2.4.6 Parallel IDE Interface Connector: IDE1
The board provided one IDE Port to support maximum up to two IDE
devices.
Pin Description
1 Reset #
4 Data 8
7 Data 5
10 Data 11
13 Data 2
16 Data 14
19 GND
22 GND
25 IOR #
28 N/C
31 Interrupt
34 N/C
37 HDC CS0 #
40 GND
IDE1
Jumpers and Connectors
SBC81203 LGA775 SBC User's Manual
Pin Description Pin
2 GND
5 Data 6
8 Data 10
11 Data 3 12
14 Data 13 15
17 Data 0 18
20 N/C 21
23 IOW # 24
26 GND 27
29 N/C 30
32 N/C 33
35 SA0 36
38 HDC CSI # 39
Description
3 Data 7
6 Data 9
9 Data 4
Data 12
Data 1
Data 16
N/C
GND
IOCHRDY
GND-Default
SA1
SA2
HDD Active #
