Clearing NVRAM Events To clear the NVRAM event log: In Tree View, click the Subsystem icon.
Page 74 VTrak E-Class Product Manual • Redundancy Check – Checks, reports and can correct data inconsistencies in logical drives • Migration – Change RAID level or add physical dries to disk arrays • PDM – Looks for bad blocks the physical drives of disk arrays •...
Page 75: Running Background Activities
Chapter 4: Management with WebPAM PROe Running Background Activities To run a background activity from the Background Activities tab: In Tree View, click the Subsystem icon. In Management View, click the Background Activities tab and select one of the following from the dropdown menu. •...
Page 76: Viewing Scheduled Activities
VTrak E-Class Product Manual To run PDM: In Tree View, click the Subsystem icon. In Management View, click the Background Activities tab and select Start Media Patrol from the dropdown menu. In the next screen, select the Source and Target physical drives. The suspect physical drive is the source.
Page 77: Deleting A Scheduled Activity
Chapter 4: Management with WebPAM PROe • End-on date. Select No End Date (perpetual). Or, select a number of occurrences for this activity. Or, select a specific end date. The default is today's date. For Redundancy Check only: • Choose the Auto Fix option. This feature attempts to repair the problem when it finds an error.
Page 78: Setting The Lock
VTrak E-Class Product Manual • Expire At Time – The date and time when the lock will automatically release. Setting the Lock The lock prevents other sessions (including by the same user) from making a configuration change to the controller until the lock expires or a forced unlock is done.
Page 79 Chapter 4: Management with WebPAM PROe Click the Subsystem icon Tree View. Click the Lock tab in Management View. If you are the User who set the lock, click the Unlock option. If another User set the lock and you are a Super User, click the Unlock option and check the Force Unlock box.
Page 80: Managing Users
VTrak E-Class Product Manual Managing Users User Management includes all functions dealing with user accounts. Functions include: • Viewing User Information (page 66) • Making User Settings (page 66) • Making Your Own User Settings (page 67) • Setting-up User Event Subscriptions (page 67) •...
Page 81: Making Your Own User Settings
Chapter 4: Management with WebPAM PROe • Enter or change the email address. • From the Privilege dropdown menu, choose a new level. See “List of User Privileges” on page 69 Click the Submit button. The Administrator or Super User can change another user’s password. See “Changing Another User’s Password”...
Page 82: Changing Another User's Password
VTrak E-Class Product Manual • Fatal – Non-Recoverable error or failure has occurred • None – Deactivates this event for notification purposes Click the Submit button. The user’s account must have an email address. See “Making User Settings” on page 66. For information about the email service, see “Making Email Settings”...
Page 83: Creating A User
Chapter 4: Management with WebPAM PROe Click the Submit button. Creating a User To create a user: Log into WebPAM PROe as the Administrator or a Super User. Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the User Management icon.
Page 84: Deleting A User
VTrak E-Class Product Manual Deleting a User There will always be at least one Super User account. You cannot delete the user account you used to log in. To delete a user: Log into WebPAM PROe as the Administrator or a Super User. Click the Subsystem icon in Tree View.
Page 85: Managing The Network Connection
Chapter 4: Management with WebPAM PROe Managing the Network Connection The network connection deals with network connections to the VTrak’s Management Ports. Functions include: • Making Subsystem Management Port Settings (page 71) • Making Controller Management Port Settings (page 71) Making Subsystem Management Port Settings The VTrak subsystem has a virtual management port.
Page 86 VTrak E-Class Product Manual Click the Maintenance Mode tab in Management View. Click the Port Configuration link for Controller 1 or 2. To enable DHCP, check the DHCP box. When DHCP is NOT enabled, enter: • Primary IP address • Primary subnet mask •...
Page 87: Managing Fibre Channel Connections
Chapter 4: Management with WebPAM PROe Managing Fibre Channel Connections This feature pertains to VTrak Fibre Channel models. Functions include: • Viewing Fibre Channel Node Information (page 73) • Viewing Fibre Channel Port Settings (page 73) • Making Fibre Channel Port Settings (page 74) •...
Page 88: Making Fibre Channel Port Settings
VTrak E-Class Product Manual • Fabric WWPN – World Wide Port Name (appears when connected to a switch) • Current Speed – 4 Gb/s, 2 Gb/s, or 1 Gb/s • Link Type – Long-wave laser, short-wave laser or electrical • Symbolic Name –...
Page 89: Viewing Fibre Channel Port Statistics
Chapter 4: Management with WebPAM PROe Port Setting Information The table below shows the type of attached topology you will achieve based on your connection type and the configured topology you select. Fibre Channel Attached Topology Configured Topology Connection Type N-Port NL-Port Switch...
Page 90: Viewing Fibre Channel Logged-In Devices
VTrak E-Class Product Manual Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the Fibre Channel Management icon. Click the SFP tab in Management View. The SFP information for all Fibre Channel ports is shown. SFP Information •...
Page 91 Chapter 4: Management with WebPAM PROe To view a list of recognized initiators: Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the Fibre Channel Management icon. Click the Initiator tab in Management View. A Fibre Channel switch will also display as an initiator in the list. If your Host PC's Fibre Channel HBA is connected to the VTrak directly (not though a Fibre Channel switch), the initiator will NOT display in the initiator list.
Page 92: Managing Sas Connections
VTrak E-Class Product Manual Managing SAS Connections This feature pertains to VTrak Serial Attached SCSI models. Functions include: • Viewing SAS Port Information (page 78) • Making SAS Port Settings (page 78) • Viewing SAS Port Statistics (page 79) • Viewing SAS Initiators (page 79) Viewing SAS Port Information A SAS Controller can have one or two SAS channels.
Page 93: Viewing Sas Port Statistics
Chapter 4: Management with WebPAM PROe Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the SAS Management icon. In Management View, click the Port 1 or Port 2 link. From the Cable Signal Strength dropdown menu, choose a value. The range is 1 to 8.
Page 94 VTrak E-Class Product Manual Adding an Initiator To add an initiator to the VTrak’s initiator list: Check the box to the left of the initiator. Click the Add to Initiator List button. The initiator appears under Storage Services. See page 81. You can then use the initiator to create a LUN.
Page 95: Managing Storage Services
Chapter 4: Management with WebPAM PROe Managing Storage Services Storage services deal with initiators and LUN mapping for Fibre Channel models and for Serial Attached SCSI models. LUN masking is the process of applying a LUN Map so that each initiator can only access the LUNs specified for it. Features include: •...
Page 96: Deleting An Initiator
VTrak E-Class Product Manual Deleting an Initiator To delete an initiator: Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the Storage Services icon. Click the Initiators tab in Management View. From the Initiators tab dropdown menu, select Delete Initiators. Check the box to the left of the initiator you want to delete.
Page 97: Editing A Lun Map
Chapter 4: Management with WebPAM PROe Select an initiator from the Initiator dropdown list. Or enter the initiator’s name in the Initiator Name field. Note that the initiator name you input must match exactly in order for the connection to work. In the LUN Mapping &...
Page 98: Managing Software Services
VTrak E-Class Product Manual Managing Software Services Software Services include the following functions: • Making Email Settings (page 84) • Making SLP Settings (page 85) • Making Web Server Settings (page 85) • Making Telnet Settings (page 87) • Making SNMP Settings (page 87) •...
Page 99: Making Slp Settings
Chapter 4: Management with WebPAM PROe • Click on the Automatic option to start the service automatically during system startup. Recommended. • Click on the Manual option to start the service manually (the service does not start during system startup). Click on the Submit button.
Page 100 VTrak E-Class Product Manual To make Web Server settings: Click the Subsystem icon in Tree View. Click the Administrative Tools icon. Click the Web Server Setting link in Management View. Enter the HTTP Port number. 80 is the default. Enter Session Time Out interval. This setting causes WebPAM PROe to time-out after a period of inactivity.
Page 101: Making Telnet Settings
Chapter 4: Management with WebPAM PROe Making Telnet Settings VTrak’s Telnet service enables you to access VTrak’s Command Line Interface (CLI) through a network connection. To make Telnet settings: Click the Subsystem icon in Tree View. Click the Administrative Tools icon.
Page 102 VTrak E-Class Product Manual Click the Administrative Tools icon. Click the SNMP Management link in Management View. Enter the SNMP Port number. 161 is the default. Enter a System Name. There is no default name. Enter a System Location. USA is the default. Enter a System Contact (the email address of the administrator or other individual).
Page 103: Making Cim Settings
Chapter 4: Management with WebPAM PROe Changing the Startup Setting Under Startup Type: • Click on the Automatic option to start the service automatically during system startup. Recommended. • Click on the Manual option to start the service manually (the service does not start during system startup).
Page 104: Making Netsend Settings
VTrak E-Class Product Manual Click the Submit button. Changing the Startup Setting Under Startup Type: • Click on the Automatic option to start the service automatically during system startup. Recommended. • Click on the Manual option to start the service manually (the service does not start during system startup).
Page 105: Chapter 4: Management With Webpam Proe, Continued
Chapter 4: Management with WebPAM PROe Deleting Netsend Recipients To delete a Netsend recipient: Highlight the recipient you want to delete in the recipient list. Click the Delete button to remove the recipient from the list. Click the Submit button. Click OK in the confirmation box.
Page 106: Exporting The User Database
VTrak E-Class Product Manual Exporting the User Database You can export the User Database file to share user information and settings among multiple VTrak subsystems. The Export action saves a text file a designated folder the Host PC. From there, you can import the User Database file to other VTrak subsystems.
Page 107: Importing A User Database
Chapter 4: Management with WebPAM PROe Importing a User Database Caution Do NOT use this function to update the VTrak firmware. The Software Management–Import tab enables you to import the User Database file from the Host PC's file system to the VTrak subsystem. When you make user settings to one VTrak, you can export the User Database file to the Host PC.
Page 108: Updating The Firmware
VTrak E-Class Product Manual Updating the Firmware This procedure is covered in Chapter 6: Maintenance. See “Updating the Firmware in WebPAM PROe” on page 205 for instructions.
Page 109: Restoring Factory Defaults
Chapter 4: Management with WebPAM PROe Restoring Factory Defaults VTrak includes a function to restore the default settings to its Firmware and Software settings. Caution The action of restoring default settings can disrupt your VTrak functions. Use this feature only when necessary and only the settings that must reset to default in order to set them correctly.
Page 110: Clearing Statistics
VTrak E-Class Product Manual Clearing Statistics The Clear Statistics function clears statistical data on controllers, Fibre Channel ports, SAS ports, physical drives, and logical drives. To clear statistical data: Click the Subsystem icon in Tree View. Click the Administrative Tools icon.
Page 111: Shutting Down The Subsystem
Chapter 4: Management with WebPAM PROe Shutting Down the Subsystem You can only do part of this function in WebPAM PROe. Additional action is required, as described below. To shutdown the subsystem: Click the Subsystem icon in Tree View. Click the Administrative Tools icon.
Page 112: Restarting The Subsystem
VTrak E-Class Product Manual Restarting the Subsystem You can only do part of this function in WebPAM PROe. Additional action is required, as described below. To restart the subsystem Click the Subsystem icon in Tree View. Click the Administrative Tools icon.
Page 113: Managing Controllers
Chapter 4: Management with WebPAM PROe Managing Controllers The RAID controllers are the heart of the VTrak subsystem. VTrak E-Class models have one or two controllers. Management of Controllers includes the following functions: • Viewing the Controllers (page 99) • Locating a Controller (page 99) •...
Page 114: Viewing Controller Information
VTrak E-Class Product Manual Figure 9. The VTrak E310f controller LEDs Mgmt FC 1 FC 2 Gb/s Gb/s 115200 8 N 1 Status LED Dirty Cache LED Figure 10.The VTrak E310s controller LEDs Mgmt 115200 8 N 1 Status LED...
Page 115: Viewing Controller Statistics
Chapter 4: Management with WebPAM PROe Upgradable items You can upgrade the following items: • Boot loader Version • Firmware Version number • Software Version number • Memory Size See “Chapter 6: Maintenance” on page 205. Viewing Controller Statistics To view controller statistics: Click the Subsystem icon in Tree View.
Page 116: Clearing An Orphan Watermark
VTrak E-Class Product Manual When disk drives of different capacities are used in the same array, coercion reduces the usable capacity of the larger disk drive(s) in order to match the smallest capacity drive. For more information, see “Capacity Coercion” on page 239. •...
Page 117: Managing Enclosures
Chapter 4: Management with WebPAM PROe Managing Enclosures On VTrak E-Class, enclosures include the main VTrak subsystem or Head Unit as well as additional enclosures that are connected to it through cascading or expansion. Enclosure Management includes the following functions: •...
Page 118: Viewing Enclosure Topology
VTrak E-Class Product Manual Figure 11. VTrak E310f/s front view Drive Carrier LEDs Drive Carriers Figure 12.VTrak E310f/s drive carrier LEDs Disk Status Viewing Enclosure Topology To view Enclosure Topology: Click the Subsystem icon in Tree View. Click the Enclosures icon.
Page 119: Viewing Enclosure Information
Chapter 4: Management with WebPAM PROe Viewing Enclosure Information To view enclosure information: Click the Subsystem icon in Tree View. Click the Enclosures icon. Click the Enclosure icon. Enclosure information appears the Information tab in Management View. You can monitor power supplies, cooling units, enclosure temperatures and voltages, and the battery.
Page 120: Checking The Batteries
VTrak E-Class Product Manual To view FRU VPD information: Click the Subsystem icon in Tree View. Click the Enclosures icon. Click the Enclosure icon. Click the FRU VPD tab in Management View. Use this information when communicating with Technical Support and when ordering replacement units.
Page 121: Reconditioning A Battery
Chapter 4: Management with WebPAM PROe controller before reconditioning is finished, the battery is charged to 100%, then reconditioning starts again. Reconditioning a Battery To recondition the battery: Click the Subsystem icon in Tree View. Click the Enclosures icon. Click the Enclosure icon.
Page 122 VTrak E-Class Product Manual Click the Enclosure icon. Click the Buzzer tab in Management View. From the Buzzer tab dropdown menu, select Settings. Check the Buzzer Enabled box. Check the Test Buzzer box. Click the Submit button. The buzzer will sound for one minute.
Page 123: Managing Physical Drives
Chapter 4: Management with WebPAM PROe Managing Physical Drives Managing Physical Drives deals with the physical disk drives installed in the VTrak subsystem enclosure, including the following functions: • Viewing a List of Physical Drives (page 109) • Identifying a Physical Drive (page 109) •...
Page 124: Viewing Physical Drive Information
VTrak E-Class Product Manual Click the Enclosures icon. Click the Enclosure icon. Click the Physical Drives icon. Click the Global Settings tab in Management View. Make the settings as needed. For SATA drives, check the boxes to enable: • Write Cache •...
Page 125: Viewing Physical Drive Statistics
Chapter 4: Management with WebPAM PROe Adjustable Items • Write Cache • Read Look Ahead Cache • Read Cache – SAS drive only • Command Queuing • DMA Mode – SATA drives only See “Making Global Physical Drive Settings” on page 109. Viewing Physical Drive Statistics To view physical drive statistics: Click the Subsystem...
Page 126: Clearing Stale And Pfa Conditions
VTrak E-Class Product Manual Clearing Stale and PFA Conditions The Clear tab only appears when those conditions are present. • Stale – The physical drive contains obsolete disk array information. • PFA – The physical drive has errors resulting in a prediction of failure. Be sure you have corrected the condition by a physical drive replacement, rebuild operation, etc., first.
Page 127 Chapter 4: Management with WebPAM PROe Important Forcing a physical drive offline will cause your logical drives to become degraded. If Auto Rebuild is enabled and a spare drive is available, the disk array will begin rebuilding itself automatically. To force a physical drive offline or online: Click the Subsystem icon in Tree View.
Page 128: Managing Disk Arrays
VTrak E-Class Product Manual Managing Disk Arrays Disk Array Management includes the following functions: • Viewing Disk Arrays (page 114) • Creating a Disk Array (page 114) • Deleting a Disk Array (page 118) • Viewing Disk Array Information (page 119) •...
Page 129: Creating A Disk Array - Automatic
Chapter 4: Management with WebPAM PROe Creating a Disk Array – Automatic The Disk Array Automatic Creation option enables you to create a new disk array following a default set of parameters. One logical drive will be made automatically when you create the disk array. To create a Disk Array using the Automatic function: Click the Subsystem icon in Tree View.
Page 130: Creating A Disk Array - Advanced
VTrak E-Class Product Manual Click the Create tab in Management View. From the Create tab dropdown menu, select Express. Check the boxes to select any one or combination of: • Redundancy – The array will remain available if a physical drive fails •...
Page 131 Chapter 4: Management with WebPAM PROe when you create the disk array. If you select less than the total available capacity, you can use the remaining space to create additional logical drives at a later time. If you are uncertain about choosing parameters for your disk array, use the Express or Automatic option to create your disk array.
Page 132: Deleting A Disk Array
VTrak E-Class Product Manual 14. Specify a Sector size from the dropdown menu. 512 B, 1 KB, 2 KB, and 4 KB are available. 512 B is the default. 15. Specify a Read (cache) Policy from the dropdown menu. Read Cache, Read Ahead Cache, and No Cache are available. Read Ahead is the default.
Page 133: Viewing Disk Array Information
Chapter 4: Management with WebPAM PROe Click the Delete tab in Management View. Check the box to the left of the disk array you want to delete. Click the Submit button. In the confirmation box, type the word confirm in the field provided. Click the OK button.
Page 134: Making Disk Array Settings
VTrak E-Class Product Manual • Media Patrol – Enabled or disabled. • PDM – Enabled or disabled. See “Making Disk Array Settings” on page 120. Making Disk Array Settings To make Disk Array settings: Click the Subsystem icon in Tree View. Click the Disk Arrays icon.
Page 135 Chapter 4: Management with WebPAM PROe For more information on axles, see “RAID 50 Axles” on page 228 or “RAID 60 Axles” on page 230. Enter a capacity and select unit of measure (MB, GB, TB). The default value is the available capacity of the disk array. You can use this value or any lesser amount.
Page 136: Deleting A Logical Drive
VTrak E-Class Product Manual Deleting a Logical Drive Caution All data the logical drive will be lost. Back up any valuable data before deleting the logical drive. To delete a logical drive: Click the Subsystem icon in Tree View. Click the Disk Arrays icon.
Page 137: Rebuilding A Disk Array
Chapter 4: Management with WebPAM PROe From the dropdown menu the Background Activities tab, select Start Migration. Highlight physical drives you want in the disk array from the Available list and press the >> button to move them to the Selected list. You can also double-click them to move them.
Page 138: Running Media Patrol On A Disk Array
VTrak E-Class Product Manual If there are multiple disk arrays, choose the icon with the yellow !. From the dropdown menu the Background Activity tab, select Start Rebuild. Select the Source physical drive. This is a remaining functional physical drive in the disk array. Select the Target physical drive.
Page 139: Transitioning A Disk Array
Chapter 4: Management with WebPAM PROe Click the Disk Arrays icon. Click the Disk Array icon. Click the Background Activities tab in Management View. From the dropdown menu the Background Activities tab, choose Start PDM. In the next screen, select the Source and Target physical drives. The suspect physical drive is the source.
Page 140 VTrak E-Class Product Manual • From one VTrak enclosure to another Important Before you can use this feature, the disk array’s Operational Status must be OK. To prepare a disk array for transport: Click the Subsystem icon in Tree View. Click the Disk Arrays icon.
Page 141: Managing Logical Drives
Chapter 4: Management with WebPAM PROe Managing Logical Drives Logical drives are made from disk arrays. In the Tree, you can see a graphic representation of the logical drives that belong to each array. You can see a summary of all logical drives in the subsystem under Logical Drive Summary. Logical drive management includes the following functions: •...
Page 142: Viewing Logical Drive Information
VTrak E-Class Product Manual However, the logical drive has lost redundancy (fault tolerance). You must determine the cause of the problem and correct it. • Offline – This condition arises as the result of a second physical drive failure. An Offline logical drive is not accessible but some or all of your data may remain intact.
Page 143: Viewing Logical Drive Statistics
Chapter 4: Management with WebPAM PROe Viewing Logical Drive Statistics To view information for a single logical drive: Click the Subsystem icon in Tree View. Click the Disk Arrays icon. Click the Disk Array icon. Click the Logical Drives icon Click the Logical Drive icon.
Page 144: Initializing A Logical Drive
VTrak E-Class Product Manual 11. Click the Submit button. Initializing a Logical Drive Initialization is done to logical drives after they are created from a disk array. Initialization sets all data bits in the logical drive to zero. The action is useful because there may be residual data the logical drives left behind from earlier configurations.
Page 145: Viewing The Logical Drive Check Table
Chapter 4: Management with WebPAM PROe Redundancy Check can also correct inconsistencies. You can also schedule a Redundancy Check. See “Scheduling an Activity” on page 62. Redundancy Check a Logical Drive: Click the Subsystem icon in Tree View. Click the Logical Drive Summary icon.
Page 146: Making Logical Drive Lun Settings
VTrak E-Class Product Manual If there are entries, they are listed as follows: • Entry Number – A number assigned to each block of entry. • Table Type – Read Check, Write Check or Inconsistent Block (see below). • Start Logical Block Address – LBA of the first block for this entry. •...
Page 147 Chapter 4: Management with WebPAM PROe Notes • Obtain the initiator name from the initiator utility on your host system. • The initiator name you input must match exactly in order for the connection to work. LUN Mapping Parameters • Initiator Name •...
Page 148: Managing Spare Drives
VTrak E-Class Product Manual Managing Spare Drives When a physical drive in a disk array fails and a spare drive of adequate capacity is available, the disk array will begin to rebuild automatically using the spare drive. See “Critical & Offline Disk Arrays” on page 276. Spare drive management includes the following functions: •...
Page 149: Creating A Spare Drive
Chapter 4: Management with WebPAM PROe Click the Spare Drive icon. In Management View, the Enclosure Front View diagram appears with the location of the spare drive highlighted. Creating a Spare Drive Important • There must be an unconfigured physical drive available for selection as a spare drive.
Page 150: Deleting Spare Drive
VTrak E-Class Product Manual Deleting Spare Drive Note If an existing spare drive has the wrong parameters for your needs, click the Settings tab to change the parameters rather than delete the spare drive and create a new one. To delete a spare drive: Click the Subsystem icon in Tree View.
Page 151: Running Spare Check
Chapter 4: Management with WebPAM PROe Running Spare Check Spare Check verifies the operational status of your spare drives. You can also schedule a Spare Check. See “Scheduling an Activity” on page 62. To check a spare drive: Click the Subsystem icon in Tree View.
Page 152: Working With The Logical Drive Summary
VTrak E-Class Product Manual Working with the Logical Drive Summary The Logical Drive Summary displays a list of all logical drives in the VTrak enclosure plus the expanded or cascaded enclosures. This list does not arrange the logical drives under the disk array to which they belong nor under the enclosure in which they are located.
Page 153: Chapter 5: Management With The Clu
Chapter 5: Management with the CLU This chapter covers the following topics: • Logging into the CLU (page 140) • Working with the Event Viewer (page 179) • Running Quick Setup (page 143) • Managing Spare Drives (page 181) • Managing the Subsystem (page 144) •...
Page 154: Logging Into The Clu
VTrak E-Class Product Manual Logging into the CLU There are two connections methods for the CLU: • Serial – Requires a null-modem cable to connect the serial ports on the Host PC and VTrak • Telnet – Requires a network connection between the Host PC and VTrak’s Management Port Making a Serial Connection Before you begin, be sure the null modem cable is connected between the Host...
Page 155 Chapter 5: Management with the CLU Figure 4. The CLU main menu Quick Setup – A sequence of four steps to setup System Date & Time, Management Port, and RAID Configuration. Subsystem Management – View controller information, lock/unlock the controller, set date and time, and monitor the enclosure. Physical Drive Management –...
Page 156: Accessing Online Help
VTrak E-Class Product Manual Background Activity – Settings for Media Patrol, Auto Rebuild, Rebuild, Migration, PDM, Transition, Synchronization, Initialization, Redundancy Check rate, and thresholds. Event Viewer – View the event logs. Additional Info and Management – Spare Drives, LUN Mapping, User management, EMail, SLP, Webserver, Telnet, SNMP, CIM, and Netsend settings, firmware flash, clear statistics and restore factory default settings.
Page 157: Chapter 5: Management With The Clu, Continued
Chapter 5: Management with the CLU Running Quick Setup Quick Setup is discussed under “Setting up the Serial Connection” on page 29.
Page 158: Managing The Subsystem
VTrak E-Class Product Manual Managing the Subsystem Subsystem Management includes the following functions: • Setting an Alias for the Subsystem (page 144) • Setting Redundancy for the Subsystem (page 144) • Running Media Patrol (page 144) • Locking or Unlocking the Subsystem (page 145) •...
Page 159: Locking Or Unlocking The Subsystem
Chapter 5: Management with the CLU Locking or Unlocking the Subsystem The lock prevents other sessions (including by the same user) from making a configuration change to the controller until the lock expires or a forced unlock is done. When the user who locked the controller logs out, the lock is automatically released.
Page 160 VTrak E-Class Product Manual Highlight the System Date or System Time setting. Press the backspace key to erase the current value. Type in a new value. Press Ctrl-A to save your settings.
Page 161: Managing The Controllers
Chapter 5: Management with the CLU Managing the Controllers Controller Management includes the following functions: • Viewing Controller Information (page 147) • Clearing an Orphan Watermark (page 147) • Making Controller Settings (page 147) • Locating the Controller (page 148) Viewing Controller Information Controller Management includes information, settings and statistics.
Page 162: Locating The Controller
VTrak E-Class Product Manual Make the following settings as required: • Type and alias into the Alias field. Maximum of 48 characters. Use letters, numbers, space between words and underscore. An alias is optional. • Highlight LUN Affinity and press the spacebar to toggle between Enabled and Disabled.
Page 163: Managing The Enclosure
Chapter 5: Management with the CLU Managing the Enclosure Enclosure Management includes the following functions: • Viewing Enclosure Information (page 149) • Viewing Power Supply Status (page 149) • Locating a Power Supply (page 149) • Viewing Blower Status (page 150) •...
Page 164: Viewing Blower Status
VTrak E-Class Product Manual From the Main Menu, highlight Subsystem Management and press Enter. Highlight Enclosure Management and press Enter. Highlight Power Supplies and press Enter. Highlight Locate Power Supply and press Enter. The LED on the selected power supply blinks for one minute. Viewing Blower Status To view the status of the blowers: From the Main Menu, highlight Subsystem Management and press Enter.
Page 165: Checking The Batteries
Chapter 5: Management with the CLU Highlight Enclosure Settings and press Enter. Highlight the Temperature Warning threshold you want to change. Press the backspace key to erase the current value. Type a new interval value in degrees C. Press Ctrl-A to save your settings. Checking the Batteries This feature enables you monitor and recondition the subsystem battery or batteries.
Page 166: Locating An Enclosure
VTrak E-Class Product Manual Highlight the battery you want to monitor and press Enter. Highlight Recondition Battery and press Enter. Press Y to confirm. During reconditioning, Battery status can show “discharging” and “recharging”, and a value will display next to Current. During that time, the controller cache is reset to Write Thru.
Page 167: Managing Physical Drives
Chapter 5: Management with the CLU Managing Physical Drives Physical Drive Management includes the following functions: • Making Global Physical Drive Settings (page 153) • Setting an Alias (page 154) • Viewing Advanced Information (page 154) • Viewing Physical Drive Statistics (page 154) •...
Page 168: Setting An Alias
VTrak E-Class Product Manual Setting an Alias An alias is optional. To set an Alias for a physical drive: From the Main Menu, highlight Physical Drive Management and press Enter. Highlight the physical drive of your choice and press Enter. Type an alias into the Alias field.
Page 169: Forcing A Physical Drive Offline Or Online
Chapter 5: Management with the CLU After you clear a PFA error, watch for another PFA error to appear. If it does, replace the physical drive. Forcing a Physical Drive Offline or Online This function enables you to force an: •...
Page 170: Managing Disk Arrays
VTrak E-Class Product Manual Managing Disk Arrays Disk Array Management includes the following functions: • Creating a Disk Array (page 156) • Deleting a Disk Array (page 160) • Viewing Disk Array Information (page 161) • Setting an Alias for a Disk Array (page 161) •...
Page 171: Creating A Disk Array - Automatic
Chapter 5: Management with the CLU Creating a Disk Array – Automatic To create a disk array using the Automatic feature: From the Main Menu, highlight Disk Array Management and press Enter. Highlight Create New Array and press Enter. Highlight Configuration Method and press the spacebar to toggle to Automatic.
Page 172: Creating A Disk Array - Express
VTrak E-Class Product Manual Creating a Disk Array – Express To create a disk array using the Express feature: From the Main Menu, highlight Disk Array Management and press Enter. Highlight Create New Array and press Enter. Highlight Configuration Method and press the spacebar to toggle to Express. Highlight Configuration Method and press to spacebar to select each of the following characteristics for your disk array: •...
Page 173: Creating A Disk Array - Advanced
Chapter 5: Management with the CLU Creating a Disk Array – Advanced For more information on the choices below, see “Chapter 7: Technology Background” on page 221. To create a disk array using the Advanced feature: From the Main Menu, highlight Disk Array Management and press Enter. Highlight Create New Array and press Enter.
Page 174: Deleting A Disk Array
VTrak E-Class Product Manual 18. Highlight Save Logical Drive and press Enter. 19. Review logical drive(s) you are about to create for your new array. Then do one of the following actions: • If you agree with the logical drive(s) as specified, highlight Complete Disk Array Creation and press Enter.
Page 175: Viewing Disk Array Information
Chapter 5: Management with the CLU Viewing Disk Array Information From the Main Menu, highlight Disk Array Management and press Enter. Highlight the disk array you want and press Enter. The information and settings screen appears. Highlight any of the following and press Enter to view a list of: •...
Page 176: Accepting An Incomplete Array
VTrak E-Class Product Manual Maximum of 32 characters. Use letters, numbers, space between words and underscore. An alias is optional. Press Ctrl-A to save your settings. Accepting an Incomplete Array This condition is the result of a missing physical drive. See “Incomplete Array” on page 279 before you use this function.
Page 177: Rebuilding A Disk Array
Chapter 5: Management with the CLU Highlight Transport and press Enter. Press Y to confirm. Rebuilding a Disk Array Before you can rebuild, you must have a replacement physical drive of adequate capacity or your disk array. To rebuild a disk array: From the Main Menu, highlight Disk Array Management and press Enter.
Page 178: Running Pdm
VTrak E-Class Product Manual 10. Optional. If you want to increase capacity, highlight Capacity, press the backspace key to erase the current logical drive capacity and type in the new value. The new value must be equal or larger than the current capacity. 11.
Page 179: Locating A Disk Array
Chapter 5: Management with the CLU Locating a Disk Array This feature helps you identify the physical drives assigned to the disk array you are working with in the CLU. To locate a disk array: From the Main Menu, highlight Disk Array Management and press Enter. Highlight the disk array you want and press Enter.
Page 180: Deleting A Logical Drive
VTrak E-Class Product Manual Highlight Number of Axles and press the spacebar to select the number of axles. Applies to RAID 50 and 60 only. Press Ctrl-A to save your settings. Note If you did not use all of the available capacity of the disk array, you can create an additional logical drive at this point.
Page 181: Managing Logical Drives
Chapter 5: Management with the CLU Managing Logical Drives The Logical Drive Management function deals with settings and functions of existing logical drives. To create or delete a logical drive, see “Managing Disk Arrays” on page 156. Logical drive management includes: •...
Page 182: Setting Read Cache Policy
VTrak E-Class Product Manual Highlight the logical drive you want and press Enter. To set write cache policy for this logical drive, highlight WritePolicy and press the spacebar to toggle between WriteBack and WriteThru (write though). Press Ctrl-A to save your settings. Setting Read Cache Policy To set read cache policy on a logical drive: From the Main Menu, highlight Logical Drive Management and press Enter.
Page 183: Running Redundancy Check
Chapter 5: Management with the CLU • Quick Initialization – Yes means only the disk data format of the logical drives are initialized. • Quick Initialization Rate – Enter a value or use the default 64 bits. To change a parameter, highlight it and press the backspace key to erase the current value, then type the new value.
Page 184: Managing The Network Connection
VTrak E-Class Product Manual Managing the Network Connection Network Management deals with network connections and settings for the Management Ports. Each Management Port can be configured: • Making Subsystem Management Port Settings (page 170) • Making Controller Maintenance Mode Settings (page 170) Making Subsystem Management Port Settings The VTrak subsystem has a virtual management port.
Page 185 Chapter 5: Management with the CLU Before you change settings, please see “Choosing DHCP or a Static IP Address” on page 30. Making Automatic Settings From the Main Menu, highlight Network Management and press Enter. Highlight Maintenance Mode Network Configuration and press Enter. Highlight the controller you want and press Enter.
Page 186: Managing Fibre Channel Connections
VTrak E-Class Product Manual Managing Fibre Channel Connections The Fibre Channel Management option appears only with VTrak Fibre Channel models. Fibre Channel Management includes the following functions: • Viewing Node Information (page 172) • Viewing Fibre Channel Logged-in Devices (page 172) •...
Page 187: Viewing Sfp Information
Chapter 5: Management with the CLU Highlight Hard ALPA and press the backspace key to erase the current value, then type the new value. The range is 0 to 255. 255 disables this feature. Press Ctrl-A to save your settings. The table below shows the type of attached topology you will achieve based on your connection type and the configured topology you select: Fibre Channel Attached Topology...
Page 188: Viewing Fibre Channel Initiators
VTrak E-Class Product Manual Highlight Fibre Channel Ports and press Enter. Highlight Fibre Channel Port 1 or Port 2 and press Enter. Highlight Fibre Channel Port Statistics and press Enter. This screen displays statistics for this port. There are no user settings on this screen.
Page 189: Managing Sas Connections
Chapter 5: Management with the CLU Managing SAS Connections The SAS Management option appears only with VTrak Serial Attached SCSI models. SAS Management includes the following functions: • Viewing SAS Port Information (page 175) • Making SAS Port Settings (page 175) •...
Page 190: Viewing Sas Port Statistics
VTrak E-Class Product Manual Viewing SAS Port Statistics There are two SAS ports on each controller. To view information about the SAS ports: From the Main Menu, highlight SAS Management and press Enter. Highlight SAS Ports and press Enter. Highlight the port you want to see and press Enter. Highlight SAS Port Statistics and press Enter.
Page 191: Chapter 5: Management With The Clu, Continued
Chapter 5: Management with the CLU Managing Background Activity Background activity refers to any of several functions that take place in the background while normal operation of the VTrak continues. Background activities work in conjunction with disk arrays and logical drives. See “Managing Disk Arrays”...
Page 192 VTrak E-Class Product Manual • PDM – Looks for bad blocks on the physical drives of disk arrays • Transition – Returns a revertible spare drive to spare status • Synchronization – Checks the data integrity on disk arrays • Initialization –...
Page 193: Working With The Event Viewer
Chapter 5: Management with the CLU Working with the Event Viewer The Event Viewer displays log of subsystem events. Events are classified as: • Runtime Events – A list of and information about the 1023 most recent runtime events recorded since the subsystem was started •...
Page 194: Clearing Nvram Events
VTrak E-Class Product Manual From the Main Menu, highlight Event Viewer and press Enter. Highlight NVRAM Events and press Enter. The log of NVRAM Events appears. Events are added to the top of the list. Each item includes: • Sequence number – Begins with 0 at system startup. •...
Page 195: Managing Spare Drives
Chapter 5: Management with the CLU Managing Spare Drives Spare Drive Management includes the following functions: • Viewing a list of Spare Drives (page 181) • Creating a Spare Drive (page 181) • Making Spare Drive Settings (page 182) • Running Spare Check (page 182) •...
Page 196: Making Spare Drive Settings
VTrak E-Class Product Manual A revertible drive can be returned to spare status after you replace the failed drive in a disk array. See “Transition” on page 246 for more information. Highlight Spare Type and press the spacebar to toggle between Dedicated and Global.
Page 197: Deleting A Spare Drive
Chapter 5: Management with the CLU The results appear next to Spare Check Status. Deleting a Spare Drive Caution If the spare drive you delete is the only spare, the controller will not rebuild a critical array until you provide a new spare drive. Highlight the spare drive you want to delete and press the spacebar to mark The mark is an asterisk (*) to the left of the listing.
Page 198: Working With Lun Mapping
VTrak E-Class Product Manual Working with LUN Mapping LUN Mapping includes the following functions: • Viewing a List of Initiators (page 184) • Enabling LUN Mapping (page 184) • Creating an Initiator (page 184) • Mapping a LUN to an Initiator (page 185) •...
Page 199: Mapping A Lun To An Initiator
Chapter 5: Management with the CLU • Fibre Channel – A Fibre Channel initiator name is the World Wide Port Name of the device and is composed of a series of eight, two-digit hexadecimal numbers. • SAS – A SAS initiator name is the SAS address of the HBA card in the Host PC.
Page 200 VTrak E-Class Product Manual The mark is an asterisk (*) to the left of the listing. Highlight Delete Marked Initiators and press Enter. Press Y to confirm the deletion.
Page 201: Managing Users
Chapter 5: Management with the CLU Managing Users User Management includes the following functions: • Viewing User Information (page 187) • Creating a User (page 187) • Changing a User’s Password (page 188) • Changing a User’s Display Name and Email Address (page 188) •...
Page 202: Changing A User's Password
VTrak E-Class Product Manual List of User Privileges • View – Allows the user to see all status and settings but not to make any changes • Maintenance – Allows the user to perform maintenance tasks including Rebuilding, PDM, Media Patrol, and Redundancy Check •...
Page 203: Changing A User's Privilege And Status
Chapter 5: Management with the CLU Changing a User’s Privilege and Status No user can change their own privilege or status. To change another user’s privilege or status. Log in as the Administrator or a Super user. From the Main Menu, highlight Additional Info and Management and press Enter.
Page 204: Working With Software Management
VTrak E-Class Product Manual Working with Software Management Software Management includes the following functions: • Making Email Settings (page 190) • Making SLP Settings (page 191) • Making Webserver Settings (page 191) • Making Telnet Settings (page 192) • Making SNMP Settings (page 192) •...
Page 205: Making Slp Settings
Chapter 5: Management with the CLU Making SLP Settings By default, SLP service is set to Automatic and its normal status is Started. To make SLP service settings: From the Main Menu, highlight Additional Info and Management and press Enter. Highlight Software Management and press Enter.
Page 206: Making Telnet Settings
VTrak E-Class Product Manual Making Telnet Settings By default, Telnet service is set to Automatic and its normal status is Started. To make Telnet service settings: From the Main Menu, highlight Additional Info and Management and press Enter. Highlight Software Management and press Enter. Highlight Telnet and press Enter.
Page 207: Managing Snmp Trap Sinks
Chapter 5: Management with the CLU Press Ctrl-A to save your settings. To start, stop or restart the SNMP service, highlight Start, Stop, or Restart and press Enter. Managing SNMP Trap Sinks Creating a SNMP trap sink To create a trap sink: From the Main Menu, highlight Additional Info and Management and press Enter.
Page 208: Making Cim Settings
VTrak E-Class Product Manual Making CIM Settings By default, CIM (Common Information Model [a protocol]) service is set to Automatic and its normal status is Started. To make CIM service settings: From the Main Menu, highlight Additional Info and Management and press Enter.
Page 209: Managing Netsend Recipients
Chapter 5: Management with the CLU From the Main Menu, highlight Additional Info and Management and press Enter. Highlight Software Management and press Enter. Highlight Netsend and press Enter. Highlight Startup Type and press the spacebar to toggle between Automatic and Manual.
Page 210 VTrak E-Class Product Manual Highlight Message Event Severity Filter and press the spacebar to change severity levels. Press Ctrl-A to save your settings. Deleting a Recipient To delete a recipient: From the Main Menu, highlight Additional Info and Management and press Enter.
Page 211: Flashing Through Tftp
Chapter 5: Management with the CLU Flashing through TFTP Use this function to flash the VTrak’s firmware. See “Updating the Firmware in the CLU” on page 208 for this procedure.
Page 212: Clearing Statistics
VTrak E-Class Product Manual Clearing Statistics This function clears the statistical counts for the RAID controller, Fibre Channel ports, SAS ports, physical drives, and logical drives. To clear statistics: From the Main Menu, highlight Additional Info and Management and press Enter.
Page 213: Restoring Factory Defaults
Chapter 5: Management with the CLU Restoring Factory Defaults This function restores the factory default settings to the firmware and software items you select. Caution Use this function with care. Do not restore to default settings for any item unless you are sure this action is needed. From the Main Menu, highlight Additional Info and Management and press Enter.
Page 214: Shutting Down The Subsystem
VTrak E-Class Product Manual Shutting Down the Subsystem There are two methods for shutting down the subsystem. Choose one of the following procedures: • Shutting down the VTrak – Telnet Connection (page 200) • Shutting down the VTrak – Serial Connection (page 200) Shutting down the VTrak –...
Page 215 Chapter 5: Management with the CLU Shutdown complete. It is now safe to power off the subsystem.
Page 216: Restarting The Subsystem
VTrak E-Class Product Manual Restarting the Subsystem There are two methods for restarting the subsystem. Choose one of the following procedures: • Restarting the Subsystem (page 202) • Restarting VTrak – Serial Connection (page 202) Restarting VTrak – Telnet Connection This function enables you to restart the VTrak subsystem on a Telnet connection.
Page 217: Making Buzzer Settings
Chapter 5: Management with the CLU Making Buzzer Settings This function enables the buzzer on the controller. When you first power-up the VTrak, it beeps twice to show normal operation. To change buzzer settings: From the Main Menu, highlight Buzzer and press Enter. A list of Controllers appears with the current buzzer setting and status.
Page 218 VTrak E-Class Product Manual...
Page 219: Chapter 6: Maintenance
Chapter 6: Maintenance This chapter covers the following topics: • Updating the Firmware in WebPAM PROe (page 205) • Updating the Firmware in the CLU (page 208) • Replacing a Power Supply (page 210) • Replacing a Cooling Unit Blower (page 210) •...
Page 220: Updating Firmware From Your Pc
VTrak E-Class Product Manual • From the Firmware Update tab dropdown menu, select Download from TFTP Server. Enter the hostname or IP address of your TFTP server in the field provided. Enter the port number of your TFTP server in the field provided (69 is the default).
Page 221: Restarting The Subsystem
Chapter 6: Maintenance When the download is completed, click the Next button. A popup message appears to warn you not to reboot the VTrak during the firmware update procedure. In the popup message, click the OK button. The update progress displays. Then a popup message appears to tell you to reboot the VTrak.
Page 222: Updating The Firmware In The Clu
VTrak E-Class Product Manual Updating the Firmware in the CLU A firmware update consists of the following actions: • Downloading the Firmware Image File (page 208) • Updating the Firmware (page 208) • Restarting Subsystem over a Telnet Connection (page 208) •...
Page 223: Restarting Subsystem Over A Serial Connection
Chapter 6: Maintenance From the Main Menu, highlight Additional Info and Management, and press Enter. Highlight Shutdown or Restart and press Enter. Press the spacebar to display Restart then press Enter. A warning message appears. Press Y to continue. The screen will go blank. Wait for two to three minutes.
Page 224: Replacing A Power Supply
VTrak E-Class Product Manual Replacing a Power Supply The power supply and its fans are replaced as one unit. There are no individually serviceable parts. No tools are required for this procedure. Remove the Old Power Supply To remove the power supply: Verify that the power supply LED is amber or red.
Page 225: Remove And Replace A Blower
Chapter 6: Maintenance Remove and Replace a Blower To replace a blower: Verify that the Fan LED on the cooling unit is amber or red. Figure 2. Fan LED Fan LED On the cooling unit, press the release button and pull the handle downward. See Figure 3.
Page 226 VTrak E-Class Product Manual Figure 4. Removing the top from the cooling unit Loosen the thumbscrews Lift the blower off the mounting pins and detach the electrical connector. Figure 5. The blower and its electrical connector Electrical Blower connector Attach the electrical connector of the new blower and set the blower in place. Be sure you position the blower onto the mounting pins.
Page 227 Chapter 6: Maintenance Figure 6. Positioning the blower onto the mounting pins Be sure the blower points outward, towards the handle. Figure 7. Positioning the blower Place the top section of the cooling unit onto the bottom section and tighten the thumbscrews.
Page 228 VTrak E-Class Product Manual 11. Verify that the Fan LEDs are green. This completes the blower replacement procedure.
Page 229: Replacing A Cache Battery
Chapter 6: Maintenance Replacing a Cache Battery The cache battery is located inside the cooling unit. The battery assembly is replaced as an individual part. Cautions • Try reconditioning the battery before you replace it. See page 107 or page 151 for more information. •...
Page 230 VTrak E-Class Product Manual Figure 10.Loosen the thumbscrews and remove the cover Loosen the thumbscrews Remove the two screws holding the battery assembly in place. Detach the connector on the circuit board. Do not detach any other connectors. Figure 11. Removing the mounting screws and detaching the connector Remove this screw Detach this connector Remove this screw...
Page 231 Chapter 6: Maintenance 10. Install the two screws holding the battery assembly in place to the cooling unit. 11. Place the top section of the cooling unit onto the bottom section and tighten the thumbscrews. 12. Carefully slide the cooling unit into the enclosure. 13.
Page 232: Replacing A Raid Controller
VTrak E-Class Product Manual Replacing a RAID Controller The RAID Controller is field-replaceable. But you can only hot-swap a controller if you have two controllers installed in your VTrak enclosure. Important Do not replace the RAID Controller based on LED colors alone. Only replace the RAID Controller when directed to do so by Promise Technical Support.
Page 233 Chapter 6: Maintenance Disconnect the Fibre Channel or SAS cables, management, serial and power cables. On the controller handle, press the release button and pull the handle downward. See Figure 13. Pull the controller out of the VTrak enclosure. Installing the new controller To install the new controller: Carefully slide the controller into the enclosure.
Page 234 VTrak E-Class Product Manual Figure 13.Replacing the VTrak controller...
Page 235: Chapter 7: Technology Background
Chapter 7: Technology Background This chapter covers the following topics: • Introduction to RAID (below) • Choosing a RAID Level (page 232) • Choosing Stripe Size (page 235) • Choosing Sector Size (page 235) • Cache Policy (page 236) • LUN Affinity (page 238) •...
Page 236: Raid 0 - Stripe
VTrak E-Class Product Manual RAID 0 – Stripe When a disk array is striped, the read and write blocks of data are interleaved between the sectors of multiple drives. Performance is increased, since the workload is balanced between drives or “members” that form the disk array. Identical disk drives are recommended for performance as well as data storage efficiency.
Page 237: Raid 1 - Mirror
Chapter 7: Technology Background RAID 1 – Mirror When a disk array is mirrored, identical data is written to a pair of drives, while reads are performed in parallel. The reads are performed using elevator seek and load balancing techniques where the workload is distributed in the most efficient manner.
Page 238: Raid 1E - Enhanced Mirror
VTrak E-Class Product Manual RAID 1E – Enhanced Mirror RAID 1E offers the security of mirrored data provided by RAID 1 plus the added capacity of more than two disk drives. It also offers overall increased read/write performance plus the flexibility of using an odd number of disk drives. With RAID 1E, each data stripe is mirrored onto two disk drives.
Page 239: Raid 5 - Block And Parity Stripe
Chapter 7: Technology Background RAID 5 – Block and Parity Stripe RAID 5 organizes block data and parity data across the physical drives. Generally, RAID Level 5 tends to exhibit lower random write performance due to the heavy workload of parity recalculation for each I/O. RAID 5 is generally considered to be the most versatile RAID level Distributed Parity Data...
Page 240: Raid 6 - Block And Double Parity Stripe
VTrak E-Class Product Manual RAID 6 – Block and Double Parity Stripe RAID level 6 stores dual parity data is rotated across the physical drives along with the block data. A RAID 6 disk array can continue to accept I/O requests when any two physical drives fail.
Page 241: Raid 10 - Mirror + Stripe
Chapter 7: Technology Background RAID 10 – Mirror + Stripe Mirroring/striping combines both of the previous RAID 1 and RAID 0 disk array types. RAID 10 is similar though not identical to RAID 0+1. RAID 10 can increase performance by reading and writing data in parallel while protecting data with duplication.
Page 242: Raid 50 - Striping Of Distributed Parity
RAID 50 arrays consist of six or more physical drives. Using a VTrak E310f/s subsystem expanded by four J300s subsystems, your RAID 50 array supports up to 60 physical drives. See “Configuring JBOD Expansion” on page 18 or page 24. However, Promise recommends that you set aside a few physical drives as hot spares.
Page 243 Chapter 7: Technology Background The chart below shows RAID 50 arrays with 6 to 16 physical drives, the available number of axles, and the resulting distribution of physical drives on each axle. RAID 50 Array No. of Drives No. of Axles Drives per Axle 3,3,3 3,3,4...
Page 244: Raid 60 - Striping Of Double Parity
RAID 60 arrays consist of eight or more physical drives. Using a VTrak E310f/s subsystem expanded by four J300s subsystems, your RAID 60 array supports up to 60 physical drives. See “Configuring JBOD Expansion” on page 18 or page 24. However, Promise recommends that you set aside a few physical drives as hot spares.
Page 245 Chapter 7: Technology Background RAID 60 Array No. of Drives No. of Axles Drives per Axle 4,4,4 4,4,5 4,5,5 5,5,5 5,5,6 4,4,4,4 5,6,6 4,4,4,5 6,6,6 4,4,5,5 9,10 6,6,7 4,5,5,5 10,10 6,7,7 5,5,5,5 4,4,4,4,4...
Page 246: Choosing A Raid Level
VTrak E-Class Product Manual Choosing a RAID Level There are several issues to consider when choosing the RAID Level for your VTrak disk array. The following discussion summarizes some advantages, disadvantages, and applications for each choice. RAID 0 Advantages Disadvantages Implements a striped disk array, the Not a true RAID because it is not fault- data is broken down into blocks and...
Page 247: Raid 1E
Chapter 7: Technology Background RAID 1E Advantages Disadvantages Implemented as a mirrored disk array Very high disk overhead - uses only whose segments are RAID 0 disk 50% of total capacity arrays High I/O rates are achieved thanks to multiple stripe segments Can use an odd number of disks Recommended Applications for RAID 1E •...
Page 248: Raid 10
VTrak E-Class Product Manual RAID 10 Advantages Disadvantages Implemented as a mirrored disk array Very high disk overhead - uses only whose segments are RAID 0 disk 50% of total capacity arrays High I/O rates are achieved thanks to multiple stripe segments Recommended Applications for RAID 10 •...
Page 249: Choosing Stripe Size
Chapter 7: Technology Background Choosing Stripe Size Stripe Size, also called “Stripe Block Size”, refers to the size of the data blocks written to, and read from, the physical drives. Stripe Size is specified when you create a disk array. In order to change the Stripe Size of an existing disk array, you must delete the disk array and create a new one.
Page 250: Tb Limitation
VTrak E-Class Product Manual • Linux operating systems with the 2.6 kernel support 64-bit LBA. For these OSes, always choose the default 512 B sector size. 2 TB Limitation If your Host PC runs Windows 2000 or Windows XP (32-bit), and you want to create logical drives larger than 2TB, you must choose a sector size larger than 512 B when you create the logical drive.
Page 251: Write Cache Policy
Chapter 7: Technology Background • Read Ahead – The read cache and the read-ahead feature are enabled. Read-ahead anticipates the next read and performs it before the request is made. Can increase read performance. • No Cache – The read cache is disabled. Write Cache Policy •...
Page 252: Lun Affinity
VTrak E-Class Product Manual LUN Affinity VTrak Fibre Channel subsystems with two controllers include a LUN Affinity feature. Normally, either controller can access all logical drives. LUN Affinity enables you to specify which controller can access each logical drive. Use this feature to balance the load of your logical drives between the two controllers.
Page 253: Failover And Failback
Chapter 7: Technology Background Failover and Failback When one controller fails, the surviving controller takes over logical drive access until the failed controller is brought back online or is replaced. For example, LUN Affinity is enabled and your logical drives are assigned to Controller 1. The following actions will happen: •...
Page 254: Initialization
VTrak E-Class Product Manual Without Capacity Coercion, the controller will not permit the use of a replacement physical drive that is slightly smaller than the remaining working drive(s). Initialization Initialization is done to logical drives after they are created from a disk array. Initialization sets all data bits in the logical drive to zero.
Page 255: Partition And Format The Logical Drive
Chapter 7: Technology Background Partition and Format the Logical Drive Like any other type of fixed disk media in your system, a RAID logical drive must also be partitioned and formatted before use. Use the same method of partitioning and formatting on an logical drive as you would any other fixed disk. Depending on the operating system you use, there may or may not be various capacity limitations applicable for the different types of partitions.
Page 256 VTrak E-Class Product Manual Increase Redundancy From Capacity Performance Lose RAID 5 RAID 50 • RAID 10 • • RAID 1E • RAID 0 • • • RAID 1E RAID 50 • RAID 10 • RAID 5 • RAID 0 •...
Page 257: Ranges Of Disk Array Expansion
Chapter 7: Technology Background Important • The Target disk array may require more disk drives than the Source disk array • If the Target disk array requires an EVEN number of disk drives but the Source disk array has an ODD number, ADD a disk drive as part of the migration process •...
Page 258: Media Patrol
VTrak E-Class Product Manual • Additional capacity might appear as unpartitioned and unformatted. Maximum LD Current LD Size Sector Size Expansion Size 8 to 16 TB 16 TB 4096 bytes 4 to 8 TB 8 TB 2048 bytes 2 to 4 TB 4 TB 1024 bytes up to 2 TB...
Page 259: Predictive Data Migration (Pdm)
Chapter 7: Technology Background Predictive Data Migration (PDM) Predictive Data Migration (PDM) is the migration of data from the suspect disk drive to a spare disk drive, similar to Rebuilding a Logical Drive. But unlike Rebuilding, PDM constantly monitors your disk drives and automatically copies your data to a spare disk drive before the disk drive fails and your Logical Drive goes Critical.
Page 260: Transition
VTrak E-Class Product Manual Transition The Transition feature enables you to specify “permanent” spare drives for your VTrak subsystem. Transition is the process of replacing a revertible spare drive that is currently part of a disk array with an unconfigured physical drive or a non- revertible spare.
Page 261 Chapter 7: Technology Background In the example above, there is a four-drive RAID 5 disk array and a global spare drive. Physical drives 1, 2, 3, and 4 belong to the disk array. Physical drive 5 remains unconfigured. Physical drive 6 is a revertible spare drive. If a physical drive fails in a disk array and there is a spare drive of adequate capacity available, the controller automatically rebuilds the array using the spare drive.
Page 262 VTrak E-Class Product Manual Automatic Transition At this juncture, you would replace the failed drive in slot 3 with a new one of the same or greater capacity. When the VTrak controller detects the new drive in slot 3, it will: •...
Page 263: Chapter 8: Troubleshooting
Chapter 8: Troubleshooting This chapter covers the following topics: • VTrak is Beeping (page 250) • LEDs Display Amber or Red (page 251) • CLU Reports a Problem (page 256) • WebPAM PROe Reports a Problem (page 258) • LEDs Display Amber or Red (page 251) •...
Page 264: Vtrak Is Beeping
VTrak E-Class Product Manual VTrak is Beeping VTrak’s alarm has five different patterns, as shown below. Figure 1. Audible alarm sound patters .25s .25s .25s .25s .75s .25s .75s .25s 2.5s .25s .25s .25s .25s .25s .25s .75s .25s .25s 1.25s .25s When you first power-up the VTrak, it beeps twice to show normal operation.
Page 265: Leds Display Amber Or Red
Chapter 8: Troubleshooting LEDs Display Amber or Red Front Panel When the power is switched on, the LEDs on the front of the VTrak will light up. Figure 2. VTrak E310f/s front panel LED display Power FRU Status Logical Drive Status...
Page 266: Drive Status Indicators
The VTrak spins up the disk drives sequentially in order to equalize power draw during start-up. After a few moments the Power/Activity and Disk Status LEDs should display green. Figure 3. VTrak E310f/s drive carrier LEDs Disk Status Power/Activity...
Page 267: Back Of Enclosure
When the FRU Status LED on VTrak’s front panel shows Amber or Red, check the LEDs on the back of VTrak. These LEDs give the status of the field replaceable units. Figure 4. VTrak E310f rear view Cooling Unit 2 Cooling Unit 1...
Page 268 VTrak E-Class Product Manual Figure 5. VTrak E310s rear view Cooling Unit 2 Cooling Unit 1 Power Supply 1 Power Supply 2 with Battery with Battery Mgmt Mgmt 115200 115200 8 N 1 8 N 1 RAID Controller 1 RAID Controller 2 Figure 6.
Page 269 Chapter 8: Troubleshooting Figure 7. The VTrak E310f controller LEDs Mgmt FC 1 FC 2 Gb/s Gb/s 115200 8 N 1 Status LED Dirty Cache LED Figure 8. The VTrak E310s controller LEDs Mgmt 115200 8 N 1 Status LED...
Page 270: Clu Reports A Problem
VTrak E-Class Product Manual CLU Reports a Problem The CLU reports information passively—you must determine which functions to check based on the sound of the VTrak’s audible alarm (see page 250) and any amber or red LEDs (see page 251). Check the event logs first.
Page 271: Checking A Reported Component
Chapter 8: Troubleshooting Checking a Reported Component In this example, let us check disk array status. Open the CLU. Highlight Disk Array Management and press Enter. Observe the status of your disk arrays. DaId Alias OpStatus CfgCapacity FreeCapacity MaxContiguousCap ------------------------------------------------------------------------------------------- 75.44GB 66.06GB 66.06GB...
Page 272: Webpam Proe Reports A Problem
VTrak E-Class Product Manual WebPAM PROe Reports a Problem WebPAM PROe aids in troubleshooting your logical drives and enclosure by continuous monitoring and reporting to the User in the following ways: • Displays yellow !s red Xs in Tree View. Figure 9.
Page 273 Chapter 8: Troubleshooting Figure 11. The Event Log • Keeps a record in the Event Log. • Displays full information in Management View. Figure 12.A failed disk drive shown in Management View Auto Rebuild Replacement Drive Failed Disk Drive Critical / Rebuilding Status...
Page 274 VTrak E-Class Product Manual Also see these troubleshooting topics: • “Event Notification Response” on page 261 • “Critical & Offline Disk Arrays” on page 276 • “Frequently Asked Questions” on page 291...
Page 275: Event Notification Response
Chapter 8: Troubleshooting Event Notification Response When you select Event Notification, WebPAM PROe sends popup and/or email messages regarding its status. The messages you see depend on your notification selection and what is currently happening in the VTrak. See “Setting- up User Event Subscriptions”...
Page 276 VTrak E-Class Product Manual Reported Event Corrective Action Battery capacity is normal Normal. Battery is discharging Battery is undergoing reconditioning. Battery is charging Battery is being recharged. Battery reconditioning is Battery reconditioning is finished. complete Battery is malfunctioning Run battery reconditioning. See page 107 or page 151.
Page 277 Chapter 8: Troubleshooting Reported Event Corrective Action Blowers have been Reinstall the cooling unit(s). If the blowers does not removed turn, replace the blowers. See page 210. Blowers are functioning Normal. normally Blowers are NOT installed Reinstall the cooling unit(s). If the blowers does not turn, replace the blowers.
Page 278 VTrak E-Class Product Manual Reported Event Corrective Action Disk array settings have The user successfully logical drive settings. See been changed page 120. Drive Interface Controller Drive-interface controller Normal. found Drive-interface controller Restart the VTrak. See page 207. If this message is NOT found appears repeatedly, contact Technical Support.
Page 279 Chapter 8: Troubleshooting Reported Event Corrective Action Fibre Channel Fibre Channel controller The initiator sent a reset command. If this message has detected bus reset appears repeatedly, contact Technical Support. See page 293. Fibre Channel controller Result of user action. Normal. has received a LUN reset command.
Page 280 VTrak E-Class Product Manual Reported Event Corrective Action Host-interface controller An unidentified error occurred. If this message has encountered an appears repeatedly, contact Technical Support. See unknown error page 293. Host-interface controller A VTrak system error occurred. If this message has encountered a appears repeatedly, contact Technical Support.
Page 281 Chapter 8: Troubleshooting Reported Event Corrective Action Logical drive has been One or more physical drives in the array went offline. placed online. Possible See page 276. data loss Logical drive has been set One or more physical drives in the array went offline. to critical.
Page 282 VTrak E-Class Product Manual Reported Event Corrective Action Online capacity Bad block found on a disk drive. Migration will finish. expansion has Check the disk drive check table after migration and encountered a physical replace disk drive as needed. See page 131. disk error Online capacity System resources are low.
Page 283 Chapter 8: Troubleshooting Reported Event Corrective Action Physical disk assigned as Result of settings or user action. Normal. dedicated spare Physical disk is no longer Result of settings or user action. Normal. assigned as dedicated spare Physical disk has been A disk drive has been inserted into the VTrak inserted subsystem.
Page 284 VTrak E-Class Product Manual Reported Event Corrective Action PSU (Power Supply Units) PSU is not inserted/has A power supply unit is missing from the VTrak. been removed Reinstall the power supply unit. PSU is off A power supply unit is present but turned off. Turn on he power supply.
Page 285 Chapter 8: Troubleshooting Reported Event Corrective Action RAID Level migration is Normal. completed RAID Level migration is Migration paused because of user intervention, paused schedule or a higher priority background activity. RAID Level migration is Migration has resumed again after a pause. resumed RAID Level migration is Migration stopped because of user intervention,...
Page 286 VTrak E-Class Product Manual Reported Event Corrective Action Rebuild is queued Rebuild has been set manually or by schedule. Rebuild marks logical Result of successful rebuild. Normal. drive synchronized upon rebuild completion Redundancy Check Redundancy Check is Redundancy Check has started manually or by started schedule.
Page 287 Chapter 8: Troubleshooting Reported Event Corrective Action Spare check completed Normal. successfully on the given spare drive Spare Drives Physical disk assigned as Result of settings or user action. Normal. global spare Physical disk is no longer Result of settings or user action. Normal. assigned as global spare Global Spare has been Result of settings or user action.
Page 288 VTrak E-Class Product Manual Reported Event Corrective Action Stripe Level migration is System resources are low. Reduce system load or aborted due to an internal restart the VTrak. See page 207. error. Stripe Level migration is Migration has been set manually or by schedule. queued Synchronization Synchronization is started Result of settings or user action.
Page 289 Chapter 8: Troubleshooting Reported Event Corrective Action Transition was switched Transition changed to rebuild because the logical to rebuild drive went critical. Watermark Migration has detected/ Watermarks are progress markers left as the result of cleared stale NV interrupted RAID migrations. If the watermark was Watermark cleared, migration should finish.
Page 290: Critical & Offline Disk Arrays
VTrak E-Class Product Manual Critical & Offline Disk Arrays A fault-tolerant disk array—RAID 1, 1E, 5, 10, and 50—goes critical when a disk drive is removed or fails. A RAID 6 or 60 disk array—goes degraded when a disk drive is removed or fails and critical when two disk drives are removed of fail. Due to the fault tolerance of the disk array, the data is still available and online.
Page 291: Without A Hot Spare Drive
Chapter 8: Troubleshooting After the disk array rebuilds itself using the spare drive, you must replace the failed drive. To set up a spare drive, see “Creating a Spare Drive” on page 135 (WebPAM PROe) or page 181 (CLU). Without a Hot Spare Drive If there is no hot spare drive of adequate capacity, you must remove the failed drive and install an unconfigured replacement drive of the same or greater capacity in the same slot as the failed drive.
Page 292 VTrak E-Class Product Manual Figure 13.Drive carrier LEDs Status Activity During rebuilding, you can still read and write data to the logical drive. However, fault tolerance is lost until the Disk Array returns to OK (not-rebuilding) status. After a successful rebuild: •...
Page 293: Incomplete Array
Chapter 8: Troubleshooting Incomplete Array An incomplete array can result from any of the following conditions: • The NVRAM watermark for the RAID level migration currently in progress is missing or cannot be found • A physical drive goes missing during transport See “Physical Drive Failed”...
Page 294: Physical Drive Problems
VTrak E-Class Product Manual Physical Drive Problems Physical Drive Offline Check the drive for: • PFA Condition – Caused by a bad block or sector. See “Clearing Stale and PFA Conditions” on page 112. • Stale Configuration – Caused by obsolete array information on the physical drive.
Page 295 Chapter 8: Troubleshooting Because the setting for migration under NVRAM requires special access, most users will not encounter this condition. Physical Drive Fails during Transport Transport is the action of moving the physical drives of a disk array: • To different slots in the same VTrak enclosure •...
Page 296: Enclosure Problems
VTrak E-Class Product Manual Enclosure Problems WebPAM PROe displays yellow !s red Xs in Tree View to identify components that need attention. When a yellow ! appears over a Subsystem in Tree View, click on the Enclosure icon. The Enclosure screen will display (below). Figure 14.Enclosure information in Management View In this example, a power supply has failed.
Page 297 Chapter 8: Troubleshooting Overheating Overheating is a potentially serious condition because the excessively high temperatures can lead to disk drive failure and controller malfunction. Overheating usually results from: • Fan failure • Poor air circulation around the enclosure WebPAM PROe reports failed fans along with elevated temperature.
Page 298 VTrak E-Class Product Manual Power Supplies VTraks are equipped with redundant power supplies. The advantage of dual power supplies is that, should one fail, the other will continue powering the subsystem until the faulty one can be replaced. VTrak is capable of operating on a single power supply.
Page 299: Controller Enters Maintenance Mode
Chapter 8: Troubleshooting Controller Enters Maintenance Mode When a RAID controller encounters and internal problem, it can enter maintenance mode. Maintenance mode is only for remedial action in the event of a problem with the controller. When an controller enters maintenance mode, it goes offline and it will display Missing under Readiness Status.
Page 300: Connection Problems
VTrak E-Class Product Manual Connection Problems When you install your Promise product following the instructions in the Quick Start Guide and this Product Manual, you should have little trouble getting your equipment to work the first time. But connection problems can arise that are not the User's or Installer's fault.
Page 301: Fibre Channel Connections
Chapter 8: Troubleshooting your network. The VTrak becomes a node on your network like any other PC, server or other component with an IP address. VTrak ships from the factory an IP address of 10.0.0.2. You must change this address to one that will work with your network. You make the initial IP address setting using the CLI or CLU.
Page 302: Browser Does Not Connect To Webpam Proe
VTrak E-Class Product Manual Browser Does Not Connect to WebPAM PROe If you successfully setup and connected to WebPAM PROe, then suddenly you can no longer connect, it might be the result of the following three conditions: • DHCP is enabled on your VTrak’s virtual management port •...
Page 303: Unsaved Data In The Controller Cache
Such data is sometimes called “dirty,” not to suggest it is corrupted in some way but because it has not been saved to a disk drive. Figure 16.The VTrak E310f dirty cache LED Mgmt FC 1...
Page 304 VTrak E-Class Product Manual...
Page 305: Chapter 9: Support
VTrak after installing disk drives from an older system. VTrak E-Class does not support Parallel ATA (PATA) disk drives. Note that if you move the disk drives from the VTrak E310f/s to the older subsystems, they will not recognize your disk array or logical drive.
Page 306 VTrak E-Class Product Manual WebPAM connection was working OK. But later on, it timed out. What do I do now? The network condition can time-out for several reasons. When an open connection has no action for a specific amount of time (the Administrator can change it), the connection times-out automatically for security reasons.
Page 307: Contacting Technical Support
Chapter 9: Support How can I be sure everything is working OK on the VTrak? Locally: The VTrak enclosure has LEDs on the front to monitor the status of power, field replaceable units (FRUs) and logical drives. When these are green, VTrak is functioning normally.
Page 308 Fax Support +31 (0) 40 256 9463 Attn: Technical Support Phone Support +31 (0) 40 235 2600 If you wish to write us for Promise Technology Europe B.V. support: Science Park Eindhoven 5542 5692 EL Son, The Netherlands Germany E-mail Support...
Page 309 +886 3 578 2390 Attn: Technical Support Phone Support +886 3 578 2395 (ext. 8811) If you wish to write us for Promise Technology, Inc. support: 2F, No. 30, Industry E. Rd. IX Science-based Industrial Park Hsin-Chu 30075, Taiwan (R.O.C.)
Page 310: Limited Warranty
VTrak E-Class Product Manual Limited Warranty Promise Technology, Inc. (“Promise”) warrants that for three (3) years from the time of the delivery of the product to the original end user: the product will conform to Promise’s specifications; the product will be free from defects in material and workmanship under normal use and service.
Page 311: Returning Product For Repair
Chapter 9: Support No other document, statement or representation may be relied on to vary the terms of this limited warranty. Promise’s sole responsibility with respect to any product is to do one of the following: replace the product with a conforming unit of the same or superior product;...
Page 312 Return ONLY the specific product covered by the warranty (do not ship cables, manuals, diskettes, etc.), with a copy of your proof of purchase to: USA and Canada: Promise Technology, Inc. Customer Service Dept. Attn.: RMA # ______ 47654 Kato Road...
Page 313: Appendix A: Useful Information
Adding a Second Controller (page 299) SNMP MIB Files Promise supplies six MIB files to integrate the VTrak E310f/s subsystem into your SNMP system. These files are in the SNMP folder on the VTrak Product CD. The MIB files include: •...
Page 314: Installing A Second Controller
AAMUX adapter on each of the SATA drives. Without the AAMUX adapter, SATA drives will display Not Usable under Operational Status. See the “Installing Disk Drives” on page 12 for installation instructions. This condition does not apply to SAS disk drives. Obtain AAMUX adapters though Promise Technology.
Page 315: Installing A Second Cache Battery
Appendix A: Useful Information Installing a Second Cache Battery The cache battery comes as an assembly, with attaching screws and a wiring harness. Install the new cache battery into the cooling unit above the new controller. To install a new cache battery: On the cooling unit above the new controller, press the release button and pull the handle downward.
Page 316 VTrak E-Class Product Manual...
Page 317: Index
Index Numerics background activities, cont. scheduling 102, 148, 239 10GB Truncate 59, 177 settings 236, 292 2 TB Limitation view 106, 151 batteries battery 12, 13, 300 AAMUX adapter failure about this manual 107, 151 recondition 56, 144, 300 Active-Active replace 102, 148 adaptive writeback cache...
Page 318 VTrak E-Class Product Manual CLU, cont. controller, cont. 101, 147 online help settings problem reporting statistics serial connection unsaved data in cache Telnet connection view 27, 251 Command Line Interface (CLI) controller LED Command Line Utility (CLU) controller status LED cooling unit command queuing 105, 150...
Page 319 Index 28, 103, 252, 276, deleting schedule, background ac- disk status LED 277, 278 tivities 110, 153 DHCP server changed IP address DMA mode, SATA drives 205, download firmware image file dirty cache LED Discover button drive slot numbering disk array 41, 116, advanced creation 83, 185...
Page 320 VTrak E-Class Product Manual 102, flush interval, controller cache failed 112, 155 force offline battery 112, 155 force online physical drive forced unlock 282, 284 power supply 27, 251 FRU LED power supply fan FRU status LED failover and failback 105, 149 FRU VPD failure recovery, physical drive...
Page 321 Index 130, 168 initialize logical drive LED, cont. 27, 291 initiator 82, 185 delete 76, 133, 174 Fibre Channel FRU status 77, 81, Fibre Channel, add 27, 251, 291 heartbeat 174, 184 27, 251, 276 logical drive 79, 133, 176 27, 251, 291 power 80, 81, 176, 184...
Page 322 VTrak E-Class Product Manual logical drive, cont. Media Patrol 122, 166 delete defined 127, 138, 167 41, 60, 117, 159, 162, information enable 130, 168 initialize reported events 61, 144 locate schedule offline MIB files partition and format migrate 41, 117, 120, 159 122, 163 RAID level disk array...
Page 323 Index overheated enclosure physical drive, cont. overview of VTrak supported 110, 153 write cache physical drive settings physical drives partition and format 12, 13 AAMUX password 109, 153 global settings 29, 140 CLI/CLU list physical drives, installing 37, 46, 68 WebPAM PROe popup messages 131, 169...
Page 324 VTrak E-Class Product Manual rebuilding 119, 161 disk array rackmount the VTrak logical drive RAID recipients, NetSend block and double parity stripe 107, 151 recondition a battery 250, 258, 282 red X block and parity stripe 60, 62, 63, Redundancy Check enhanced mirror 130, 169, 178 introduction...
Page 325 Index reported events, cont. scheduling background activities resource not available 41, 118, 121, 159, 165 SMART error sector size Spare Check sector size, defined spare drive security certificate stripe level migration serial cable connections synchronization serial connection system setting up 64, 145 transition setting lock...
Page 326 VTrak E-Class Product Manual SMART error stripe size, defined SNMP subsystem 55, 144 MIB files alias 89, 193 31, 33, 56, 145 service date and time 87, 192 settings fully booted 88, 193 trap sinks information 63, 64, 145 Software Services lock 137, 182 Spare Check...
Page 327 Index 66, 187 test users, view buzzer email test email view 205, 208 TFTP server background activities timing out, WebPAM PROe controllers 104, 152 topology disk arrays 75, 173 topology, Fibre Channel enclosure 60, 178 Transition Fibre Channel logged in devic- automatic 76, 172 defined...
Page 328 VTrak E-Class Product Manual watermark, reported events WebPAM PROe, initial setup using Web Server 86, 191 42, 118, 121, service write cache policy 85, 191 129, 159, 165 settings 38, 48 WebPAM PROe write cache policy, defined 110, access over an intranet write cache, physical drive access over the Internet Event Frame...

This manual is also suitable for:

Vtrak e310s

Promise Technology VTRAK E310f Product Manual

Chapter 1: Introduction to Vtrak

Chapter 2: Vtrak Installation

Chapter 3: Vtrak Setup

Chapter 4: Management with Webpam Proe

Chapter 5: Management with the CLU

Quick Links

Related Manuals for Promise Technology VTRAK E310f

Summary of Contents for Promise Technology VTRAK E310f
