3) Some commands are discussed together for conveni-
ence. In these cases, a slash (I) separates the
commands.
Ex ampl e :
a) DINT 1 EINT
b) SWSEG wseg 1 SWOFF woff
In each example, there are two distinct
They are discussed together because
related in function.
commands.
they are
4) Memory addresses may be shown with the segment
enclosed in
<
and
>,
with the offset immediatly
following. <1>0 refers to segment 1, offset
o.
5) Command parameter values retain their previous
values until changed. Most parameters have
default values, described in the command descrip-
tions below. Some parameters are shared by more
than one command.
Example: The following commands all share the
write buffer start address parameters,
wseg and wo ff:
a) WR wseg woff Inth cyl head sec
b) SWSEG wseg
c) SWOFF wo ff
6)
Parameter defaults are:
rseg .-
1
wseg =
2
dseg =
desseg =
1
srcseg =
2
rndseg =
2
rramseg =
1
wramseg =
2
putseg =
2
fseg
.-
2
roff
.-
0
woff =
0
doff =
0
deso ff =
0
srcoff =
0
rndoff
-= 0
rramoff =
0
wramoff =
0
putoff =
0
foff ..
0
fpat = ffff
Inth
.-
512
rlnth =
512
cmplnth =
512
unit _.
0
cyl =
0
head =
0
sec =
0
maxseg = 3 offset val =
0
intvee =
0
fstart =
0
fintvl-=
1
rramlnth =
2048
wramlnth =
1280
7)
Some parameters are dependent upon the current
disk unit. SMD disks have different numbers of
